STEP MOTOR REPLACEMENT INSTRUCTIONS (82-ST0502)

Removing the Motor

The motor is attached to the step frame using three
bolt goes through a plastic motor spacer (Fig. 3). These spacers are not attached to the motor and will fall
out when the bolt and/or the motor is removed.
1. Disconnect the 2-wire power motor harness from the motor plug. It may be necessary to use a 5/16"
socket with ratchet to loosen the hex bolts used for mounting the motor.
2.
Completely remove the three hex bolts (Fig. 4).
Fig. 3
Rev: 10.04.18
KWIKEE
Moving parts can pinch, crush or cut. Keep clear and use caution.
Plastic Spacer
(total of 3)
REVOLUTION SERIES
®
STEPS
5/16
" hex bolts. On the bottom side of the motor, each
5/16
" Hex Bolts
Page 2
Fig. 4
CCD-0002267
