INDUCTION HEATERS
Read these operation
instructions attentively
INSTRUCTION MANUAL
Fast Therm 20
Fast Therm 35
Fast Therm 150
Fast Therm 300
NTN-SNR ROULEMENTS
1 rue des Usines – BP 2017
74000 Annecy Cedex - France
www.ntn-snr.com
Control all parts without delay for possible transport
damages. If such damages are determined inform the
carriers immediately
Advertisement
Table of Contents
Related Manuals for NTN-SNR Fast Therm 20
Summary of Contents for NTN-SNR Fast Therm 20
- Page 1 INDUCTION HEATERS Read these operation instructions attentively INSTRUCTION MANUAL Fast Therm 20 Fast Therm 35 Fast Therm 150 Fast Therm 300 NTN-SNR ROULEMENTS 1 rue des Usines – BP 2017 74000 Annecy Cedex - France www.ntn-snr.com Control all parts without delay for possible transport damages.
-
Page 2: Table Of Contents
2. Introduction ................5 3. Installation ................5 4. Setting up the work piece ........... 6 5. Fast therm 20 operating instructions ........ 7 6. Fast Therm 35, 150 and 300 operating instructions ..8 7. Malfunctioning / Error Signals ......... 10 8. -
Page 3: Safety Precautions
1. SAFETY PRECAUTIONS: The operation instruction should always be followed: • NTN-SNR ROULEMENTS shall not be held liable for damages caused by improper handling or by use which does not comply with the designation purpose. • Prerequisites of the operator:... - Page 4 Ensure that the machine operates at the correct supply voltage. The heater is supplied with a plug, change the plug should only be made by a suitably qualified person. • Do not use or store the heater in humid environments. NTN-SNR ROULEMENTS induction heaters are designed for indoor use only. •...
- Page 5 Fast Therm 20: Distance cm X (mT) 2.95 0.76 0.21 0.11 0.09 0.07 Y (mT) 3.74 0.84 0.32 0.16 0.11 0.09 Fast Therm 35: Distance cm X (mT) 4.26 1.12 0.35 0.16 0.11 0.08 Y (mT) 3.58 1.66 0.56 0.27 0.16...
-
Page 6: Introduction
• The wires should be connected as follows: Fast Therm 20 ET 35: Braun (Black us) = Phase | blue (White us) = neutral | Green / yellow = ground. Fast Therm 150 et 300: Phase = blue (black us) | Phase = Brown (black us) | Ground = Green / yellow: •... -
Page 7: Setting Up The Work Piece
Horizontal • Vertically and Horizontally: The part should never touch the housing. • Small objects to be heated in vertically position Fast Therm 20: Fast Therm 35: Max. dimensions part Max dimensions part Max inner diameter (d): 160 mm (6.3”) Max inner diameter: 190 mm (7.48‘‘) -
Page 8: Fast Therm 20 Operating Instructions
8KG (17 lbs) 12KG (26 lbs) 20KG (44 lbs) 5. Fast Therm 20 operating instructions: Do not start the heating process without using a bar! • Connect the machine (according to the type in 110 or 230V-16A) and attach the magnetic sensor. -
Page 9: Fast Therm 35, 150 And 300 Operating Instructions
When the equipment is running, the default display on the screen is 110° C (230° F). By pressing keys A and B, you can raise or drop the temperature. Press the key C « START/STOP » to begin heating. The screen begins to show the temperature from 50°... - Page 10 6.2. Time mode: • Switch on the equipment. Press key E. • The machine displays « 00.00 ». • Set the heating time in seconds by pressing keys A and B. After setting the seconds, adjust the time in minutes by pressing key E and then use keys A and B. •...
-
Page 11: Malfunctioning / Error Signals
E01: The probe is not plugged in or the cable of the probe is broken E02 (Fast Therm 20) / E03 (Fast Therm 35/150/300): The increase of temperature is lower than 1° C (33.8 ° F) in 1 minute, Please check: •... -
Page 12: Technical Data
9. Technical data: Fast Therm 20 : Type Fast Therm 20 Voltage 115V-15A-60Hz / 230V-16A-50Hz Power 1.7 KVA (115V) / 3.6 KVA (230V) Temperatures control Max.240ºC (464ºF) Heating speed control Microprocessor controlled Overall dimensions 345x200x240mm (13,5” x 7,9” x 9,5”) Max. - Page 13 Fast Therm 150 : Type Fast Therm 150 Voltage 460V-32A-60Hz / 400V-32A-50Hz Power 14.7 KVA (460 V) / 12.8 KVA (400 V) Temperatures control Max. 240° C (464° F) Heating speed control Microprocessor controlled Overall dimensions 505x260x440mm (19,8” x 10,2” x 17,3”) Max.
-
Page 14: Electrical Drawing
10. Electrical Drawing: Electrical drawing Fast therm 20: Electrical drawing Fast Therm 35:... - Page 15 Electrical drawing Fast Therm 150 and 300:...
-
Page 16: Declaration Of Conformity
Neither NTN -SNR ROULEMENTS nor its employees shall be liable for any direct or indirect damages arising either out of any defects in the products or the use of the products, even if NTN-SNR ROULEMENTS has been informed in advance of the possibility of such damage. Such excluded damages shall include, but are not limited to: costs of removal and installation, losses sustained as the result of injury to any person, or damage to property.
