Front Panel

1
Controls
1 Loudspeaker selectors 1 through 8 – Press the button in to listen
to the desired loudspeakers.
Loudspeaker ON
Loudspeaker OFF

Rear Panel

3
3 Connection from amplifier – from the L(left) and R(right)
loudspeaker output of your receiver or amplifier (100 watts
MAX)

Typical Hook Up

The diagram below shows an overview of a typical system using 8 loudspeaker pairs.
Overview of typical system
Connect to receiver/amplifier R/L
Amplifier loudspeaker output
+
+
Installation Tips
18 or 16 gauge stranded loudspeaker wire is recommended. 14 gauge is recommended for runs longer than 50 feet.
You can mix any combination of 4, 6, 8 and 16 ohm loudspeakers
Wire according to local laws. Specific "CL" fire rating may be required according to your local building codes. Your dealer may know
more about obtaining such wire.
Avoid running close to AC power wiring for safety and to avoid the possibility of picking up any noise.
2
2 Single Pair Direct Switch – Impedance protection switch for the
amplifier/receiver. Use as directed in this owners manual.
Single Pair Single Pair
OFF Engaged
4
4 Loudpeaker Connections – connections to be made from the
QLS8.1 to the desired loudspeakers, with the corresponding
selector on the front panel.
