Contact Digga Australia for enquiries. For any spare or replacement parts, contact Digga Service and Spares or a local Digga representative. For identification purposes always try to have available the auger drive unit type and serial number. This information may be necessary for verification of any component part numbers. Component part numbers and/or manufacturing gear set numbers may be stamped on individual parts.
BEFORE DISASSEMBLY In the PDD-PD12 series, there is one single primary planetary gear set. In the PD15-PD22 series there is a primary and a secondary stack planetary gear set using a common ring gear. In the PD25 – PD50 series there are primary and secondary individual gear sets. UNIT DISASSEMBLY PROCEDURE All parts should be inspected as they are removed from unit.
OUTPUT SHAFT SUBASSEMBLY REFER TO APPROPIATE EXPLODED VIEW DRAWING PDD – PD5 PD25 - PD50 1. Inspect inner and outer bearing cups and cones. If either is damaged, the complete bearing assembly will need replacing. 2. Remove inner and outer bearing races from output housing with the appropriate tool. 3.
PRIMARY PLANETARY SUBASSEMBLY Rotate planet gear to check for any abnormal noises or roughness in the primary planet bearings. At the same time, inspect planet gears for any damage or worn teeth. If replacement or further inspection is required, proceed as follows. For PD15 - PD22 lift top gear set from bottom set then proceed as follows.
PRIMARY AND SECONDARY PLANETARY COMBINATION SUBASSEMBLY SUIT PD15 - PD22 ONLY PRE APRIL 2011 SECONDARY PLANETARY SUBASSEMBLY SUIT PD25-50 SUIT PD15-22 POST APRIL 2011...
UNIT REASSEMBLY Start with output housing assembly. Turn case upside down and position on table. Bottom seal end should be facing upward and install bearing cup with appropriate tooling. Install bottom seal applying a smear of Loctite 243 thread locker to outside of seal and fit using appropriate tooling. Ensure seal is flush with the housing.
Page 9
14. *Fit primary gear set as from step # 11. NOTE: THE DRIVE UNIT CAN BE FILLED WITH GEAR OIL NOW OR AFTER FULLY ASSEMBLED. IF FULLY ASSEMBLED THE OIL WILL HAVE TO BE POURED THROUGH THE BUNG IN THE OUTPUT HOUSING. OIL QUANTITY IS ON PAGE 2. 15.
Page 32
PD15/ PD18/ PD22 PARTS LIST (PRE APRIL 2011) ITEM PART NUMBER DESCRIPTION BE-000025 BEARING TAPERED ROLLER FA-000115 SCREW SOCKET HEAD CAP FA-000225 BOLT HEX FA-000446 SCREW SOCKET HEAD CAP GB-000535 SEAL PROTECTOR GB-000542 KEY - LOCK GB-000567 SHAFT GB-001491 SHAFT GB-002145 SHAFT GB-001699...
Page 33
DESCRIPTION DE-000088 DECAL NEW GENERATION (CAUTION) DE-000089 DECAL NEW GENERATION (WARNING) DE-000091 DECAL NEW GENERATION (DIGGA PD) - 75MM DE-000099 DECAL NEW GENERATION (1) - 35MM DE-000100 DECAL NEW GENERATION (2) - 35MM DE-000103 DECAL NEW GENERATION (5) - 35MM...
PD15/ PD18/ PD22 (POST APRIL 2011) PM-000100-D PDD - PD50 Service and Repair Manual - October 2017...
Page 35
PD15/ PD18/ PD22 PARTS LIST (POST APRIL 2011) Parts List ITEM PART NUMBER DESCRIPTION BE-000025 BEARING TAPERED ROLLER E32020J FA-000024 BOLT HEX M8 x 30 G8.8 ZINC PLATED FA-000132 SCREW SOCKET HEAD CAP M10 X 90 ZINC PLATED FA-000610 SCREW SOCKET HEAD CAP M12 x 90 G12.9 GB-000535 SEAL PROTECTOR - S6/8 - SUIT 120x150x12 SEAL GB-000542...
Page 36
DESCRIPTION DE-000088 DECAL NEW GENERATION (CAUTION) DE-000089 DECAL NEW GENERATION (WARNING) DE-000091 DECAL NEW GENERATION (DIGGA PD) - 75MM DE-000099 DECAL NEW GENERATION (1) - 35MM DE-000100 DECAL NEW GENERATION (2) - 35MM DE-000103 DECAL NEW GENERATION (5) - 35MM...
Page 38
PD25 / PD30 / PD40 / PD50 PARTS LIST ITEM PART NUMBER DESCRIPTION BE-000023 BEARING BE-000029 BEARING TAPERED ROLLER FA-000001 BOLT HEX FA-000144 SCREW SOCKET HEAD CAP FA-000115 SCREW SOCKET HEAD CAP FA-000184 BOLT HEX GB-000008 RING GEAR - S4 - ALL RATIOS GB-000539 RING GEAR - S8 GB-000555...
Page 39
DESCRIPTION DE-000088 DECAL NEW GENERATION (CAUTION) DE-000089 DECAL NEW GENERATION (WARNING) DE-000092 DECAL NEW GENERATION (DIGGA PD) - 105MM DE-000111 DECAL NEW GENERATION (2) - 60MM DE-000112 DECAL NEW GENERATION (3) - 60MM DE-000113 DECAL NEW GENERATION (4) - 60MM...
• Replace all missing, illegible, or damaged safety signs. • Replacement parts for parts with safety signs attached must also have safety signs attached. • Safety signs are available from your dealer or from ITEM 3 Digga Australia. ITEM 2 ITEM 1 ITEM 5 DE-000099...
Page 41
• Replace all missing, illegible, or damaged safety signs. • Replacement parts for parts with safety signs attached must also have safety signs attached. • Safety signs are available from your dealer or from ITEM 3 Digga Australia. ITEM 2 ITEM 1 ITEM 5 DE-000099...
Page 42
• Replace all missing, illegible, or damaged safety signs. • Replacement parts for parts with safety signs attached must also have safety signs attached. • Safety signs are available from your dealer or from ITEM 3 Digga Australia. ITEM 2 ITEM 1 ITEM 5 DE-000110...
SWING CONTROL SYSTEM DESCRIPTION: The SCS consists of 3 cylinders. 1 X Aft dampener or main cylinder and 2 X interconnecting Hood cylinders. These cylinders are grease filled and are not pressurised. They can be topped up with grease whenever required. GREASE TYPE: VALVOLINE C-00-EP ( Semi Fluid Grease ) or equivalent.
Ensure the drive is tilted 60º when filling. NOTE PREMIUM DRIVE UNIT RANGE (PDD-PD50 DRIVE UNITS) Use quality extreme pressure gear oil (EPG ISO 320 GRADE - MINERAL OIL) PM-000100-D PDD - PD50 Service and Repair Manual - October 2017...
CHANGING THE SHAFT SEAL 4. Push locking tabs down 1. Remove hood bolts 2. Remove motor bolts 3. Remove gear set & & remove hood & remove motor ring gear using a screwdriver 7. Tap out bearing and 5. Remove lock nut using a 6.
Page 46
CHANGING THE SHAFT SEAL 12. Place a flat metal sheet 9. Now that the shaft 10. Run some Loctite 11. Place the shaft seal seal has been removed, 263 (Red) around the in it’s position ensuring on top of the seal and tap with a hammer so that the return the bearing to outside of the shaft seal...
Page 47
CHANGING THE SHAFT SEAL 17. Screw the nut in place (flat 18. Lock the nut by 19. Replace the gear set 20. Replace the ring gear. side up) using a chisel and bending the previously Use a screw to help guide hammer ensuring the recess used tabs into the nut’s it into place.
INSTALLATION OF HOOD CYLINDERS Place interconnecting tube in hood, screw hood cylinders on to tube, finger tight only, place both cylinders into hood and align bolt holes. Gently lift both cylinders back out of hood and tighten tube nuts ensuring cylinders stay in same position on tube for bolt hole alignment. Place cylinders back in hood, fit and tighten retaining bolts.
INSTALLATON OF AFT DAMPENER: Smear grease on all Aft Dampener retaining pins prior to installing. A new Aft Dampener does not need charging with grease, it comes from the factory ready to use. If reusing an Aft Dampener that requires recharging it must be done before installing back in frame. Remove grease gun and grease nipple. Installation is the reversal of removal procedure.
CONTACT INFORMATION For further information on spare parts please contact one of the Digga sales office below your closest authorised Digga Dealer. DIGGA INTERNATIONAL SALES OFFICES ASIA PACIFIC NORTH AMERICA EUROPE DIGGA HEAD OFFICE - QUEENSLAND DIGGA NORTH AMERICA DIGGA EUROPE...
Page 69
Australian Designed and Manufactured PM-000100-D...
