Freenotes Harmony Park IMBARIMBA Installation Manuals

IMBARIMBA
The Imbarimba is a unique musical design combining the
element of two African instruments: the marimba and the
kalimba. The notes are arranged in the layout of the kalimba.
This allows both hands equal access to the upper and lower
notes. Coated fiberglass bars are entirely weatherproof
and withstand hard use and the elements.
(LH) C MAJOR / (RH) A MINOR PENTATONIC
3
45 4 "
3
17 4 "
PROPRIETARY AND CONFIDENTIAL
FREENOTES HARMONY PARK
THE INFORMATION CONTAINED IN THIS
194 BODO DRIVE, UNIT F
DRAWING IS THE SOLE PROPERTY OF
DURANGO CO 81303
FREENOTES HARMONY PARK. ANY
TEL: (970) 375-7825
REPRODUCTION IN PART OR AS A WHOLE
FAX: (970) 247-0856
WITHOUT THE WRITTEN PERMISSION OF
EMAIL: INFO@FREENOTESHARMONYPARK.COM
FREENOTES HARMONY PARK IS
WWW.FREENOTESHARMONYPARK.COM
PROHIBITED.
5
28 8 "
IMBARIMBA 2016
PRODUCT SHEET / INSTALLATION GUIDE
SCALE: 1:16
SHEET 1 OF 6
