Mini
Rad-D
Product Guide
Mini Rad-D
Detector
1.3 cm diam x 3.8 cm Cesium Iodide -
CsI (Na) Scintillation detector with
high-sensitivity photo-multiplier tube
Display
Intense, large LED display
Power
Two AA batteries
Battery Life
5,000 hours
Alarm
Audio, vibrate, visual
Response Time
< 1 second
Background
Automatic
Compensation
Energy Range
50 Kev to 3 Mev
Dimensions
3.7 x 2.5 x 1.2 in (94 x 64 x 30.5 mm)
Weight
6.5 oz (184 gr)
Environment
Driving Rain, operates in high RF
environment
Temperature
10° to 122° F (-20° to 50° C)
Humidity
93% RH non-condensing at 95° F (35°
C)
Drop Test
No Holster – 5 ft (1.5 m) drop onto a
concrete floor
Warranty
2 year parts and labor
Figure 1
Alarm Level Equivalents
Alarm Level
mRem/Hr
1
2
3
4
5
6
7
8
9
uSv/Hr
0.035
0.35
0.04
0.40
0.055
0.55
0.065
0.65
0.1
1.00
0.2
3.00
0.35
3.50
0.6
6.00
1.1
10.10
Advertisement
Related Manuals for D-tect Systems Mini Rad-D
Summary of Contents for D-tect Systems Mini Rad-D
- Page 1 Mini Rad-D Detector 1.3 cm diam x 3.8 cm Cesium Iodide - CsI (Na) Scintillation detector with high-sensitivity photo-multiplier tube Display Intense, large LED display Power Two AA batteries Battery Life...
- Page 2 If the Mini Rad-D stops detecting normal background radiation levels for a period of time (such as incorporating key improvements around product reliability and ruggedness in harsh if it is taken into a concrete building), the mini rad-D will recalibrate itself. The device will beep and environments. These improvements include: the LED will show a “racetrack”...
- Page 3 Limited or Extended Warranty, these services will be billed to notice of the claim; and (b) that D-tect Systems will have sole control of the defense of the the customer at D-tect Systems’ standard prices and terms.
- Page 4 D-tect Systems will have no liability to you with respect to any claim of patent infringement which is based upon the combination of the Products or parts furnished under this limited warranty with software, apparatus or devices not furnished by D-tect Systems. D-tect Systems will have no liability for the use of ancillary or peripheral equipment or software not furnished by D-tect Systems which is attached to or used in connection with the Products.
