- Page 1 AD37 G2 PIR Dual Tech Manual DUAL TECHNOLOGY MOTION DETECTOR MODEL NO. LP402 MODEL NO. AD37 Installation Manual Challenger_AD37 _Instructions_Rev01...
- Page 2 PIR systems must be trigged to set off an alarm. The AD37 is compact, attractive and easy to install, it can be mounted indoors on a wall or in a corner. The AD37 is ideal for commercial, office and residential applications.
- Page 3 AD37 G2 PIR Dual Tech Manual Install PIR on wall as below figure Hold the base of the PIR in the chosen position, ensuring that the front of the PIR will face towards the center of the protected area, mark and drill two fixing holes in the wall.
- Page 4 AD37 G2 PIR Dual Tech Manual Illustration 4 E.O.L Tamper Alarm Blue Blue Yellow Black Yellow Black Red 4K7 5K6 2K2 1K Illustration 5 Control panel types available on this model. Type Control Panel Alarm Tamper Honeywell, Ademco Microtech Challenger (Force-48),...
-
Page 5: Wiring Diagram
AD37 G2 PIR Dual Tech Manual Wiring Diagram Force-48 Use this wiring configuration when connecting normally closed detection devices to the zone using 6-Wires. illustrated) Zone +13V Tamper E.O.L resistor=N.P Alarm E.O.L resistor=N.P Illustration 6 Force-48 2). Fully Supervised ( illustrated) E.O.L... - Page 6 AD37 G2 PIR Dual Tech Manual Force-10 3). Use this wiring configuration when connecting normally closed detection devices to the zone using 6-Wires. illustrated) Please Note: If more than one tamper is to be wired Force 10 system then the TAMP circuit will need to be wired in series and not parallel.
-
Page 7: Top View
AD37 G2 PIR Dual Tech Manual Understanding the LED The multi-color LED located on the bottom of the sensor indicates the status of the unit as described in the following table. Table1:LEDs Status Yellow RCR detection only(no alarm) Green PIR detection only (no alarm) PIR and RCR detection. -
Page 8: Specifications
Due to our policy of continuous improvement we reserve the right to change specification without prior notice. Errors and omissions accepted. These instructions have been carefully checked prior to publication. However, no responsibility can be accepted by Challenger Security Products for any misinterpretation of these instructions. Distributed by:...
