  • Page 1 +44 (0) 1933 35 2000 +44 (0) 1933 31 2000 fax © 2006 Belkin Corporation. All rights reserved. All trade names are registered trademarks of respective manufacturers listed. Mac, Mac OS, and Apple are trademarks of Apple Computer, Inc., registered in the U.S. and other countries.

  • Page 2: User Manual

    SOHO DVI KVM Switch User Manual F1DD102U F1DD104U...

  • Page 3: Table Of Contents

    Display Diagrams ... 3 Specifications ... 4 2. What You Need to Get Started ... 5 Equipment Requirements ... 5 3. How to Install Your SOHO KVM Switch ... 6 Pre-Configuration ... 6 Connecting Your Console ... 7 Connecting Your Computers ... 8 Connecting USB Devices ...

  • Page 4: Usb Keyboard And Mouse With Up To Four Computers. Designed To Organize

    Introduction Congratulations and thank you for purchasing Belkin’s SOHO DVI KVM Switch. The SOHO KVM Switch lets you share one DVI-D monitor, and one USB keyboard and mouse with up to four computers. Designed to organize and save your desk space, the SOHO KVM Switch sits neatly on your desk to reduce clutter.

  • Page 5: Features

    • Rack-Mountable The SOHO KVM Switch can also be mounted to a standard 19-inch rack using an optional rack-mount bracket (Belkin part number F1D005), sold separately. • ADC Monitor Support The SOHO KVM Switch supports ADC monitors with Apple® adapters.

  • Page 6: Display Diagrams

    Introduction Display Diagrams LED Indicators Direct-Access Port Selectors Console Speaker and Microphone Jacks Monitor Port DC Power Jack DC 5V, 2.5A audio Device B Device A Device Ports (front panel) �� �� �� (F1DD104U model shown) (back panel) Console PC 4 PC 3 Console USB 04...

  • Page 7: Specifications

    Dimensions: (F1DD102U) (F1DD104U) Weight: (F1DD102U) (F1DD104U) Note: Specifications are subject to change without notice. F1DD102U, F1DD104U 2 and 4 for 2- and 4-port models DVI-D, ADC (with DVI adapter) Up to 1600x1200@65Hz USB Type A USB Type A 3.5mm jack 3.5mm jack...

  • Page 8: What You Need To Get Started

    The SOHO KVM Switch supports any USB-based mouse. Cables Belkin SOHO Series KVM Cables are required to connect your computers to your SOHO KVM Switch. Belkin KVM Cables offer the highest quality possible to support resolutions of up to 1600x1200@65Hz and to ensure that your data is optimally transmitted.

  • Page 9: How To Install Your Soho Kvm Switch

    Pre-Configuration Where to Place the SOHO KVM Switch The compact size of the SOHO KVM Switch makes it perfect for desktop placement. Consider the following when deciding where to place the SOHO KVM Switch: the length of the cables attached to your keyboard, mouse, and monitor;...

  • Page 10: Connecting Your Console

    Step 1 Connect the video cable attached to your monitor and connect it to the DVI monitor port on the back of your SOHO KVM Switch. See Fig. 1. Step 2 Connect your keyboard and mouse cables to the keyboard and mouse USB ports on the back of your SOHO KVM Switch.

  • Page 11: Connecting Your Computers

    Make sure all your computers are powered off. Step 2 Using Belkin SOHO KVM Cables (Belkin part number F1D9201-XX), connect one end of the DVI cable to your computer’s DVI monitor port and the other end to the monitor port on the SOHO KVM Switch labeled “PC 1”. See Fig. 2.
  • Page 12 Repeat Steps 1 through 5 for all computers. Once you have connected all your computers, connect the power adapter to your SOHO KVM Switch and power on the Switch. Next, power on your computers. You are now ready to use your SOHO KVM Switch.

  • Page 13: Connecting Usb Devices

    You can connect up to two USB peripheral devices to the built-in USB 2.0 hub on your SOHO KVM Switch. These devices may be connected at any time after the installation procedure. Once a USB device is connected to your SOHO KVM Switch, you will be able to access that device through whichever computer you are currently using.

  • Page 14: Using Your Soho Kvm Switch

    SOHO KVM Switch will appear on your monitor. The number “01” LED on the front of your SOHO KVM Switch will be lit. You can now use that computer as if it were directly connected to your monitor, keyboard, mouse, speakers, microphone, and USB peripheral devices.

  • Page 15: Frequently Asked Questions

    Yes, but only if the USB hub is powered by its own power adapter. What type of DVI monitor can I use? The SOHO KVM Switch will support DVI-D monitors and ADC monitors (using a DVI-to-ADC display adapter). What type of DVI cards will the SOHO KVM Switch support?

  • Page 16: Troubleshooting

    General Problem: My computer does not boot up when connected to the SOHO KVM Switch, but it works fine when I connect the USB keyboard, video, and USB mouse directly to the computer. Solution: • Make sure that the USB cable is properly connected between the SOHO KVM Switch and the computer.
  • Page 17 • Activate USB support on boot up on the BIOS. • Try using a different keyboard. • Try connecting the computer to a different port on the SOHO KVM Switch. • Try connecting the USB cable to a different port on the computer.
  • Page 18 Troubleshooting Mouse Problem: The mouse is lost when I switch to a different port. Solution: • Check that the USB mouse you are using is connected properly to the console of the SOHO KVM Switch. • Disconnect and reconnect the USB cable attached to the channel with which you are experiencing problems to re-synchronize the mouse connection.

  • Page 19: Information

    Belkin Corporation warrants the Belkin product for five years. What will we do to correct problems? Product Warranty. Belkin will repair or replace, at its option, any defective product free of charge (except for shipping charges for the product). What is not covered by this warranty? All above warranties are null and void if the Belkin product is not provided to Belkin Corporation for inspection upon Belkin’s request at the sole expense of the purchaser, or if Belkin Corporation...
  • Page 20 Belkin product to Belkin Corporation for inspection shall be borne solely by the purchaser. If Belkin determines, in its sole discretion, that it is impractical to ship the damaged equipment to Belkin Corporation, Belkin may designate, in its sole discretion, an equipment repair facility to inspect and estimate the cost to repair such equipment.
