- Page 1 INSTALLATION INSTRUCTIONS INSTALLER: EXTERIOR DECORATIVE FRONT Leave this manual with the appliance. CONSUMER: DFEV60LSS-1 FOR USE ON VFLB60SP90(N,P)-1 Retain this manual for future reference.
-
Page 2: Carton Contents
CARTON CONTENTS Items not shown to scale. INDEX NUMBER DESCRIPTION QUANTITy SUPPLIED REPLACEMENT PART NUMBERS Inner Glass and Frame 40313 Top Mount Bracket 40266 Side Mount Bracket 40265 Bottom Mount Bracket 40267 Screen Assembly 40314 Outer Glass and Frame 40315 Outer Glass R12431 Silicone Gasket... -
Page 3: Hardware Pack
HARDWARE PACK HARDWARE PACK CONTENTS #10 X ½” HEX HEAD SCREW #10 X ½" HEX HEAD SCREW #10 X ½” HEX HEAD SCREW #10 X 1" HEX HEAD SCREW DESCRIPTION QUANTITy SUPPLIED #10 X 1” HEX HEAD SCREW 10 X 1/2 Phillips Hex Head Screw 10 X 1 Phillips Hex Head Screw... - Page 4 INTRODUCTION BEFORE BEGINNING INSTRUCTIONS TO INSTALLER Leave instruction manual with owner after installation. This stainless steel exterior decorative front is designed to be 2. Have owner register online or fill out and mail Product installed on an exterior wall of your residence. The fireplace Registration Card supplied with unvented fireplace. flame will be visible on a porch or area outside of the residence. This decorative front is for installation on an exterior wall only. The other side will be inside the residence. Glass panels will close off the exterior side of the fireplace and will act like an Consult the local Building Department regarding regulations, exterior window. The heat from the fireplace will be projected...
-
Page 5: Fireplace Preparation
FIREPLACE PREPARATION NOTICE: The exterior decorative front must be attached to the Locate bottom mount bracket shown in Figure 3 and attach fireplace before the unit has been installed into the framing. with four provided #10 x 1/2 inch screws as shown. PREPARING THE FIREPLACE The exterior decorative front slides onto the top and sides of the linear fireplace. - Page 6 FIREPLACE PREPARATION (CONT'D) Using four provided #10 x 1 inch screws, attach the bottom of CAUTION the inner glass-frame to the fireplace as shown in Figure 7. Do not put pressure on glass inside the frame. Glass is loose until secured after the installation. Locate the inner glass-frame. With the bottom of the inner glass-frame angled out towards the installer, hook the flange of the inner glass-frame onto the top mount bracket.
- Page 7 FIREPLACE PREPARATION (CONT'D) 11. Secure the outer glass and frame to the top of the fireplace 13. Repeat for other side. using four provided #10 x ½ inch screws. See Figure 9. 14. When installed on an exterior wall, the following supplied component is not required: • One Screen Frame Assembly This assembly can be discarded. The screen frame assembly is required on the side of the fireplace inside the residence.
- Page 8 FINISHING EXTERIOR DECORATIVE FRONT NOTICE: The fireplace must be protected during finishing. Do not 3b. Exterior non-combustible finishing material is placed over the face of the outdoor kit. See Figure 14. allow acid wash to get onto the fireplace. The stainless may be covered in full or in part by a non-combustible stone, tile or other finishing material. It is recommended that the outer perimeter face of the outdoor kit be covered with non-combustible finishing material.
- Page 9 MAINTENANCE - GLASS CLEANING GLASS CLEANING Clean the glass before use and as needed. During start-up condensation (which is normal) forms on the inside of the glass and causes lint, dust and other airborne particles to cling to the glass surface. Also initial paint curing may deposit a slight film on the glass.
- Page 10 This page intentionally left blank. Page 10 40245-0-0219...
- Page 11 This page intentionally left blank. 40245-0-0219 Page 11...
- Page 12 Empire Comfort Systems Inc. Belleville, IL If you have a general question about our products, please e-mail us at info@empirecomfort.com. If you have a service or repair question, please contact your dealer. www.empirecomfort.com 37831-0-0517...
