- Page 1 Model No. CRT-350-N SPECIFICATION Date 2016/4/8 Ver. Motor-driven Card Reader Page 1/17 User Manual Motor-driven Card Reader Model:CRT-350-N USER MANUAL CREATOR(CHINA) TECH CO., LTD.
- Page 2 SPECIFICATIONS 2/17 CRT-350-NJ10 Version Profile Version Completed Descriptions 2016-04-02 Product Outline Modification 2015-11-10 The First Release...
- Page 3 SPECIFICATIONS 3/17 CRT-350-NJ10 CATALOG 1 Product Composition ....................错误！未定义书签。 2 Product Model ......................错误！未定义书签。 3 Product Feature ......................错误！未定义书签。 4 Card Type Required ....................错误！未定义书签。 5 Universal Specs......................错误！未定义书签。 6 Basic Function ......................错误！未定义书签。 7 Adaptability ......................错误！未定义书签。 8 Lifetime ........................错误！未定义书签。 9 Reliability ........................
-
Page 4: Product Composition
SPECIFICATIONS 4/17 CRT-350-NJ10 1 Product Composition CRT-350-N Basic composition as follows: 1－ Electronic control shutter 2－ Card reader main body 3－ PSAM card slot 4－ RS-232 communication interface 5－ DC socket Caution: Above of DC 30V is prohibited, which may damage the device. -
Page 5: Product Model
SPECIFICATIONS 5/17 CRT-350-NJ10 2 Product Model CRT-350-N 3 Product Principal Feature The product is an ATM-oriented card reader supporting magnetic stripe card & contact IC card. 1) R/W magnetic stripe card & IC card with 2 PSAM card slots. 2) Electronic control shutter, unlock shutter via mag-stripe card detected or switch. - Page 6 SPECIFICATIONS 6/17 CRT-350-NJ10 3.6 R/W Contact IC Card Support R/W asynchronous or synchronous card 1). CPU Card (Asynchronous) ISO/IEC 7816 -1,-2,-3 criteria Table 1： CPU & IC Card Interface Specifications IC Card Specifications Descriptions Definition IC card power DC+5V±0.25V (Max 50mA) DC+3V±0.25V (Max 20mA) Open circuit Working clock is controlled by the...
- Page 7 SPECIFICATIONS 7/17 CRT-350-NJ10 3.7 R/W SAM Support to operate SAM,2 SAM slots integrated（SAM1,SAM2） Support to detect SAM status Table 2: SAM card, IC card interface specs. IC Card Specs. Descriptions Definition IC card power DC+5V±0.25V (Max 50mA) DC+3V±0.25V (Max 20mA) Open circuit Working clock is controlled by 3.58MHz(default)
- Page 8 SPECIFICATIONS 8/17 CRT-350-NJ10 4 Card Type Requested Length：85.47～85.90 mm Width: 53.92～54.18 mm Thickness: 0.76±0.1 mm 4.1 Mag-stripe Card 1) Mag-stripe card type ISO/IEC 7810/ID-1, 7811-1/2/6 approved. 2) Magnetic force Support Lico / Hico 3) Read mag-stripe card 4) Write mag-stripe card 5) Mag-stripe card recording specs.
-
Page 9: Basic Function
SPECIFICATIONS 9/17 CRT-350-NJ10 5 Universal Specifications 5.1 Product Outline Please refer to Appendix enclosed herein for the size & outline photo of the product. 5.2 Product Weight Around1.3kg (Excluding accessories & package) 5.3 Power Specs. 1) Working Voltage： DC 24V ±10% 2) Power Ripple：<200mV 3) Working Current (Excluding magnetic current)：... - Page 10 SPECIFICATIONS 10/17 CRT-350-NJ10 7 Adaptability 7.1 Working Temperature & Humidity 5~50°, 20% ~ 80%RH 7.2 Storage Temperature & humidity -20°~ +70°, 20% ~ 80%RH Remarks: Under storage status, card reader doesn’t works. -20° Storage time <24hours 60° storage time <96hours 7.3 Vibration Frequency scope:5～50Hz；...
- Page 11 SPECIFICATIONS 11/17 CRT-350-NJ10 8 Lifetime 8.1 Card Reader Lifetime Card transmission: 1,000,000 times （One time means card shuttle runs in the corridor of card reader.） Principal Parts: R/W Magnetic Head 1,000,000 times Pre-detecting magnetic head: 1,000,000 times Drive motor: 1,500,000 times Synchronous rubber belt: 1,000,000 times Drive rubber wheel:...
- Page 12 SPECIFICATIONS 12/17 CRT-350-NJ10 9.5 Maintenance Requirements 1) Optical sensor maintenance 2) Drive mechanism maintenance...
-
Page 13: Power Failure Protection
SPECIFICATIONS 13/17 CRT-350-NJ10 10 Power Failure Protection The card will be back to users when backup capacitor connected during main power down. 10.1 Power Failure Definition 1) Power failure value:<20V 2) Power failure lasting time:>15ms 10.2 Power Failure Troubleshooting Process: When power failure occurred during card reader’s operation,the card inside will be driven to the front by resetting initialization command Pd Wv and the stored power of backup capacitor. - Page 14 SPECIFICATIONS 14/17 CRT-350-NJ10 12 Electronic Interface RS-232 Interface & Power Socket 12.1 RS-232Communication Interface 1) Card Reader’s DB-9PIN Definition Signal Input/Output Functions Data receive Data send Data ready Signal Ground Data prepare Request send Clear send 2) RS-232 Data cable wiring diagram...
- Page 15 SPECIFICATIONS 15/17 CRT-350-NJ10 12.2 Power Socket Signal Function +24V 24V main power input PGND Power Ground PGND Power Ground +24VB Backup power input Single power wiring PIN1, PIN4 connect DC 24V positive,PIN2,PIN4 connect DC 24V Ground 2) Backup capacitor wiring （Backup capacitor specs refers to 10.4） PIN1 connects DC 24V positive,PIN2 connect DC 24V Ground PIN4 connect backup capacitor positive,PIN3 connect backup capacitor negative...
-
Page 16: Specifications
SPECIFICATIONS 16/17 CRT-350-NJ10 13 Product Outline... - Page 17 SPECIFICATIONS 17/17 CRT-350-NJ10...
