RETRACTABLE
EXTERIOR BLIND
A SSE MB LY G UID E
Installing your new Coolaroo Exterior Blind is simple,
following our step-by-step instructions.
Parts list
Description
a. Exterior blind
b. Left and right
headrail brackets
c. Base rail screws
d. Base rail arms
e. Screws
f. Anchors
The Exterior Blind can be installed:
• to the wall face
• to the side of a reveal or
• from the under side of the window eave
or structure.
Qty
1
2
2
2
8
8
You will also need:
• Power drill with 3mm bit
• Phillips head screwdriver
• Pencil or felt tip marker
• Pliers
Advertisement
Related Manuals for Coolaroo Exterior Blind
Summary of Contents for Coolaroo Exterior Blind
- Page 1 RETRACTABLE EXTERIOR BLIND A SSE MB LY G UID E Installing your new Coolaroo Exterior Blind is simple, following our step-by-step instructions. Parts list Description You will also need: a. Exterior blind • Power drill with 3mm bit b. Left and right •...
- Page 2 IMPORTANT: DO NOT REMOVE THE PIN UNTIL BLIND IS ASSEMBLED IN BRACKETS (STEP 7). Your Exterior Blind comes pre-tensioned but can be re-tensioned if required (STEP 8). *Please note for the longer blinds it is advisable to have two people to install.
- Page 3 STEP 6 STEP 8-3 Mount the Exterior Blind in the mounting brackets, Take the blind out of positioning the RIGHT end first. The Flat Pin (Left) the brackets and repeat must be installed vertically. steps 8-1 and 8-2 until you have the desired tension.
- Page 4 If this is a problem, try reducing the tension slightly. Correct tension should have the Exterior Blind retracting all the way to the top and with enough tension left to snugly hold the base rail against the top roll of fabric.
