Summary of Contents for Smarthome 7307
- Page 1 SMARTHOME.COM™ 1-800-SMART-HOME 949-221-9200 http://www.smarthome.com Order #7307 Total Protection Alarm System SMARTHOME™ #7307 PAT. D410633 Patents Pending...
-
Page 2: Table Of Contents
SMARTHOME.COM™ 1-800-SMART-HOME 949-221-9200 http://www.smarthome.com Order #7307 Your Guide to the Total Protection Alarm System SMARTHOME™ #7307 – – TABLE OF CONTENTS PACKAGE CONTENTS...4 OVERVIEW...5 PLANNING YOUR HOME SECURITY NEEDS... 6 INSTALLATION -Control Panel... 7 -Door/Window Sensor... 8 -Motion Sensor... 9 TESTING YOUR SYSTEM... -
Page 3: Package Contents
SMARTHOME.COM™ 1-800-SMART-HOME 949-221-9200 http://www.smarthome.com Order #7307 PACKAGE CONTENTS Everything required for installation is included with this package 1 Control Panel (SC-001) includes: 1 antenna (installed) 1 AC adapter 1 9 volt alkaline battery Two sets of Door/Window Sensors (WT-433), each set includes:... -
Page 4: Planning Your Home Security Needs
SMARTHOME.COM™ 1-800-SMART-HOME 949-221-9200 http://www.smarthome.com Order #7307 PLANNING YOUR HOME SECURITY NEEDS Before you begin to install your security system, analyze the premises to determine your security needs. Consider those doors and windows which are more likely to be used as points of entry by an intruder, the ones that are poorly lit or the entrances that can not be seen from the street. - Page 5 SMARTHOME.COM™ 1-800-SMART-HOME 949-221-9200 http://www.smarthome.com Order #7307 INSTALLATION 4. Attach the unit to the wall. If hanging the unit, insert two screws using the template provided. If screwing the back directly to the wall, take the back plate right off by prying apart one hinge.
-
Page 6: Testing Your System
SMARTHOME.COM™ 1-800-SMART-HOME 949-221-9200 http://www.smarthome.com Order #7307 INSTALLATION (Cont. : Installing the motion sensor (PS-433) Set the switch on the side to "TEST" and allow 60 seconds for the unit to warm up. ( when using test mode, a signal will not be sent to the Control Panel ). -
Page 7: Lights And Sounds
SMARTHOME.COM™ 1-800-SMART-HOME 949-221-9200 http://www.smarthome.com Order #7307 LIGHTS AND SOUNDS Below is an explanation of the lights and sounds of the Control Panel. LIGHTS ACPWR light on System is being powered by electrical current. ACPWR light off System is not receiving any electrical power. -
Page 8: Transmitter
SMARTHOME.COM™ 1-800-SMART-HOME 949-221-9200 http://www.smarthome.com Order #7307 STANDARD PROGRAMMING Option 2: Home Sequence - To arm your system when someone remains in the premises. 1. Press the current MPIN [ 0 0 0 ]. 2. Press [ C ]. You hear a long beep. The arm light and the red lights in zones 3 and 4 go on. Both the green and red lights flash in zone 1 for 45 seconds which gives you 45 seconds to leave the premises before the system is activated. -
Page 9: Passwords Master Personal Identification Number (Mpin)
SMARTHOME.COM™ 1-800-SMART-HOME 949-221-9200 http://www.smarthome.com Order #7307 KEYCHAIN TRANSMITTER (4B-434) TO DISARM THE SYSTEM, OR DEACTIVATE THE SIREN USING THE KEYCHAIN TRANSMITTER When the system is armed: Press button #3. The red light on the transmitter flashes and the Control Panel beeps twice. -
Page 10: Secondary Personal Identification Number (Spin)
SMARTHOME.COM™ 1-800-SMART-HOME 949-221-9200 http://www.smarthome.com Order #7307 PASSWORDS SECONDARY PERSONAL IDENTIFICATION NUMBER (SPIN) You may want to give someone limited access to the system, (baby sitter, cleaner, repairman etc.). For this purpose the SC-100 provides you with the option of adding up to 3 separate SPIN. -
Page 11: To Clear A Zone
SMARTHOME.COM™ 1-800-SMART-HOME 949-221-9200 http://www.smarthome.com Order #7307 ADVANCED PROGRAMMING To program sensors to send their signals to a different zone, you must first clear them from communicating with their current zone. TO CLEAR A ZONE 1. Enter the current MPIN. 2. Press [ B ]. -
Page 12: Standard Arming Sequences
SMARTHOME.COM™ 1-800-SMART-HOME 949-221-9200 http://www.smarthome.com Order #7307 ADVANCED PROGRAMMING STANDARD ARMING SEQUENCES Each zone can be programmed to react 5 different ways when it receives a signal from a remote sensor. 1. Chime Mode - represented by the green lights When only the green light is on and the Control Panel receives a signal from a remote sensor, the Control Panel emits a subtly two tone chime. -
Page 13: Customize A Sequence
SMARTHOME.COM™ 1-800-SMART-HOME 949-221-9200 http://www.smarthome.com Order #7307 ADVANCED PROGRAMMING TO CUSTOMIZE A SEQUENCE: Program the system to the sequence you want to alter. 1. Enter the current MPIN. 2. Press [ B ]. 3. Press a number key to select the zone you would like to change, [ 1, 2, 3 or 4 ]. -
Page 14: Battery Maintenance
SMARTHOME.COM™ 1-800-SMART-HOME 949-221-9200 http://www.smarthome.com Order #7307 BATTERY MAINTENANCE The SC-100 Security System comes with 5 batteries that at some point you may have to replace: 9 volt alkaline battery for the Control Panel 9 volt alkaline battery for the Motion Sensor... -
Page 15: Keychain Transmitter
SMARTHOME.COM™ 1-800-SMART-HOME 949-221-9200 http://www.smarthome.com Order #7307 BATTERY MAINTENANCE KEYCHAIN TRANSMITTER BATTERY The Keychain Transmitter operates on a 12 volt alkaline battery which is installed at the factory. There are two screws on the back of the transmitter that holds the case together.
