EA08A/RS
Generator Automatic Voltage Regulator
Operation Manual
Self Excited Automatic Voltage Regulator for use in Brushless, Full
Harmonic or Harmonic and Auxiliary Winding.
Compatible with the Leroy Somer RS128 A & RS128-0.
This component must be housed inside alternator terminal box and be fitted by a compete
nt electrical engineer.
SP POWERWORLD LTD
Willows, Waterside, Ryhall, Stamford, Lincs, PE9 4EY, UK Tel:
+44 1780 756872 - Email: info@sp-powerworld.com
www.sp-powerworld.com
Advertisement
Table of Contents
Related Manuals for SP POWERWORLD EA08A/RS
Summary of Contents for SP POWERWORLD EA08A/RS
- Page 1 Compatible with the Leroy Somer RS128 A & RS128-0. This component must be housed inside alternator terminal box and be fitted by a compete nt electrical engineer. SP POWERWORLD LTD Willows, Waterside, Ryhall, Stamford, Lincs, PE9 4EY, UK Tel: +44 1780 756872 - Email: info@sp-powerworld.com...
- Page 2 1. INTRODUCTION Sensing Input External Volts Adjustment Terminal 0 ~ 110V = 95 ~ 135V ±10% @ 1KΩ Terminal 0 ~ 220V = 180 ~ 250V X1、 、 、 、 X2 Z1、 、 、 、 Z2 Terminal 0 ~ 380V = 360 ~ 515V 45 ~ 600HZ Frequency 50/60 Hz, Jumper selectable...
- Page 3 ● TRIM : Analog Voltage Input Adjustment. 2. WIRING ● VOLT : Voltage Adjustment. 1. 0V-110-220-380 Sensing Input terminal. ● DROOP : Droop Adjustment. 2. F+、F- : Excitation Output. ● DIP : To set the frequency related voltage dip 3. X1-X2 、 Z1-Z2 Power Input terminal.
- Page 4 Exciter field Armature Stator wires N:5Aor1A (Harmoni) AUX. wires 110V 220V 380V EXT.VR 1k Ohm N:5A N:1A Figure 3 3 Phase (Auxiliary Winding ¡ Full Harmonic ¡ Self Excited) Wiring Exciter field Armature Stator wires N:1A Harmoni wires AUX. wires 110V 220V 380V...
