Summary of Contents for MultiDyne SMPTE-HUT
- Page 1 INSTRUCTION MANUAL Hybrid Universal Transceiver SMPTE Hybrid Cable Elimination System for Broadcast Camera Systems MultiDyne Harnessing The Power of Light 10 NEWTON PLACE HAUPPAUGE, NY 11788 USA 877-685-8439 / 516-671-7278 / FAX 516-671-3362 sales@multidyne.com www.multidyne.com...
- Page 2 MULTIDYNE, the Multidyne logo, are registered trademarks of MULTIDYNE Electronics, Inc. Copyright 2019 MULTIDYNE Electronics, Inc., Hauppauge, New York. Printed in the United States of America. All Rights Reserved. Contents of this publication may not be reproduced in any form without the written permission of MULTIDYNE Electronics, Inc.
-
Page 3: Table Of Contents
TABLE OF CONTENTS INTRODUCTION..…………..………...…..…..……………………………………………….……..…....……1 FEATURES AND OPERATION…...…………………………………………..…….......………2 - 4 CAM HUT (CAM SIDE)......………...………..………..………..………..………..…2 FRONT PANEL FEATURES......………...………..………..………..………..……….…2 OPTIONAL FRONT PANEL FEATURES..………...………..………..………..………..………..…3 REAR PANEL FEATURES......………...………..………..………..………..………..…3 CONFIGURING THE OPERATION VOLTAGE......………...………..………..…3 BASE (CCU SIDE) UNIT………………………….......………...………..……….…3 - 4 TECHNICAL SPECIFICATIONS......…..…………………………......………………..…5... - Page 4 SAFETY INFORMATION Instruction Manual, SMPTE HUT Important Safety Information Warning –indicate danger that requires proper procedures or • Read these instructions. practices to prevent injury or death to personnel. • Keep these instructions. • Heed all warnings. Cautions indicate proper procedures or practices to prevent •...
-
Page 5: Introduction
Instruction Manual, SMPTE HUT INTRODUCTION INTRODUCTION the optional optical repeater, it is important that the user be sure that his up-link and down-link signals are matched to the proper The SMPTE HUT system enables you to replace long runs of the connectors consistently throughout the link. -
Page 6: Optional Front Panel Features
FEATURES & OPERATION Instruction Manual, SMPTE HUT Optional Front Panel Features If ordered with the optional Optical repeater, besides the features of the basic unit, the front panel will have these additional features as shown in the second panel: Optical Status Leds: If the complete optical repeater option that allows optical remapping is fitted, there are 2 LEDs labeled FROM CCU and TO CCU for the 2 optical fibers. - Page 7 Instruction Manual, SMPTE HUT FEATURES & OPERATION For proper operation, the HUT-CCU must be set for the type of camera system being used. There are 2 versions of HUT-CCU: one with dip switches, and a rugged version with metal bat handle switches. Set the HUT-CCU for the camera type according to the following tables: CCU Unit (HUT BS) Front Panel Camera Select DIP Switch Settings:...
-
Page 8: Technical Specifications
TECHNICAL SPECIFICATIONS Instruction Manual, SMPTE HUT Connections SDI Standards Supported, repeater SMPTE 259M/292M/297M/425M, DVB/ASI SDI Added Jitter, repeater < .03 UI, < 1 MHZ Laser Safety, repeater Class 1 Optical Wavelengths, nm, repeater 1310. 1550 or CWDM optional Optical Sensitivity, repeater -18 dBm Optical Output Power, repeater -2 ~ -8 dBm...
