BATTING CAGE - 50' Long
BATTING CAGE - 70' Long
Upon completion of the assembly/installation of this kit, make sure this
instruction sheet is in the possession of the owner or facility manager, to
save for future reference, and to order replacement parts.
INST00333078
2017 PORTER ATHLETIC, INC. ALL RIGHTS RESERVED.
6-13-2017
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Porter 330150
Summary of Contents for Porter 330150
- Page 1 Upon completion of the assembly/installation of this kit, make sure this instruction sheet is in the possession of the owner or facility manager, to save for future reference, and to order replacement parts. INST00333078 2017 PORTER ATHLETIC, INC. ALL RIGHTS RESERVED. 6-13-2017...
- Page 2 FAILURE TO COMPLY WITH THE FOLLOWING INSTRUCTIONS, CAUTIONS AND WARNINGS MAY RESULT IN SERIOUS INJURIES AND/OR PROPERTY DAMAGE. THE No. 330150 AND 330170 BATTING CAGES ARE DESIGNED TO PROVIDE LIMITED PROTECTION FOR SPECTATORS. HOWEVER, STRICT SAFETY PRECAUTIONS AND ADULT SUPERVISION MUST BE OBSERVED AT ALL TIMES TO MINIMIZE THE POSSIBILITY OF ACCIDENTAL INJURIES.
- Page 3 1. Check all parts against Parts List on Page 2 to make sure all have been included. Detail "A" 2. Begin by assembling uprights. At top end, insert eye-bolt (6) into hole thru upright (1). Secure with 5/16" locknut (7). Note - the eye must be in the horizontal position. Tighten the locknut after rotating the eye-bolt.
- Page 4 7. Raise the assembled batting cage uprights into position in their holes, according to Detail "C" the dimensions shown in Detail “D”. The four corner uprights are positioned at a 45 angle, with the rope cleats and pulleys pointed toward the batting cage. All COMPLETED INSTALLATION (SHOWN IN CONCRETE FOOTING) intermediate upright assemblies are rotated square with the cage, pointing toward...
- Page 5 Porter Athletic, Inc. 601 Mercury Drive, Champaign, IL U.S.A., 61820 Toll Free: (888) 277-7778 Phone: (217) 367-8438 Fax: (217) 239-2255 www.porterathletic.com SAVE THESE INSTRUCTIONS FOR FUTURE USE...
