MODEL W1768/W1769
1 HP POWER FEEDER
WITH 4 ROLLERS
OWNER'S MANUAL
(FOR MODELS MANUFACTURED SINCE 5/07)
Phone: (360) 734-3482 • Online Technical Support: tech-support@shopfox.biz
COPYRIGHT © SEPTEMBER, 2007 BY WOODSTOCK INTERNATIONAL, INC. REVISED FEBRUARY, 2014 (BL)
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE OR FORM WITHOUT
THE WRITTEN APPROVAL OF WOODSTOCK INTERNATIONAL, INC.
#9857CR  Printed in Taiwan

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the W1768 and is the answer not in the manual?

Questions and answers

Related Manuals for Shop fox W1768

Summary of Contents for Shop fox W1768

  • Page 1   MODEL W1768/W1769 1 HP POWER FEEDER WITH 4 ROLLERS OWNER'S MANUAL (FOR MODELS MANUFACTURED SINCE 5/07) Phone: (360) 734-3482 • Online Technical Support: tech-support@shopfox.biz COPYRIGHT © SEPTEMBER, 2007 BY WOODSTOCK INTERNATIONAL, INC. REVISED FEBRUARY, 2014 (BL) WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE OR FORM WITHOUT THE WRITTEN APPROVAL OF WOODSTOCK INTERNATIONAL, INC. #9857CR  Printed in Taiwan...
  • Page 2 This manual provides critical safety instructions on the proper setup, operation, maintenance, and service of this machine/tool. Save this document, refer to it often, and use it to instruct other operators. Failure to read, understand and follow the instructions in this manual may result in fire or serious personal injury—including amputation, electrocution, or death.

  • Page 3: Table Of Contents

    SERVICE......................22 General ....................22 Wheel Replacement ..................22 Troubleshooting................... 23 Electrical Safety Instructions ................24 Model W1768 Wiring Diagram ................25 Model W1769 Wiring Diagram ................26 PARTS......................27 Main Breakdown ..................27 Stand Breakdown ..................29 Labels & Cosmetics ..................30 WARRANTY......................

  • Page 4: Introduction

    Model W1768/W1769 (For Machines Mfg. Since 5/07) INTRODUCTION Woodstock.Technical.Support Woodstock International, Inc. is committed to customer satisfaction. Our intent with this manual is to include the basic information for safety, setup, operation, maintenance, and service of this product. In the event that questions arise about your machine, please contact Woodstock International Technical Support at (360).734-3482 or send e-mail to: tech-support@shopfox.biz.

  • Page 5: Machine Specifications

    Model W1768/W1769 (For Machines Mfg. Since 5/07) MACHINE SPECIFICATIONS Machine Data Sheet © Woodstock International, Inc. • Phone #: (800) 840-8420 • Web: www.shopfox.biz MODEL W1768/W1769  1 HP POWER FEEDER WITH 4 ROLLERS Model Number W1768 W1769 Overall Dimensions 144 lbs. Weight Length/Width/Height 43–1/4 x 23–1/2 x 29–1/2 in.
  • Page 6 Model W1768/W1769 (For Machines Mfg. Since 5/07) Model Number W1768 W1769 Operation Information Minimum Workpiece Length 7 in. Number of Feed Speeds Feed Speeds 13, 26, 33, 66 FPM Swing 360 deg. Vertical Movement 9-7/8 in. Horizontal Movement 18-1/8 in.
  • Page 7 Model W1768/W1769 (For Machines Mfg. Since 5/07) Controls.and.Features Vertical Travel Handcrank Upper Elbow 1 HP 2-Speed Joint Lock Motor Vertical Travel Horizontal Lock Travel Lock Lower Elbow Joint Lock Horizontal Handwheel Gearbox Oil Rotary Plug Movement Lock Power Feeder Swivel Lock...

  • Page 8: Safety

    Model W1768/W1769 (For Machines Mfg. Since 5/07) SAFETY SAFETY For.Your.Own.Safety, Read.Manual.Before.Operating.Machine The. purpose. of. safety. symbols. is. to. attract. your. attention. to. possible. hazardous. conditions.. This. manual.uses.a.series.of.symbols.and.signal.words.intended.to.convey.the.level.of.importance.of.the. safety.messages..The.progression.of.symbols.is.described.below..Remember.that.safety.messages.by. themselves. do. not. eliminate. danger. and. are. not. a. substitute. for. proper. accident. prevention. mea- sures—this.responsibility.is.ultimately.up.to.the.operator!
  • Page 9 Model W1768/W1769 (For Machines Mfg. Since 5/07) WEARING.PROPER.APPAREL..Do not wear FORCING.MACHINERY..Do not force machine. It clothing, apparel, or jewelry that can become will do the job safer and better at the rate for entangled in moving parts. Always tie back which it was designed.

  • Page 10: Additional Safety For Power Feeders

    Model W1768/W1769 (For Machines Mfg. Since 5/07) Additional.Safety.for.Power.Feeders MAIN.INJURY.HAZARDS:.Death,.amputation,.or.crushing.injuries.from.getting.entangled.in. moving.parts—which.may.include.being.pulled.into.the.cutting.tool.on.attached.machinery;. death,.blindness,.broken.bones,.or.bruises.from.being.struck.by.an.ejected.workpiece. (kickback)..To.minimize.your.risk.of.these.hazards,.always.heed.the.following.information: ATTACHED.MACHINERY. Follow all warnings and FEATHERBOARD. When cutting long or large safety information for the attached machine stock that is difficult to feed properly, use doing the cutting work.

  • Page 11: Electrical

    Model W1768/W1769 (For Machines Mfg. Since 5/07) ELECTRICAL Circuit.Requirements This machine must be connected to the correct size and The. machine. must. be. properly. set. up. type of power supply circuit, or fire or electrical damage before. it. is. safe. to. operate.. DO. NOT.

  • Page 12: Grounding Requirements

    Model W1768/W1769 (For Machines Mfg. Since 5/07) Grounding.Requirements This machine MUST be grounded. In the event of certain The machine must be properly set up types of malfunctions or breakdowns, grounding provides before it is safe to operate. DO NOT a path of least resistance for electric current to travel—in...

  • Page 13: Setup

    Model W1768/W1769 (For Machines Mfg. Since 5/07) SETUP Unpacking This machine has been carefully packaged for safe transportation. If you notice the machine has been damaged during shipping, please contact your authorized Shop Fox dealer immediately. Inventory The following is a description of the main components Keep.

  • Page 14: Cleaning Machine

    Model W1768/W1769 (For Machines Mfg. Since 5/07) Cleaning.Machine To prevent corrosion during shipment and storage of your Gasoline.and.petroleum. machine, the factory has coated the bare metal surfaces products.have.low.flash. of your machine with a heavy-duty rust prevention points.and.can.explode. compound. or.cause.fire.if.used.to. clean.machinery..Avoid.

  • Page 15: Assembly

    Model W1768/W1769 (For Machines Mfg. Since 5/07) Assembly To correctly position this power feeder on your table top, first gather the stand parts shown in Figure.6, then assemble the power feeder stand (refer to the parts diagram for any intricate details).

  • Page 16: Base Mounting

    Model W1768/W1769 (For Machines Mfg. Since 5/07) Base.Mounting Position the power feeder on the table top to Also, you must be able to adjust the power determine where to drill your base mounting feeder so it points towards the machine fence slightly (see Figure.8).
  • Page 17 Model W1768/W1769 (For Machines Mfg. Since 5/07) Through-Bolt.Mounting. We recommend that you mount your new power feeder to the machine table using the included M12-1.75 x 50 Bolt hex bolts and lock washers, plus additional flat washers Feeder and locking hex nuts for a through-bolt setup (see.Figure.

  • Page 18: Test Run

    Model W1768/W1769 (For Machines Mfg. Since 5/07) Test.Run Once power feeder assembly is complete and mounted on the table, you must test run your power feeder to make sure it runs properly. Your power feeder motor has two feed speeds and two feed directions that are controlled at the switch (see Figure.11).

  • Page 19: Operations

    Model W1768/W1769 (For Machines Mfg. Since 5/07) OPERATIONS General This machine will perform many types of operations that are beyond the scope of this manual. Many of these operations can be dangerous or deadly if performed incorrectly. The instructions in this section are written with the understanding that the operator has the necessary knowledge and skills to operate this machine.

  • Page 20: Changing Feed Speed

    Model W1768/W1769 (For Machines Mfg. Since 5/07) Changing.Feed.Speed Your power feeder has the option to feed a workpiece at 13, 26, 33, and 66 feet per minute. These rates are achieved by changing the combination of change gears, shown in Figure.12, and turning the motor switch to high or low range operation, shown in Figure.13.

  • Page 21: Power Feeder Accessories

    Model W1768/W1769 (For Machines Mfg. Since 5/07) Power.Feeder.Accessories The following power feeder accessories may be available through your local Woodstock International Inc. Dealer. If you do not have a dealer in your area, these products are also available through online dealers.
  • Page 22 Model W1768/W1769 (For Machines Mfg. Since 5/07) The.Model.D3096.Shop.Fox..Featherboard helps reduce the risk D3096 of kick-back and achieve consistent results. Designed to lock into standard ⁄ " x ⁄ " miter gauge slots, this Featherboard is adjustable for various stock widths and miter slot locations. No drilling or bulky clamp arrangements! The.Model.D2018.60-Pc..Tap.&.Die.Set includes both coarse and...

  • Page 23: Maintenance

    Model W1768/W1769 (For Machines Mfg. Since 5/07) MAINTENANCE General Regular periodic maintenance on your machine will ensure its optimum performance. Make a habit of inspecting your machine each time you use it. Check.for.the.following.conditions.and.repair.or. replace.when.necessary: • Loose mounting bolts and damaged wheel rubber.

  • Page 24: Service

    Model W1768/W1769 (For Machines Mfg. Since 5/07) SERVICE General This section covers the most common service adjustments or procedures that may need to be made during the life of your machine. If you require additional machine service not included in this section, please contact Woodstock International Technical Support at (360) 734-3482 or send e-mail to: tech-support@shopfox.biz.

  • Page 25: Troubleshooting

    Model W1768/W1769 (For Machines Mfg. Since 5/07) Troubleshooting This section covers the most common problems and corrections with this type of machine. WARNING!.DO.NOT.make.any.adjustments.until.power.is.disconnected.and. moving.parts.have.come.to.a.complete.stop! PROBLEM POSSIBLE.CAUSE CORRECTIVE.ACTION Motor will not start. 1. Low voltage. 1. Check power supply for proper voltage.

  • Page 26: Electrical Safety Instructions

    Model W1768/W1769 (For Machines Mfg. Since 5/07) Electrical.Safety.Instructions These pages are current at the time of printing. However, in the spirit of improvement, we may make changes to the electrical systems of future machines. Study this diagram carefully. If you notice differences between your machine and these wiring diagrams, call Woodstock International Technical Support at (360) 734-3482.

  • Page 27: Model W1768 Wiring Diagram

    Model W1768/W1769 (For Machines Mfg. Since 5/07) Model.W1768.Wiring.Diagram 220V Two Speed Motor Two Speed Side A Side B Motor Direction Switch Ground Read Page 24 STOP Before Wiring 6-15 Plug (As Recommended) Figure.17. Motor switch (side view). Figure.18. Motor switch and capacitor (front view).

  • Page 28: Model W1769 Wiring Diagram

    Model W1768/W1769 (For Machines Mfg. Since 5/07) Model.W1769.Wiring.Diagram 220V Two Speed Motor Two Speed Side A Side B Motor Direction Switch Ground Read Page 24 STOP 220 VAC Before Wiring 3-Phase 15-15 PLUG (as recommended) Figure.19. Motor switch (side view).

  • Page 29: Parts

    Model W1768/W1769 (For Machines Mfg. Since 5/07) PARTS Main.Breakdown -27-...
  • Page 30 XPN09M HEX NUT M12-1.75 70-4 X1768070-4 MOTOR FAN X1768024 GREASE NIPPLE 70-5 XPC035A R CAP 35M 250V 1-1/2 X 2-3/4 (W1768) X1768025 ROLLER SPINDLE 70-6 X1768070-6 SEALING RING X1768026 SPROCKET CASE HEX BOLT M12-1.75 XPORS028 O-RING 27.5 X 2.0 S28...

  • Page 31: Stand Breakdown

    Model W1768/W1769 (For Machines Mfg. Since 5/07) Stand.Breakdown 102V2 106V2 110V2 102V2 102V2 PART # DESCRIPTION PART # DESCRIPTION X1768101 COLUMN BASE XPB22M HEX BOLT M8-1.25 X 50 102V2 XPB43M HEX BOLT M12-1.75 X 75 X1768131 HORIZONTAL TUBE CONE XPW06M...

  • Page 32: Labels & Cosmetics

    Safety.labels.warn.about.machine.hazards.and.how.to.prevent.serious.personal.injury..The.owner. of.this.machine.MUST.maintain.the.original.location.and.readability.of.all.labels.on.this.machine.. If.any.label.is.removed.or.becomes.unreadable,.REPLACE.that.label.before.allowing.machine.to.be. operated.again..Contact.us.at.(360).734-3482.or.www.shopfoxtools.com.to.order.new.labels.. 200V2 PART # DESCRIPTION PART # DESCRIPTION 200V2 X1768200V2 MACHINE ID LABEL CSA V2.10.12 (W1768) X1765207 DAMPNESS WARNING LABEL 200V2 X1769200V2 MACHINE ID LABEL CSA V2.10.12 (W1769) X1765204 DISCONNECT POWER LABEL X1765201 ENTANGLEMENT LABEL X1765208 LUBRICATION NOTICE LABEL...
  • Page 33 Model W1768/W1769 (For Machines Mfg. Since 5/07)
  • Page 34 Fold along dotted lIne place stamp Here Woodstock international inc. p.o. box 2309 bellingham, Wa 98227-2309 Fold along dotted lIne tape along edges--please do not staple...

  • Page 35: Warranty

    Woodstock International, Inc. will repair, replace, or arrange for a dealer refund at its expense and at its option, the Shop Fox machine or machine part, which in proper and intended use has proven to be defective, provided that the original owner returns the product prepaid to an authorized warranty or repair facility as designated by our Bellingham, Washington office with proof of their purchase of the product within two years, and provides Woodstock International, Inc.
  • Page 36 High Quality Machines and Tools Woodstock International, Inc. carries thousands of products designed to meet the needs of today's woodworkers and metalworkers. Ask your dealer about these fine products:...
