  6. Operator's manual

Harvestec 6000 Series Operator's Manual

Corn head
Hide thumbs
Table of Contents

Advertisement

Quick Links

6000
SERIES
2018
1.379.044
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 6000 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Harvestec 6000 Series

Summary of Contents for Harvestec 6000 Series

  • Page 1 6000 SERIES 2018 1.379.044...
  • Page 2 The following is some useful information provided to help ensure efficient and safe operation of this corn head. This manual gives some information regarding the 6000 series corn heads. Read this manual carefully to learn how to operate and service your machine correctly.

  • Page 3: Table Of Contents

    7.5. Header Drive Shafts ........................35 7.6. Plastic snout adjustment ......................36 7.7. Automatic header height control ....................36 8. HARVESTING ........................37 8.1. Stalk chopper ..........................38 8.2. Harvestec Corn Head Automatic Header Height Control (AHHC) System ......39 9. ROW SPACING ADJUSTMENT ..................40...
  • Page 4 10. MOUNTING TO ANOTHER TYPE OF COMBINE ............. 40 11. MAINTENANCE AND LUBRICATION ............... 41 11.1. Frame ............................41 11.2. Auger ............................41 11.2.1. Folding corn head - snapping unit connecting clutches ........42 11.2.2. Folding corn head - auger connecting clutches ............ 42 12.

  • Page 5: Safety

    SAFETY 1. SAFETY This is the safety-alert symbol. When you see this symbol on your machine or in this manual carefully read the message that follows, and be alert to the possibility of personal injury or death. Follow recommended precautions and safe operating procedures. UNDERSTAND SIGNAL WORDS A signal word –...
  • Page 6 SAFETY GENERAL SAFETY GUIDELINES 1. ALLOW ONLY TRAINED AND EXPERIENCED OPERATORS TO OPERATE THIS MACHINE. Operating this equipment safely requires the full attention of the operator. Do not wear entertainment headphones while operating this machine. 2. ALWAYS DISENGAGE header drive, shut off the engine and remove key before service, adjustment, maintenance and lubrication of the corn head.
  • Page 7 SAFETY SAFETY DECALS Carefully read Operator’s Manual before operating the machine. When operating, always observe safety instructions. FRONT SIDE One amber reflecting strip is located on each plate of the header extremity light guard facing forward. FIG A: Two DANGER decals are located on the front side of the header rear sheet (on each side of the feeder opening).
  • Page 8 SAFETY FIG. C: Two DANGER decals are located on the rear of the end shields. FIG C FIG. D: Four DANGER decals are located at the ends on the rear side of the header back panel above the drive shafts and on the hinged shields at both sides. FIG D...
  • Page 9 SAFETY FIG. E: Two WARNING decals are located on the hinged shields at both sides. FIG E (chopper models only) FIG. F and FIG. G: Two WARNING decals are located on the hinged shields at both sides. FIG F (chopper models only) FIG G 111670W1...
  • Page 10 SAFETY Engage feeder lift cylinder safety stop before Never attempt to open or remove shield going under header or feeder while the engine is running. Keep every shield in its place. Avoid direct contact of your hand, leg, any part of your body or clothing with rotating or moving machine parts or elements.
  • Page 11 SAFETY LIST OF ACTIVE MACHINE PARTS Active machine part Danger Snapping units, gathering chains Snatch, entanglement Gathering auger Cutting, entanglement Outside shields Nip, bruise Side chain drive Snatch, entanglement Drive shafts Entanglement Inner space between combine and corn Crushing head Stalk chopper Cutting, impact from unexpected flying objects Shields, snouts...
  • Page 12 SAFETY Illustration below shows placement of safety decals orange yellow figure shows placement of machine safety decals. 6112 6112C 6208 Type numbers 6208C Attention! The figure shows 6212 6212C only the labels on one side of 6306 6306C 6308C-70 the header, but in reality the 6308 6308C decals...

  • Page 13: Operation And Function

    OPERATION AND FUNCTION 2. OPERATION AND FUNCTION The Harvestec corn head can be mounted on most combines. Corn ears are detached from the corn stalks as is shown on the illustration below. The corn stalk enters the area between the snapping rolls (1,2) which counter-rotate relative to each other, and are pulled downwards between the snapping plates (3) by the rolls (1,2).
  • Page 14 OPERATION AND FUNCTION Operation The corn head is driven from the combine feeder shaft through a universal drive shaft or chain shaft coupling. Power is transmitted from the drive shaft by gears encased in an oil bath to a shaft which passes through the snapping unit. Torque limiting clutches transmit power from the shaft to each snapping unit.
  • Page 15 OPERATION AND FUNCTION The corn head has no specific emergency stop system. The emergency stop is actuated using the combine systems located in the combine operator’s cab. Understand and respect the relevant instructions of the combine emergency stop procedures as related to the corn head.

  • Page 16: Identification And Specifications

    A mounting kit is assembled to the corn head at the factory as ordered. A data plate is located on the left side of the corn head upper beam. The model number refers to the following: for example: HARVESTEC 6312C • 6312 12-row fixed frame with 30” row spacing •...

  • Page 17: Specifications

    IDENTIFICATION AND SPECIFICATIONS 3.2. Specifications 3.2.1. Dimensions Weight Width Length in Height in Length shipping Height shipping Row Spec Model Chopper (mm) condition (mm) condition (mm) (mm) 6R70cm 6306C-70 2140 4710 4299 14,1 2970 1100 1410 2430 6R30 6306 2090 4600 4609 15,1...

  • Page 18: Shipping Conditions

    SHIPPING CONDITIONS 4. SHIPPING CONDITIONS The corn head is delivered mounted on a shipping skid suitable for handling by forklift. Lifting rings are also provided suitable for overhead lifting. Ensure that the lifting equipment is adequate for the weight indicated on the serial data plate. When using a forklift under the skid, ensure that the forks are spaced evenly about the centerline of the corn head.
  • Page 19 SHIPPING CONDITIONS NOTE: Only use a cable with specified capacity that meets the weight of the machine. max. 90º When lifting a 12-row corn header use four cables as shown in the photo below.

  • Page 20: Mounting The Corn Head On The Combine

    MOUNTING TO THE COMBINE 5. MOUNTING THE CORN HEAD ON THE COMBINE While the corn head is mounted on shipping stand • Remove the parking stands and snouts from the shipping position and install parking stands in their retracted position •...
  • Page 21 MOUNTING TO THE COMBINE CASE IH 1000-2000 Adjust the nuts on the U-bolts (1) as required to provide adequate clamping force. Refer to the combine operator’s manual for the correct adjustments and latching methods. New Holland CR/ CX; Case AFX; similarly MF 9000/8680/8780; Gleaner S/R/C62 Adjust the position of the latch retainer (1) to ensure that the feeder lever is fully engaged.
  • Page 22 MOUNTING TO THE COMBINE Attention! Pre-perforated plates must be removed from the roof of the hood for Case AFX combines. MF 8500 Series Adjust the nuts on the U-bolts (1&2) as required to provide adequate clamping force (3). Refer to the combine Operator’s Manual for the correct adjustments and latching methods.
  • Page 23 MOUNTING TO THE COMBINE Claas Attach the Snouts Place the central snouts onto the rear divider pins (1). For easier mounting, first loosen the rear divider pin which is secured by a hex bolt (2), secure the central snouts from the outside with Allen-head bolts (3) and then tighten the loosened hex bolts.
  • Page 24 MOUNTING TO THE COMBINE Remove the Lifting Bar Remove the lifting bar from the snapping unit ONLY after the corn head is properly attached and secured to the combine, and the combine feeder lift cylinder stop is engaged. Connect Header Drive Shafts Connect the drive shafts and ensure that the protective shields are properly in place and that all rotating parts are adequately shielded.
  • Page 25 MOUNTING TO THE COMBINE Position the protective shield of the drive shaft, according to the combine operator’s manual, after connecting to the feeder drive shaft. To prevent the rotation of the header drive shaft shield, attach both original chain restraints to the corn head.
  • Page 26 MOUNTING TO THE COMBINE Connect the hydraulic system (for folding corn heads) The hydraulic source is typically the combine reel lift function. The schematic below illustrates the hydraulic system of the folding corn head.
  • Page 27 MOUNTING TO THE COMBINE The right order of the cylinders movement during folding is the following: 1. The locking cylinders (D1, D2) and plastic hinged dividers cylinders (B1, B2) has to extend until the end position. 2. After 1. point the lifting cylinders (A1, A2) must fold the wings. If the lifting cylinders start before the other cylinders (D1, D2, B1, B2) reach their end positions, then the pressure relief valve’s adjuster screw has to be turned a half turn clockwise.

  • Page 28: Run-In Procedure

    RUN-IN PROCEDURE 6. RUN-IN PROCEDURE A 20 minutes “trial run” is suggested after the initial mounting. Prior to the trial run, perform a full lubrication procedure as described in Section 1 "Maintenance and Lubrication”. Gearboxes are filled with lubricant at the factory but levels should be checked before beginning the trial run.

  • Page 29: Setup Procedure And Adjustment Of The Corn Head

    SETUP PROCEDURE 7. SETUP PROCEDURE AND ADJUSTMENT OF THE CORN HEAD 7. 1. Frame The corn head is provided with parking stands which must always be used when it is to be disconnected from the combine. Before detaching the corn head from the combine, adjust the parking stand position such that the distance between the ground and the lower support of the corn head is about 30 cm (12 inches).

  • Page 30: Auger

    SETUP PROCEDURE 7.2. Auger The auger is driven through a torque-limiting clutch that can disengage excessive loads on the drive. This clutch is located on the left-hand side, but an additional clutch is located on the right hand side on larger corn heads. In some conditions it may be necessary to change the speed of the auger.

  • Page 31: Input Gearbox Drive

    SETUP PROCEDURE 7.3. Input Gearbox Drive The input gearboxes are connected by a double joint coupling drive or shaft (1) depending on the combine. The gearbox assemblies (2) are selected to provide a nominal snapping unit input speed of 550 rpm for each combine. Gearboxes can be exchanged as necessary.

  • Page 32: Snapping Units

    SETUP PROCEDURE 7.4. Snapping units 7.4.1. Snapping rolls adjustment Three important settings must be observed when installing or adjusting the snapping rolls. 7.4.1.1. Distance between snapping roll shafts Adjust the shafts parallel to each other by setting 62 mm (2.45”) between the two bearing housings as shown in the illustration below.

  • Page 33: Snapping Plate Adjustment

    SETUP PROCEDURE 7.4.1.3. Alignment The front bearing support is mounted to the snapping roll frame with slotted holes. Set the rolls in line as shown below. Correct Incorrect Knife 7.4.2. Snapping plate adjustment The nominal factory setting is 27 mm (1-1/16”) at the front and 32 mm (1-1/4”) at the rear. For proper operation, the snapping plate gap should be 5 mm (3/16”) tighter at the front than at the rear.

  • Page 34: Vine Knife Adjustment

    SETUP PROCEDURE 7.4.3. Vine knife adjustment The gap between the vine knives and the stalk rolls should not exceed 0.5 mm (.02”). This gap should be set on one rib and all rib clearances should be checked by the rotation of the rolls to ensure there is no interference.

  • Page 35: Gearbox Timing And Backlash Adjustment

    SETUP PROCEDURE 7.4.5. Gearbox timing and backlash adjustment Snapping roll gear timing is done by visually aligning the hex shafts as shown below. The backlash can be determined by rotating one gear relative to the other. There should be 1° of free rotation between the gears.

  • Page 36: Plastic Snout Adjustment

    SETUP PROCEDURE 7.6. Plastic snout adjustment Lower the combine feeder until the distance between the skid shoe of the snapping unit and the ground is 8 cm (3-1/4”). The skid shoe of the snout should just touch the ground. Manufacturer and Distributor are not responsible for incorrect snout adjustment. 7.7.

  • Page 37: Harvesting

    HARVESTING 8. HARVESTING The corn head is ready for harvesting after completing the preceding instructions in this manual, which refer to Mounting, Run-in, and Set-up and Adjustment Procedure. • Always be aware of the presence of the stalk chopper, if fitted, when harvesting. •...

  • Page 38: Stalk Chopper

    HARVESTING 8.1. Stalk chopper The stalk chopper (1) cuts the stalks directly under the snapping rolls (2) with special knives. The stalk chopper drive can be disengaged by turning the hex knob (3) 180 degrees. Then chopper knives can be reversed when worn. When knife replacement is necessary replace the bushings, bolts and safety wires as well.

  • Page 39: Harvestec Corn Head Automatic Header Height Control (Ahhc) System

    HARVESTING 8.2 Harvestec Corn Head Automatic Header Height Control (AHHC) System The Harvestec corn head AHHC ground contacting system requires that the combine be equipped with the OEM (Original Equipment Manufacturer) combine AHHC system to operate. It also operates with the combine lateral header tilt system if the combine is so equipped.

  • Page 40: Row Spacing Adjustment

    MAINTENANCE AND LUBRICATION 9. ROW SPACING ADJUSTMENT The row unit spacing must match the corn row spacing for optimum performance. This is of greater importance with wider corn heads. Improper matching can result in premature wear of the snapping roll front supports and the leading edge of the snapping plates. The row unit spacing is not adjustable.

  • Page 41: Maintenance And Lubrication

    MAINTENANCE AND LUBRICATION 11. MAINTENANCE AND LUBRICATION 11.1. Frame The frame of non-folding corn heads does not require any special maintenance. The folding mechanism of the folding corn head should be greased with Liton Ep2 or equivalent quality grease once a season. Grease the fitting until grease extrudes from the sides of the parts shown on the picture (marked with “A”).

  • Page 42: Folding Corn Head - Snapping Unit Connecting Clutches

    MAINTENANCE AND LUBRICATION 11.2.1. Folding corn head - snapping unit connecting clutches The clutch jaws should be greased daily with Liton Ep2. 11.2.2. Folding corn head - auger connecting clutches Grease the surfaces of the clutch jaws every 50 hours with Liton Ep2. Before unfolding the corn head into the harvesting position ensure that the auger connecting clutch drive jaws are as shown below.

  • Page 43: Input Gearboxes

    MAINTENANCE AND LUBRICATION 12. INPUT GEARBOXES SAE 80W-140 oil is used for lubrication. To check the oil level, remove the level plug (1) with the corn head in harvesting position. Check the oil level annually, more often if leakage is detected. The drain and filling plugs (2) are on the main casting of the gearbox, but filling can also be done through the level plug or breather ports.

  • Page 44: Drive Components

    MAINTENANCE AND LUBRICATION “Driven” gearbox position, if “Driven” gearbox position, if the “driver” gearbox is the “driver” gearbox is mounted in the lower position. mounted in the upper position. The location of the breather depends on the final position of the gearbox. The breather should be placed in the cover hole above the oil level plug.

  • Page 45: Snapping Unit

    MAINTENANCE AND LUBRICATION 14. SNAPPING UNIT 14.1. Gearboxes Main gearbox Chopper gearbox SAE 80W-140 oil 0.26 kg (0.3 l) EP-00 liquid grease 2.5 kg (2.5 l) Start of every harvest, 50 hours, or when or when leakage Check frequency leakage detected detected Inspect gearboxes daily to detect any leakage which may cause failure.
  • Page 46 MAINTENANCE AND LUBRICATION Stalk chopper gearbox: Lubricant fill Lubricant drain plug/dipstick To check lubricant levels: - Lower corn head to the ground - Unscrew the dipstick - Wipe the dipstick, then replace it but do not screw it back in - Wait, then remove the dipstick - The lubricant level should be midway between the minimum and maximum warning lines.
  • Page 47 MAINTENANCE AND LUBRICATION Chopper knives • Check knife condition daily. • Never operate with damaged knives. • The radial clearance between the knife and bushing should not exceed 1 mm (.04”). If clearance exceeds 1 mm (.04”), change both the knife and bushing. •...

  • Page 48: Snapping Roll

    MAINTENANCE AND LUBRICATION 14.1.1. Snapping roll The front bearings are lubricated with Liton Ep2 and sealed on both sides by the bearing manufacturer. A greased labyrinth is provided to protect the bearings. Grease the front fitting every 250 operating hours until grease extrudes from the labyrinth. This will ensure flushing of the old grease and fully replacing it with new grease.

  • Page 49: Gathering Chain

    MAINTENANCE AND LUBRICATION 14.1.2. Gathering chain • Lubricate daily using synthetic or vegetable grease or oil. • Check daily for abnormal wear. The corn head Pre-harvesting and Pre-delivery inspection checklists are at the end of the operator’s manual. Please verify the corn heads condition before the first running procedure following the Pre-delivery inspection.

  • Page 50: Electrical Schematics

    ELECTRICAL SCHEMATICS 15. Electrical schematics 15.1. JD electrical schematic...

  • Page 51: Cnh Electric Schematic

    ELECTRICAL SCHEMATICS 15.2. CNH electrical schematic...

  • Page 52: Agco Electric Schematic

    ELECTRICAL SCHEMATICS 15.3. AGCO electrical schematic...

  • Page 53: Claas Electric Schematic

    ELECTRICAL SCHEMATICS 15.4. CLAAS Lexion electrical schematic...

  • Page 54: Cih 2000 Electric Schematic

    ELECTRICAL SCHEMATICS 15.5. CIH 2000...

  • Page 55: Trouble Shooting

    TROUBLE SHOOTING 16. TROUBLE SHOOTING 16.1. A large quantity of ears builds up between the auger and feeder. This can result from improper adjustment of the combine for corn harvesting operation, including threshing component speed, concave clearance or angle of the feeder front face. Ensure that the combine is adjusted for corn harvesting in accordance with the instructions and settings as recommended in the combine operator’s manual.

  • Page 56: Off-Season Storage Of Your Corn Head

    OFF-SEASON STORAGE WARRANTY AND SERVICE OFF-SEASON STORAGE OF YOUR CORN HEAD When harvesting is completed, thoroughly clean the corn head and remove all remaining stalks. Carefully inspect the corn head to ensure it will be in proper operating condition for the next season.

  • Page 57: Lubrication Chart

    LUBRICATION CHART 19. LUBRICATION CHART...
