Predator Radar Installation Manual V2.1.18.1
Please make sure there is adequate spare cable for when the camera is resting on the lanyard, failure to do this
could damage the connector circuit board.
Power Connections
Connect 24Vdc to CON5.
DO NOT APPLY AC VOLTAGE TO THE PREDATOR
Ethernet Connections
Connect Ethernet cable to Predator Radar connection
board using a RJ45 connector (CON4).
© 360 Vision Technology Ltd.
RADAR.
Page 8
