Product Manual
LS1400 Light Sensor
PRODUCT DESCRIPTION
The Audacy LS1400 Light Sensor is a battery
powered device specially designed to detect
ambient light levels and wirelessly transmit
this information to the Audacy Gateway.
The information provided by the sensor is
used to determine the amount of artificial
light needed in given space. This provides
for daylight harvesting and reduction of
energy consumption.
25-year battery life design and will not
require AC or DC line power, providing
building owners and occupants placement
flexibility.
KEY FEATURES
FCC and IC approved
Flexible mounting options
25+ year battery life
Small form factor with internal antenna
RoHS compliant
Factory configurable for custom
applications
ND7948-2 02/2014
The product has a
Users Manual – LS1400 Light Sensor
www.idealindustries.com
PRODUCT CONTENTS
The following items are included inside the
package:
Qty Description
1
Light Sensor LS1400
1
Sensor Cradle
2
Mounting Screw
1
Locking Screw
1
Instruction card
Page 1
Advertisement
Table of Contents
Related Manuals for Audacy LS1400
Summary of Contents for Audacy LS1400
- Page 1 Product Manual LS1400 Light Sensor PRODUCT DESCRIPTION The Audacy LS1400 Light Sensor is a battery powered device specially designed to detect ambient light levels and wirelessly transmit this information to the Audacy Gateway. The information provided by the sensor is used to determine the amount of artificial light needed in given space.
- Page 2 1. Wall-mount the LS1400 cradle in the desired location with the optional mounting screws(2). Cradle can be mounted directly to drywall. 2. Press the button located on the bottom side of the LS1400 to activate device. 3. An optional screw can be used to lock the LS1400 in the cradle.
- Page 3 Product Manual LS1400 Light Sensor MECHANICAL (REAR VIEW) *Dimensions in inches MECHANICAL (TOP VIEW) *Dimensions in inches ND7948-2 02/2014 Users Manual – LS1400 Light Sensor Page 3 www.idealindustries.com...
- Page 4 Product Manual LS1400 Light Sensor SUPPORT Technical support for IDEAL INDUSTRIES products can be initiated through the following methods: Website: http://www.idealindustries.com/support/ Telephone: +1 800-435-0705 Email: contactus@idealindustries.com ND7948-2 02/2014 Users Manual – LS1400 Light Sensor Page 4 www.idealindustries.com...
- Page 5 20cm is maintained between the radiator (antenna) & user’s/nearby person’s body at all times. 2. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. ND7948-2 02/2014 Users Manual – LS1400 Light Sensor Page 5 www.idealindustries.com...
- Page 6 PRODUCTS, TO THOROUGHLY TEST THE SAME FOR SAFETY PURPOSES. CUSTOMER ASSUMES THE SOLE RISK AND LIABILITY OF ANY USE OF IDEAL INDUSTRIES, INC. PRODUCTS IN CRITICAL APPLICATIONS, SUBJECT ONLY TO APPLICABLE LAWS AND REGULATIONS GOVERNING LIMITATIONS ON PRODUCT LIABILITY. ND7948-2 02/2014 Users Manual – LS1400 Light Sensor Page 6 www.idealindustries.com...
- Page 7 This limited product warranty gives you specific legal rights, and you may also have other legal rights which vary from state to state. ND7948-2 02/2014 Users Manual – LS1400 Light Sensor Page 7 www.idealindustries.com...
