SMC Networks EZ Networking SMC2208USB/ETH Specifications page 2

TECHNICAL SPECIFICATIONS
INTERFACES
• Complies with USB specification v1.0 and v1.1
• One 4-pin A-type USB connector
• One RJ-45 connector for Ethernet network interface
STANDARDS
• USB Specification 1.0 and 1.1
• IEEE 802.3 Ethernet
• IEEE 802.3u Fast Ethernet
ACCESS METHOD
• USB Port: USB spec.1.0 and 1.1
• RJ-45 Port: IEEE 802.3 and 802.3u CSMA/CD
• 10 and 100 Mbps full and half duplex
POWER CONSUMPTION
• 10Mbps mode: Max 143mA @5V
• 100Mbps mode: Max 150mA @5V
LED INDICATION
• 10/100: ON in 100 Mbps mode, OFF in 10 Mbps mode.
• F/H: ON in full duplex mode, OFF otherwise.
• ACTIVE: ON when 10 or 100Mbps Ethernet traffic is Active
DRIVERS SUPPORT
• Windows XP
• Linux kernel v2.4 or later versions
• Mac 9.X
• Mac 10.1
• Mac 10.2
COMPLIANCES
• FCC part 15 class B
• CE(CISPR22 class B)
ENVIRONMENT
• Operating Temperature: 0 ~ 55
• Humidity: 10 ~ 90%
• Storage Temperature -20 ~ 65
• Humidity 10 ~ 90%
www.smc.com
SMC2208USB/ETH
O
C
O C
WARRANTY
• Limited Lifetime
DIMENSIONS
• 74.5 x 28.1 x 15.1 mm
• 2.9 x 1.1 x 0.59 in
WEIGHT
• 7.1 g
• .25oz
Contact
North America
20 Mason
Irvine, CA 92618
1-800-SMC-4YOU
24/7 Technical Support
Europe/ Africa
Fructuos Gelabert 6-8
08970 Sant Joan Despí
Barcelona, Spain
Check www.smc.com for your local
country contact information
