4 Connections to Predators with HMA

When the HMA (Hinged Mount Adaptor) is fitted to the Predator, the 'Predator Composite Cable' is not used.
Connections between the power supply and Predator use conventional cables as detailed below.
24Vac Power connections between Predator PSU and Predator that is fitted with HMA
Ethernet connections between Predator PSU and Predator that is fitted with HMA.
The Ethernet connection uses standard CAT5, CAT5e or CAT6 cables fitted with RJ45 connectors.
Gain access to connectors in the HMA
• Ensure that the fixed part of the HMA is securely bolted to the top of the pole.
• The hinged part of the HMA (Hinged Mount Adapter) is fastened to the fixed part using three M8x25
long hex head bolts. Use a spanner (13mm) to remove the three bolts. Each bolt is fitted with a
split spring lock washer, a plain metal washer (which prevents the split washer from damaging the
fibre washer) and a fibre washer (which prevents the paint on the hinged part from being damaged
unnecessarily.
• Open the hinge taking care that the gasket is not damaged and support the weight of the Predator.
Gently open the HMA until the lanyard is able to take the weight. If the lanyard appears to support the
weight of the Predator, there is no need to continue to support the Predator. The connection circuit
board (PCB-000-0222-01) can now be seen.
Cable Size
0.75mm²
1.00mm²
1.25mm²
1.50mm²
2.50mm²
3.00mm²
4.00mm²
RJ45 CAT5, CAT5e, CAT6 Cable
Pin 1 White with Orange Band
Pin 2
Pin 3 White with Green Band
Pin 4
Pin 5 White with Blue Band
Pin 6
Pin 7 White with Brown Band
Pin 8
© 360 Vision Technology Ltd.
No IR IR75
20m 10m
25m 12.5m
30m 15m
40m 20m
65m 30m
80m 40m
100m 50m
Orange
Blue
Green
Brown
IR100WL IR125
7.5m 7.5m
10m 10m
12.5m 12.5m
15m 15m
25m 25m
30m 30m
40m 40m
Signal
Tx+
Tx-
Rx+
Rx-
