LG-Ericsson EARU 1211 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
1211/1212/1311/1312

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EARU 1211 and is the answer not in the manual?

Questions and answers

Related Manuals for LG-Ericsson EARU 1211

Summary of Contents for LG-Ericsson EARU 1211

  • Page 1 1211/1212/1311/1312...
  • Page 2 C O N T E N T S Product and personal safety guidelines Regulatory information About EARU 1211/1212/1311/1312 Checking package contents Installing EARU 1211/1212/1311/1312 Setting EARU 1211/1212/1311/1312 Open Source Software Notice...

  • Page 3: Precautionary Messages

    Precautionary messages To prevent personal injury, equipment damage, and service interruptions, you must follow all precautionary messages in LG-Ericsson documentation and all local safety standards required by your service provider. The following precautionary messages appear in LG-Ericsson documentation:...

  • Page 4: Safety Standards

    Class 1 (IEC)/Class I (FDA) and is therefore considered safe under all reasonably foreseeable conditions. The following text includes additional information on the laser for the EARU 1211/1212/1311/1312 . Laser wavelength 1530 - 1600 nm Maximum laser output power <= 0.299 mW (-5.25 dBm) Standards: IEC 60825-1:2007 Edition 2.0...
  • Page 5 Handling optical fibers When you work with optical fibers, you must take the following general precautions: • Wear safety glasses when you install optical fibers. • Do not look into the opening of an optical fiber, or the opening of an optical fiber connector, if the optical fiber is active or the unit has the power turned on.
  • Page 6 Repairing optical fibers When an accidental break occurs in the optical fiber, do the following: • Report the location of the damaged optical fiber to both the service provider and the field repair personnel. • Power down all laser sources to the optical fiber or disconnect the remote optical fiber end from the laser sources.
  • Page 7 CAUTIONS Warranty: Customers can receive repair services for this product under specified conditions. This warranty does not cover failure or damage of the product caused from, using a power adapter other than the one provided, PC failures, data loss, or negligent treatment of the product.

  • Page 8: Regulatory Information

    Compliance to applicable technical standards and regulations The EARU 1211/1212/1311/1312 meets or exceeds the following standards and requirements: • (CFR Title 47, Chapter 1) FCC Part 15, Subpart B, Class B (USA) • ICES-003, Issue 4, Class B (Canada) •...

  • Page 9: United States Of America

    The user could lose the authority to operate this equipment if an unauthorized change or modification is made. European Union The EARU 1211/1212/1311/1312 conforms with the essential requirements of Directive 2004/108/ EC (EMC Directive), Directive 2006/95/EC (Low Voltage Directive) and Directive 1999/5/EC (Radio and Telecommunications Terminals Equipment) through compliance to the following harmonized standards: •...
  • Page 10 • EN 300 386 V1.4.1 (Class B, other than telecommunications centres criteria) • EN 60950-1:2006 +A11:2009 • IEC/EN 60825-1:2007 • IEC/EN 60825-2:2004+Amd1:2006...

  • Page 11: Australia/New Zealand

    Install and use the equipment according to the instruction manual. Australia / New Zealand The EARU 1211/1212/1311/1312 complies with EN 55022:2006+A1:2007 (Class B) and EN 300 386 V1.4.1 (Class B) in respect of the EMC regulatory arrangements of the...

  • Page 12: Names And Functions Of Each Part

    About EARU 1211/1212/1311/1312 Thank you for selecting EARU 1211/1212/1311/1312. The EARU 1211/1212/1311/1312 is an equipment working as a modem in WDM-PON (Wavelength Division Multiplexing - Passive Optical Network). This product multiplexes 1250Mbps to 1000Mbps Ethernet signals (maximum 4ea) into WDM-PON optical signal.

  • Page 13: Bottom View

    Bottom view EARU 1211 ⑧ ⑦ ⑪ ⑩ EARU 1212 ⑨ ⑥ EARU 1311 EARU1312...
  • Page 14 LEDs and Port functions Number Indicator Usage Color Function Power ON : Power OK and normal status ① Green display Blink : Firmware Downloading Status ON : Alarm event ② display Blink (by turns) : CPU booting ①+② Blink (at once) : Main application loading Combina Green OFF, Red ON : Boot Fail tion...
  • Page 15 Labels ① ③ ② Number item Label Location PEC & SN Label Rear 9.652mm x 27.94mm Hazard level 1 Front (per IEC 60825-2) 9.5mm x 15mm Regulatory Rear 17.04mm x 80.44mm...
  • Page 16 Specifications Item Specification Dimensions in mm 224.4(w) x 230.6(h) x 92(d) Power DC 12V, 1A Ambient Temperature 0℃ to 40℃(@EARU121x), 0℃ to 50℃(@EARU131x) Humidity 20% to 80% EN 300 386 (Class B, other then Telecom Centres) Technical standards FCC part 15 (CFR 47) (Class B) EN 55022 (Class B) / 55024 Data rate 1000Mbps...

  • Page 17: Checking Package Contents

    Before installing this product, ensure all parts are provided. Checking what is in the package Check the package to make sure the following items are included. EARU 1211/1212/1311/1312 Main body User manual Pedestal (for desktop mounting (option)) Wall mounting kit (Option)

  • Page 18: Installation Environments

    Installation environments Install the EARU 1211/1212/1311/1312 in an environment where the following specifications are met. - Operating temperature: 0℃ to 40℃(@EARU121x), 0℃ to 50℃(@EARU131x) - Relative humidity: 20% to 80% - Power consumption: Max 10.29W...

  • Page 19: Installing The Product

    Installing the product Mounting method Only use these two types of mounting methods. Other mounting types will not work properly. Desktop mounting Step1. Insert the lower side projections of the pedestal to the lower side holes of main body. Lower holes Lower projections...
  • Page 20 Step2. Push upper side projections of pedestal toward the upper side holes of main body till they join. Upper projections Upper holes Upper projection...
  • Page 21 SPRIAL PLASTIC PLUGs into the hole. Step 3: Insert the supplied screws through the and screw them into the PLUGs. WALL MOUNTING PANEL Step 4: Hang the on the EARU 1211/1212/1311/1312 BODY WALL MOUNTING PANEL. Item Name Quantity Item Number WALL MOUNTING PANEL...
  • Page 22 Connecting optical cable (@EARU 1211, 1212) Check that the power is off. Insert the SC APC connector into the optical port of the EARU 1211 or 1212 . Insert the other end of the APC optical cable into the optical outlet on your wall.
  • Page 23 Fiber cable Management Route fiber drop cable. Step 1 : Determine the cable entry location. Unfasten 2 screws on the storage cover of EARU and open it. 1211/1212/1311/1312 Cable exit location Step 2 : Cable can only enter the slack storage device from the lower left slot. Route the cable (about 2m) in the slack storage device in a clockwise direction.
  • Page 24 Step 3 : The fiber drop cable must exit the slack storage devicefrom the uper, right or left slot. Step 4 : Leave enough fiber drop cable extending from the slack storage device to allow for a drip loop when connected to EARU unit.
  • Page 25 Connecting Ethernet cable Connect Ethernet cables to the RJ45 Ethernet port numbered 1 to 4 in EARU 1211/1212/1311/1312. Connect the other side of the Ethernet cable to the Ethernet port of your home device.
  • Page 26 Connecting Telephone cable Connect Telephone cables to the RJ11 POTS port numbered 1 to 2 in EARU 1212 or 1312. Connect the other side of the POTS cable to the POTS port of your home telephone. CAUTION All of Ethernet and POTS(Tel Line) cables from EARU should be connected only to in-house and in-building without direct routing to the outside plant.

  • Page 27: Power Connection

    Connect the DC Power Adapter to the Power connection Make sure that both ends of the optical cable and the Ethernet cables are installed. And insert the connector of adapter into the port of the EARU 1211/1212/1311/1312. Make sure that the PWR LED (green) turns on.
  • Page 28 Checking the connection status of service provider line (Link) When the EARU 1211/1212/1311/1312 is first powered on, the STS LED should turn red momentarily. Once communication is established, this LED turns off. The LAN LED should turn green and blink.

  • Page 29: Using Internet

    Using Internet With a web browser such as the Internet Explorer on your PC, you can surf freely through the Internet. Note EARU 1211/1212/1311/1312 does not require any access program. Use your regular internet browser.

  • Page 30: Open Source Software Notice

    LG- Ericsson at : opensource@lgericsson.com This offer is valid for a period of three (3) years from the date of the distribution of this product by LG-Ericsson.  ...
  • Page 31 Copyright © 2010 LG-Ericsson Co., Ltd. All Rights Reserved. Copyright of this manual belongs to LG-Ericsson Co., Ltd. Reproduction, distribution or revision of part or all of contents in this manual in any form without written permission of LG-Ericsson Co., Ltd. is prohibited.

This manual is also suitable for:

Earu 1212Earu 1311Earu 1312
