STL Trigger-Beam LED Flashlight Instruction Manual

Phone 800.757.2581
STL Trigger-Beam LED Flashlight Instruction Manual
Product structure:
Technical parameter:
Dimension
Weight
Light source
Beam brightness
Rechargeable Battery
Non-rechargeable
batteries
Outer casing material
Surface treatment
Lens material
Cruising Time
Operation：
1.
Battery Installation，twist the end cap off, slide the 18650 battery positive
end upward into the flashlight and twist on the end cap to secure the battery.
2. Gently push the back switch to change between high, low and strobe
functionality on the flashlight.
3.
Press the back switch in all the way to power the flashlights on & off.
Charging:
1.
Rotate the grab handle counter-clockwise until the circular plug is fully
accessible.
2.
Plug in the flashlight charger to the flashlight and the light on the wall or car
charger plug will activate showing the charger is in effect.
3. The flashlight will need to be in the On position in order for the flashlight to
begin charging. The light indicator on the charger will turn red when the
flashlight is in the on position meaning the flashlight is charging and not yet fully
2809 Business Park Dr
•
Fax 844.894.2652
5.7"L x 1.34" lamp diameter x 1.02" handle diameter
130G
CREE high-power LED
220 Lumens
18650 Rechargeable lithium battery
(2) 123 Size Batteries
Aluminum 6061-T6
Titanium black
FCL lens
100% Brightness-186 minutes, 10% Brightness-3300 minutes
• Buda • Texas •78610
•
Email customerservice@speedtechlights.com
