LaserSpeed LS9000
OPERATOR GUIDE
- for daily operation -
www.betalasermike.com
Manual Part Number: 93296 • Manual Drawing Number: 0921-01419 • English • Revision F • © Copyright Feb 2013

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LaserSpeed LS9000 and is the answer not in the manual?

Questions and answers

Summary of Contents for Beta LaserMike LaserSpeed LS9000

  • Page 1 LaserSpeed LS9000 OPERATOR GUIDE - for daily operation - www.betalasermike.com Manual Part Number: 93296 • Manual Drawing Number: 0921-01419 • English • Revision F • © Copyright Feb 2013...
  • Page 2: Declaration Of Conformity

    LaserSpeed 9000 Operator Guide Declaration of Conformity Declaration of Conformity Part No. 93296 / Drawing No. 0921-01419 Page 2 of 16 Revision F (Feb 2013)
  • Page 3: Table Of Contents

    LaserSpeed 9000 Operator Guide Contents Contents Declaration of Conformity ............... 2 Contents ....................3 Proprietary Statement ................4 European Commission Requirements ............ 5 Safety Information ..................6 Intended Use ......................6 Laser Classification ....................7 Laser Safety Precautions ..................8 Labels and Safety Features .................
  • Page 4: Proprietary Statement

    (stored on-site) and one printout is permitted. If this document is supplied in printed form, no part of this document may be reproduced or scanned without the prior written consent of Beta LaserMike. This document may not be distributed or circulated to third parties.
  • Page 5: European Commission Requirements

    CE marked for the Heavy Industrial environment (EN50082-2). Beta LaserMike also recommends that any cables not supplied by Beta LaserMike, but used for powering Beta LaserMike equipment, be built using good EMC practices (i.e. cables with braided shield, and connectors with 360...
  • Page 6: Safety Information

    LaserSpeed 9000 Operator Guide Safety Information Safety Information  Under NO circumstances should the earth safety connections be broken – internal damage to sensitive electronic components may occur and at worst electrocution to personnel may result.  This equipment must be earthed/grounded. ...
  • Page 7: Laser Classification

    LaserSpeed 9000 Operator Guide Safety Information Laser Classification The Model LS9000 Non-contact Length and Speed Gauge (Model LS9000) is classified as a IIIb laser device. This category contains infrared and visible laser devices with powers up to 500 mW. The optical gauge in the system uses a 50 mW solid-state laser device operating between 760 and 800 nm (near infrared region of the spectrum).
  • Page 8: Laser Safety Precautions

    If your country or state has no regulations governing the safe use of lasers, Beta LaserMike recommends that you follow the guidelines specified by the American National Standard for the safe use of lasers (ANSI Z136.1–1986). For a copy of this document, write to:...
  • Page 9: Labels And Safety Features

    LaserSpeed 9000 Operator Guide Safety Information Labels and Safety Features This section acquaints you with the advisory and identification labels on the instrument and the safety features incorporated into the design of the instrument. The following figures show the advisory and identification labels on the Model LS9000.
  • Page 10 LaserSpeed 9000 Operator Guide Safety Information LS9000E Labels IDENTIFICATION LABEL LASER WARNING LABEL LS9000X Labels IDENTIFICATION LABEL LASER WARNING LABEL Part No. 93296 / Drawing No. 0921-01419 Page 10 of 16 Revision F (Feb 2013)
  • Page 11: Introduction

    LaserSpeed 9000 Operator Guide Introduction Introduction This manual describes the daily routine usage of the LaserSpeed 9000 Gauge. For installation and setup, see the LaserSpeed 9000 Instruction Handbook. ® The Model LS9000 LaserSpeed Non-Contact Length and Speed Gauge is an industrial, laser-based instrument that measures the velocity and length of moving material.
  • Page 12: Lasertrak Software

    LaserSpeed 9000 Operator Guide LaserTrak Software LaserTrak Software ® LaserTrak® is a Windows -based software program, which allows you to acquire and display the Length, Velocity, Quality Factor, and Gauge Status in real time. The LaserTrak software configures the gauge’s operating parameters, displays data, and collects data, which can be stored on a computer hard drive.
  • Page 13 LaserSpeed 9000 Operator Guide LaserTrak Software 3) Check status lights on the gauge. The power light should be on and the Laser on light should be on. This indicates that power has been applied to the gauge and the Interlock is closed so the Laser power can be applied.
  • Page 14: Gauge Alignment

    LaserSpeed 9000 Operator Guide LaserTrak Software Gauge Alignment LaserSpeed gauges have a standoff distance and a depth of field the product needs to stay within in order to make measurements. The last two digits of the model number indicate the standoff distance. For example model LS9000-303, the last two digits are 03 meaning 300 mm (11.8 inches).
  • Page 15 LaserSpeed 9000 Operator Guide LaserTrak Software The Chart Recorder Screen acquires Speed, Length, Quality Factor and Status from the gauge and displays them on a chart recorder screen. Chart Recorder Screen Speed Graph Quality Factor Graph The Quality Factor represents how well the gauge is measuring the product. Quality Factor ranges from 0 to 15, with 15 being the best.
  • Page 16: Servicing And Returning Your Equipment

    Field warranty service is available, if the customer pays travel expenses by advance purchase order. All service operations should be performed by skilled electronics technicians, who have been trained by Beta LaserMike. Part No. 93296 / Drawing No. 0921-01419 Page 16 of 16...
