- Page 1 LIGHT GROOVE 150DX RG150/RG150A OPERATION MANUAL STOP Be sure to read this operation manual before using the machine. - N o t e -...
- Page 3 ………………………………………………………………… …………………………… ……… ………………………………………………………………………… ……………………………………………………………… ……………………………………………………………… ………………………………………………………… ………………………………………………………………………… …………………………………………………… ……………………………………………………………………… …………………………………………………………… …………………………………………… ……………………………………………………… …………………………………………………………………… WARNING WARNING CAUTION CAUTION WARNING WARNING CAUTION WARNING WARNING CAUTION CAUTION...
-
Page 4: Safety Considerations
1. SAFETY CONSIDERATIONS WARNING 1. Ensure you use the correct voltage. 2. Check the switch is OFF before inserting the plug into the power supply socket. 3. Avoid electric shock. 4. Be aware of the environment you are working in. 5. - Page 5 16. Do not handle the power cord carelessly. 17. Perform careful maintenance daily. 18. Check for damaged parts. 19. Store carefully when the machine is not in use. 20. For overhaul and repair of the machine, ask an appointed REX agent.
- Page 6 2. PRECAUTIONS WHEN USING THE LIGHT GROOVE 150DX WARNING 1. Use rollers that match the pipe being processed. (Refer to Fig. 1, Fig. 5) 2. Never touch rotating parts. 3. When replacing or inspecting the rollers, turn the switch OFF and pull the cord out of the socket.
- Page 7 3. MAIN PARTS, STANDARD SPECIFICATIONS, ACCESSORIES NAMES OF EACH PART Parts in common Manual Pump/RG150 Cord Automatic Pump /RG150A STOP STANDARD SPECIFICATIONS RG150 RG150A 220 - 220 - STANDARD ACCESSORIES OPTIONAL ACCESSORIES Application...
-
Page 8: Getting Ready
4. GETTING READY 1. Setting Up Attaching the legs (Fig. 4) STOP CAUTION Changing the rollers. (Fig. 5) 1 - 1½ (25A - 40A) 2 - 6 (50A - 150A) 8 - 12 (200A - 300A) 8 - 12 /10 - 12 (250A - 300A) 14 - 16 (350A - 400A) - Page 9 4. GETTING READY 2. Setting Up the Pipe Adjusting the height of the pipe (Fig. 8) Spirit Level Pipe Bearing Pipe 120° Contact between Pipe pipe and collar 10 11) CAUTION Adjusting the pipe swing (Fig. 11) 5° 3° CAUTION...
- Page 10 4. GETTING READY Operating the head lock pin CAUTION Operating the roller lock pin according to the type of pipe Pull Push Automatic Alignment Pipe 1. Position when the pipe is set 2. Pipe rotation 3. Centre is aligned aut tomatically...
-
Page 11: Operating The Pump
4. GETTING READY 3. Operating the Pump WARNING Operating Manual Pump (RG150) Fig. 15 Operating Manual Pump (RG150) Operating Automatic Pump (RG150A) Fig. 16 Operating the Automatic Pump Operating Automatic Pump (RG150A) Green LED Stop Down... - Page 12 1. Loosen the lock nut. (Fig. 17) Loosen Procedures in common 2. Adjusting the position of the upper roller (Fig. 18) Manual Pump /RG150 Automatic Pump /RG150A Engaging the pipe 3. Adjustment of groove depth (Fig. 19) Procedures in common Tighten 4.
- Page 13 5. OPERATION GUIDE 2. Grooving 1. Preparing to process the pipe (Fig. 21) Manual Pump /RG150 Pipe Automatic Pump /RG150A 2. Adjusting the guide roller (Fig. 22) Procedures in common 3. Adjusting the head (Fig. 23) Procedures in common 4. Using the Foot Switch (Fig. 24) <...
- Page 14 5. OPERATION GUIDE 5. Grooving(Fig. 25, 26) Manual Pump /RG150 (200A - 300A) Pull over and down Automatic Pump /RG150A 6. Finishing up (Fig. 27) Manual Pump /RG150 Automatic Pump /RG150A 3. CONFIRM GROOVE DIMENSIONS Pipe Groove gauge トマリ トオリ ×...
- Page 15 5. OPERATION GUIDE Deeper Shallower 2. Check the L and W dimensions with a caliper. Roll groove size table ▲ ▲ Pipe Outside (25A) (32A) (40A) (50A) (65A) (80A) (100A) (125A) (150A) (200A) (250A) (300A) (350A) (400A) 8 (200A) 8 (200A) to 16 (400A)
-
Page 16: Carrying The Machine
5. OPERATION GUIDE 4. Pipe chamfer Pipe 5. Carrying the machine 1. Locking the head (Fig. 32) 2. Removing the legs (Fig. 33) CAUTION STOP Carrying (Fig. 34) STOP Lifting (Fig. 35) STOP... - Page 17 6. SERVICING AND REPAIRS, TROUBLESHOOTING WARNING Cause and measures when problems occur (TROUBLESHOOTING)
-
Page 18: Daily Inspection, Maintenance
7 DAILY INSPECTION, MAINTENANCE WARNING A. General Inspection D. Grease Nipple C. Inspection of Rollers B. Inspection of the Electric Cable 1. Inspect all screws and nuts (A) 2. Inspect the electric cable, etc. (B) 3. Rollers inspection (C) 4. Periodic lubrication (C) & (D) 5. -
Page 19: Requesting Repairs
8. REQUESTING REPAIRS... -
Page 20: Warranty And Liability
Warranty and Liability 7A080-CE6 RG150/RG150A 1808D0200...
