Nexxt XPY330 User Manual

Integrated wireless ip camera
Hide thumbs

Advertisement

Quick Links

Download this manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the XPY330 and is the answer not in the manual?

Questions and answers

Related Manuals for Nexxt XPY330

Summary of Contents for Nexxt XPY330

  • Page 2 Nexxt Solutions - Integrated Wireless IP Camera with IR Cut-Off Filter Integrated Wireless IP Camera with IR cut-off filter INTRODUCTION Thank you for purchasing the Nexxt Solutions XPY 330 Camera. Featuring an infrared cut-off filter, our new XPY is an integrated wireless IP Camera...

  • Page 3: Before You Begin

    Nexxt Solutions - Integrated Wireless IP Camera with IR Cut-Off Filter BEFORE YOU BEGIN This camera is intended for indoor use only. • Use the supplied power adaptor to connect the • camera to the AC mains (5.0V DC, 1.5A).
  • Page 4 Nexxt Solutions - Integrated Wireless IP Camera with IR Cut-Off Filter FEATURES The camera combines a high-sensitivity 1/4 CMOS • image sensor, an advanced IR cut-off filter with a powerful wireless web server in order to capture lifelike images from anywhere, and to transmit them instantly on your local network or over the internet.

  • Page 5: Package Contents

    Nexxt Solutions - Integrated Wireless IP Camera with IR Cut-Off Filter quick configuration changes via the Settings menu. Compatibility with smartphones enables remote • surveillance and camera control in real-time from any location. Supports image snapshots and image forwarding •...

  • Page 6: Camera Installation

    Nexxt Solutions - Integrated Wireless IP Camera with IR Cut-Off Filter CAMERA INSTALLATION Our WiFi Pan and Tilt Camera can be set up in minutes for instant monitoring and live viewing on your Windows computer and 3G Smartphone - all via your wireless network router or switch.
  • Page 7 Nexxt Solutions - Integrated Wireless IP Camera with IR Cut-Off Filter Step 2: Connect the other end of the network cable to the Ethernet switch, router or IP sharing device. Step 3: Plug the power cable to the wall outlet and turn on the device.
  • Page 8 Nexxt Solutions - Integrated Wireless IP Camera with IR Cut-Off Filter Please note that if you are using the camera on a wireless network, you will need to configure the camera for wired use, prior to configuring wireless settings in the device (later described in this manual).
  • Page 9 Nexxt Solutions - Integrated Wireless IP Camera with IR Cut-Off Filter Introduction The IP camera Super Client is an easy-to-use soft- ware designed for surveillance applications with multiple cameras. This software includes PT con- trols, recording, alarm notifications, in addition...
  • Page 10 Nexxt Solutions - Integrated Wireless IP Camera with IR Cut-Off Filter Adding devices After installing the client software, we need to add the devices. When running the program, the device list on the right of the main interface is empty; there is a guide to show you how to add the devices.
  • Page 11 Nexxt Solutions - Integrated Wireless IP Camera with IR Cut-Off Filter 300-Series Image: 330-Series Image:...
  • Page 12 Nexxt Solutions - Integrated Wireless IP Camera with IR Cut-Off Filter Name: name assigned to the camera, used to distinguish it from other devices connected. This name will be displayed on the camera list. Basic information: the basic information used for connecting the camera, such as connection method, username, password, PT protocol, etc.
  • Page 13 Nexxt Solutions - Integrated Wireless IP Camera with IR Cut-Off Filter Forwarding Server: It provides access to videos by retrieving the files from the server. This requires the setup of server settings. This mode cannot support PT control. Support P2P: Supports P2P technology. This mode cannot support PT Control.
  • Page 14 Nexxt Solutions - Integrated Wireless IP Camera with IR Cut-Off Filter 330-Series Image: This menu is used to quickly set the camera parameters. Not all models have this function. Click the Get button to obtain the current settings. Click Apply or Set depending on the model to save your modifications.
  • Page 15 Nexxt Solutions - Integrated Wireless IP Camera with IR Cut-Off Filter Additional information It is used to enter personal-related information, such as user name, telephone, address, and memo. Introduction to the main window Below is the main window of the client software.
  • Page 16 Nexxt Solutions - Integrated Wireless IP Camera with IR Cut-Off Filter Pan and Tilt feature of the camera. Main Menu: Allows the user to connect or disconnect all the devices, open the history manager, system setup, and other functions. PT Control This feature is available based on the model of the camera.
  • Page 17 Nexxt Solutions - Integrated Wireless IP Camera with IR Cut-Off Filter To set record function, right click the device and Camera/ choose Camera Options or click the   Group Options button. Next, go to Alarm tab. Enable record: when selecting this option, the recording function will be enabled.
  • Page 18 Nexxt Solutions - Integrated Wireless IP Camera with IR Cut-Off Filter Alarm The Client software supports various kinds of alarm triggers, alarm events, and can be used to set an alarm schedule. Select the camera in the display area or from the...
  • Page 19 Nexxt Solutions - Integrated Wireless IP Camera with IR Cut-Off Filter includes the capturing of audio and the video recording time. Schedule trigger: Sets the schedule during which alarm can be triggered. Days: specify the day(s) of the week the alarm will be triggered.
  • Page 20 Nexxt Solutions - Integrated Wireless IP Camera with IR Cut-Off Filter Sound: when an alarm is triggered, the program will play a sound on the computer to frighten the intruder. Sounds can be customized. You can choose the sound from the list in the program.
  • Page 21 Nexxt Solutions - Integrated Wireless IP Camera with IR Cut-Off Filter Email: when the alarm goes off, the program will send an email acknowledgement with the pictures or video recording attached. Attachment: the user can choose to send emails with or without attachments, or with pictures or videos.
  • Page 22 Nexxt Solutions - Integrated Wireless IP Camera with IR Cut-Off Filter FTP Uploading: when the alarm is triggered, the program will upload the snapshots to the FTP server. Upload file: three options are available: picture only, video only, or both picture and video.
  • Page 23 Nexxt Solutions - Integrated Wireless IP Camera with IR Cut-Off Filter Dialing: when the alarm is triggered, the program will dial the assigned telephone number automatically using the PC’s modem. This service requires a modem to be installed on the PC which supports dialing functions.
  • Page 24 Nexxt Solutions - Integrated Wireless IP Camera with IR Cut-Off Filter This service requires an SMS modem to be installed on the PC. SMS modem port: the serial port number which is attributed to the SMS modem. Receiving phone number: the enabled-SMS land line or mobile phone number which will receive the incoming message when the alarm is triggered.
  • Page 25 Nexxt Solutions - Integrated Wireless IP Camera with IR Cut-Off Filter http://www.skype.com. Send Skype Message: this option sends a text “message” to the designated Skype account. Send SMS: this option sends a text “message” to the designated phone. Please note that this feature requires a Skype account balance.
  • Page 26 Nexxt Solutions - Integrated Wireless IP Camera with IR Cut-Off Filter Run once: this option will execute the command only when the alarm goes off for the first time, with no further action after that. URL Link: when the alarm is triggered, the program will open the assigned URL.
  • Page 27 Nexxt Solutions - Integrated Wireless IP Camera with IR Cut-Off Filter When this feature is enabled, the program will always request authentication from users. By default, the admin account enjoys full administra- tor privileges. This account can never be deleted;...
  • Page 28 Nexxt Solutions - Integrated Wireless IP Camera with IR Cut-Off Filter Once you type in the account information and assign the corresponding permissions, click OK to save it. Privileges to add or remove accounts mean that the account operator can include or delete its dependant users.
  • Page 29 Nexxt Solutions - Integrated Wireless IP Camera with IR Cut-Off Filter After selecting the desired device and date, click the Find button. Records publisher Users can remotely view videos and alarm logs using the records publishing tool from the client.
  • Page 30 Nexxt Solutions - Integrated Wireless IP Camera with IR Cut-Off Filter By default, this function is not enabled. You must first select the Enable History Publisher option and click the Apply button to enable this feature. The LAN IP address will be displayed at this point. Users can directly view records in the LAN if the PC has a fixed IP address.
  • Page 31 Nexxt Solutions - Integrated Wireless IP Camera with IR Cut-Off Filter Users can set a password for controlled access permissions. The Web server port is the port provided for remote visit. Normally, this value does not need to be changed, but if that port is being occupied by other devices, users can assign a different port number within the 1 ~ 65535 range.
  • Page 32 Nexxt Solutions - Integrated Wireless IP Camera with IR Cut-Off Filter A list containing all the devices with recorded video files will appear. Next, click on any specific device, and a list of recordings identified with the date will be displayed at this stage.
  • Page 33 Nexxt Solutions - Integrated Wireless IP Camera with IR Cut-Off Filter During playback, the user can rewind or forward the video, take a snapshot or invert the recorded images. The process to remotely access alarm records is the same as with video records.
  • Page 34 Nexxt Solutions - Integrated Wireless IP Camera with IR Cut-Off Filter Wizard mode: this is for first time installation of the IP camera or if the IP camera is not very familiar to the user. This is a step-by-step process for success- fully detecting and installing the IP camera.
  • Page 35 Nexxt Solutions - Integrated Wireless IP Camera with IR Cut-Off Filter If network cable and power supply are correctly connected, the device type, name and IP address will be shown in the device list. (Otherwise, please confirm whether the power supply and network cable are functional).
  • Page 36 Nexxt Solutions - Integrated Wireless IP Camera with IR Cut-Off Filter for the first time, please click Update, so that IP address of the IP camera, gateway and DNS can be synchronous with the PC. 3. If it is necessary to manually modify the contents...
  • Page 37 Nexxt Solutions - Integrated Wireless IP Camera with IR Cut-Off Filter Input the authorized user name and password. The default user name of the camera is admin, and the password is left blank. After successful authentication, the following page will be shown:...
  • Page 38 Nexxt Solutions - Integrated Wireless IP Camera with IR Cut-Off Filter the QuickTime media player interface for FireFox, Safari, and Google web browser. iPod/iPhone/iPad user interface: this mode is designed specifically for Apple mobile devices, such as iPod, iPhone, and iPad. This can only be used for monitoring, because it does not have the capability for setting up the IP camera.
  • Page 39 Nexxt Solutions - Integrated Wireless IP Camera with IR Cut-Off Filter After logging into the device, the monitoring image will be displayed on the left side of the screen. The panel where users can implement the basic parameters to operate the device will be shown on the right side of the frame.
  • Page 40 Nexxt Solutions - Integrated Wireless IP Camera with IR Cut-Off Filter Mode: this value is set according to the frequency of the fluorescent light. If the frequency does not match the frequency of the light, markings will be seen across the screen.

  • Page 41: Ip Camera Settings

    Nexxt Solutions - Integrated Wireless IP Camera with IR Cut-Off Filter IP CAMERA SETTINGS Click the device button located on the right hand   corner of the control panel, to enter into the device interface. Camera Information It displays the device ID, firmware, embedded Web UI version, SD card size, IP address along with other basic information pertaining to the camera.
  • Page 42 Nexxt Solutions - Integrated Wireless IP Camera with IR Cut-Off Filter device uses this time as the naming scheme for the saved recorded files on the PC or SD card. If you synchronize time with the NTP server, please make sure the IP camera’s gateway and DNS server parameter are valid and correct.
  • Page 43 Nexxt Solutions - Integrated Wireless IP Camera with IR Cut-Off Filter Multi-Camera Settings When you access the current IP camera, you can also watch additional devices using the same inter- face. The interface to add other cameras is illus- trated below.
  • Page 44 Nexxt Solutions - Integrated Wireless IP Camera with IR Cut-Off Filter When you finish filling out all the information, click the add button below to save all these configuration values in the camera. Note: multi- camera view is currently supported only by IE.
  • Page 45 Nexxt Solutions - Integrated Wireless IP Camera with IR Cut-Off Filter your settings. Since the camera will restart at this time, the network cable must be unplugged. After rebooting, you can access the camera again using the correct device. PPPoE Settings This is used to set up the Point-to-Point Protocol over Ethernet (PPPoE) parameters.
  • Page 46 Nexxt Solutions - Integrated Wireless IP Camera with IR Cut-Off Filter means of dial-up Internet for instance, you can use the camera’s own DDNS. The IP camera supports two DDNS methods, one is provided by the factory, while the second one is generated by a third party’s DDNS system, like DynDns.
  • Page 47 Nexxt Solutions - Integrated Wireless IP Camera with IR Cut-Off Filter When users check “show date timestamp on video”, a timestamp will be added in the bottom right corner of recorded footage. Mail Service Settings The mail service is mainly used to send email notifications in case an alarm is triggered.
  • Page 48 Nexxt Solutions - Integrated Wireless IP Camera with IR Cut-Off Filter FTP Service Settings The FTP server is mainly used for uploading live pictures in case an alarm is triggered. FTP server: the address of the FTP server. FTP port: the port used for the FTP server. Usually, this is set to 21.
  • Page 49 Nexxt Solutions - Integrated Wireless IP Camera with IR Cut-Off Filter Alarm Service Settings This is used to set the alarm functions on the camera. The XP 330 supports motion detection and external alarm inputs. Motion detection means that the IP camera will sense movement and immediately it will trigger an alarm to alert about such an event.
  • Page 50 Nexxt Solutions - Integrated Wireless IP Camera with IR Cut-Off Filter up on a weekly basis, within a 24 hour-time frame. By selecting the scheduler you will be enabling the alarm. SD Card Record This is used to set certain parameters of the SD card recording.
  • Page 51 Nexxt Solutions - Integrated Wireless IP Camera with IR Cut-Off Filter PT settings This is used to set the pan and tilt parameters and the signaling lamp. When this light is enabled, the green LED of camera’s head will flash.

  • Page 52: Mobile Access

    Nexxt Solutions - Integrated Wireless IP Camera with IR Cut-Off Filter MOBILE ACCESS To begin with, the mobile phone you must have internet access and be connected to the wireless LAN if attempting to login internally. If attempting to access externally, you must ensure to type in the...
  • Page 53 Nexxt Solutions - Integrated Wireless IP Camera with IR Cut-Off Filter Next, taking the Opera mini 4 Version on Windows Mobile as an example, we are going to present the whole procedure. 1. Enter access address http://demo.ipcam.so in the browser address bar; the following interface will appear: 2.

  • Page 54: Miscellaneous Settings

    Nexxt Solutions - Integrated Wireless IP Camera with IR Cut-Off Filter Monitoring page description: Function of monitoring page keys: Update: it is used to refresh the page. If the monitor picture freezes, you may press this key to update the contents of the page.
  • Page 55 Nexxt Solutions - Integrated Wireless IP Camera with IR Cut-Off Filter port forwarding setup for illustration (we recom- mend to use our Nexxt Solutions routers for best results). For illustrative purposes, the router’s default access address is 192.168.0.1, the IP camera’s access address is 192.168.0.100, and the default access...
  • Page 56 Nexxt Solutions - Integrated Wireless IP Camera with IR Cut-Off Filter 4. Under Service Port and Internal Port field, input the incoming port for the IP camera (in this example, it will be 81). In the IP Address field, type the camera’s IP address (in this example, it will be...
  • Page 57 Nexxt Solutions - Integrated Wireless IP Camera with IR Cut-Off Filter Common router default access addresses: Nexxt Solutions router’s default access address is 192.168.0.1 DLINK router’s default access address is 192.168.0.1 Linksys router’s default access address is 192.168.1.1 3com router’s default access address is 192.168.2.1...
  • Page 58 Nexxt Solutions - Integrated Wireless IP Camera with IR Cut-Off Filter 3. If a firewall is installed in your network or computer, ensure this is not blocking inbound connections to the camera and/or port. Question: Does the 330 series allow users to browse dynamic video through a mobile phone? Answer: Yes, it does.

  • Page 59: Specifications

    Nexxt Solutions - Integrated Wireless IP Camera with IR Cut-Off Filter SPECIFICATIONS Model AILPT324U5 Specifications 1/4 color CMOS Image sensor 4 mm Lens 10 pcs Infrared LED 300,000 Pixels infrared cut-off filter (ICR) to ensure lifelike daytime color and sensitive...
  • Page 60 This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

This manual is also suitable for:

Ailpt324u5
