UNDER SINK
Reverse Osmosis Filtration Systems
VRO-3Q
VRO-4Q
VRO-5Q
Installation, Use & Care Guide
(Customer must read this manual thoroughly before installing the system)
Questions, problems, missing parts? Before returning to your retailer, call our customer service department at:
1 (877)-447-4768. 8:30am-4:30pm CST, Mon - Fri or email us at customerservice@ghpgroupinc.com
GHP Group
USA: 6440 W. Howard Street, Niles, Illinois 60714
Canada: 271 Massey Road, Guelph, Ontario, N1K 1B2
CONSUMER: Retain this manual for future reference.
www.ghpgroupinc.com
The VRO-3Q and VRO-4Q have been tested
and certified by NSF International against
NSF/ANSI Standard 42, 58 and CSA B483.1
for reduction of the claims specified on the
performance data sheet
The VRO-5Q has been tested and certified by
NSF International against NSF/ANSI Standard
58 and CSA B483.1 for reduction of the claims
specified on the performance data sheet
2017-06-21
Printed in China
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for vitapur VRO-3Q
Summary of Contents for vitapur VRO-3Q
- Page 1 The VRO-3Q and VRO-4Q have been tested and certified by NSF International against NSF/ANSI Standard 42, 58 and CSA B483.1 for reduction of the claims specified on the performance data sheet UNDER SINK The VRO-5Q has been tested and certified by NSF International against NSF/ANSI Standard 58 and CSA B483.1 for reduction of the claims...
-
Page 2: Table Of Contents
Table of Contents: Safety Precautions ............1 * Mounting the Ball Valve Onto Storage Tank ..... 11 Conditions for Operation ..........1 * Connecting the Water Lines ........11 Package Contents ............2 * Tubing Connection with Push-in Fitting ...... 12 Tools Required for Installation ......... -
Page 3: Package Contents
Package Contents: VRO-3Q VRO-4Q VRO-5Q Accessories Kit Part Description VRO-3Q Air-gap Faucet Set Part Description Inlet Valve Set Unit Assembly Saddle Drain Clamp Set Tank Ball Valve VRO-4Q Storage Tank Mounting Screw 2 or 3 Part Description 6’ of 1/4” Blue Tubing Unit Assembly 6’... -
Page 4: System Layout And Components
Reverse Osmosis System Layout and Components: VRO-3Q Filtration Process: Auto Shut-O Valve Black Stage Stage Stage Black Replacement Parts Filter Stage Part Number Description Service Life Filter Color Code VRFQ-CTO Carbon Block Filter, 5 Micron 6 to 12 Months Green Dot... - Page 5 Reverse Osmosis System Layout and Components (continued): VRO-4Q Filtration Process: Stage Stage Stage Stage Black Replacement Parts Filter Stage Part Number Description Service Life Filter Color Code VRFQ-PP PP Sediment Filter, 5 Micron 6 to 12 Months Yellow Dot VRFQ-CTO Carbon Block Filter, 5 Micron 6 to 12 Months Green Dot...
-
Page 6: System Layout And Components
Reverse Osmosis System Layout and Components: VRO-5Q Filtration Process: Black Replacement Parts Filter Stage Part Number Description Service Life Filter Color Code VRFQ-PP PP Sediment Filter, 5 Micron 6 to 12 Months Yellow Dot VRFQ-CTO Carbon Block Filter, 5 Micron 6 to 12 Months Green Dot VRFQ-CTO... -
Page 7: Installation Instructions
Installation Instructions: All Vitapur RO Systems have been pre-assembled and tested at the factory, and don’t need to dis-assemble. If you want to check or replace the filter(s). The following steps need to be implemented: Installing the Quick Connect Filter (See Figure 1): 1. -
Page 8: Tapping Into Cold Water Line
Installation Instructions (continued): Tapping into Cold Water Line (See Figure 3 and 4): CAUTION: The water supply to your unit MUST be from the COLD WATER LINE. Hot water will severely damage your filtration system. 1. Turn off the cold water supply by turning off the shut off valve under the sink. If the cold water line does not have a shut off valve under the sink, turn off the main water line in the house. -
Page 9: Installing The Air-Gap Faucet
Installation Instructions (continued): CAUTION: Do not drill through a counter top that is more than 1” thick. CAUTION: Do not attempt to drill through a tiled, marble, granite or similar countertop. Consult a plumber or the countertop manufacturer for advice or assistance CAUTION: When drilling through a countertop make sure the area below the drilled area is free of wiring and piping. -
Page 10: Installing The Saddle Drain Clamp
Installation Instructions (continued): Installing the Air Gap Faucet Continued (see figure 7 and 8): 3. Loosen stem-nut on the faucet. 4. Slide Chrome Plate and Black Rubber Washer onto the faucet stem. The chrome plate, rubber washer and faucet body are installed above sink or countertop. 5. -
Page 11: Mounting Ro Unit Under Sink
2. Install mounting screws at least 15 3/4” from cabinet floor. Leave 1/4” space between the head of the screw and the wall to slip bracket onto the screws. Then tighten the screws to secure the system. System Dimensions: VRO-3Q VRO-4Q & VRO-5Q 14” 10”... -
Page 12: Mounting The Ball Valve Onto Storage Tank
Installation Instructions (continued): Mounting the Ball Valve Onto the Storage Tank (See figure 11 and 12): 1. Connect the Ball Valve to the water Storage Tank thread on the upper side of the tank. Make sure the black rubber gasket sits flat. Tighten the valve but do not overtighten. 2. -
Page 13: Tubing Connection With Push-In Fitting
Installation Instructions (continued): Tubing Connection with Push-in Fittings (See Figure 14, 15 and 16): 1. Take off the blue horseshoe clip from collet. 2. Pull out and discard the protect plug by pushing the collet inward and holding with fingers. 3. -
Page 14: Periodic System Maintenance
NOTE: Place a tray or towel under the RO system to catch any water drips before uninstalling the filter sumps. For Model VRO-3Q: 1. Refer “Un-install Quick Connect Filter” on page 6, to remove 1st stage of filter (left one in front of the system). -
Page 15: Ro Membrane Replacement
Periodic System Maintenance (continued): For Model VRO-4Q: 1. Refer “Un-install Quick Connect Filter” on page 6, to remove 1st stage of filter (left one in front of the system). 2. Then, remove 2nd and 4th stage of filters. 3. Discard the filters in a proper manner. 4. -
Page 16: Post Carbon Filter Replacement (Vro-5Q Only)
Post Carbon Filter Replacement (VRO-5Q only): The inline post carbon filter has a life expectancy between 6 to 12 months. The inline post carbon filter is an effective filter in removing any post taste and odor. Flow Direction Water Water Inlet Outlet 1. -
Page 17: Troubleshooting Guide For Ro Systems
Troubleshooting Guide for the RO Systems: Problem Possible Cause Solution It’s a normal occurrence during initial start-up of the system. Milky coloured water Air in system This milky colour will disappear during normal use within 1 to 2 weeks Air gap of faucet Inherent sound with an air-gap faucet Noise from faucet Location of drain saddle... -
Page 18: Performance Data
Performance Data: Reverse Osmosis Drinking Water System Model: VRO-3Q, VRO-4Q and VRO-5Q The system must be installed and operated in accordance with manufacturer’s recommended procedures and guidelines. Failure to follow the instructions may result in the leakage, malfunction and will void warranty. -
Page 19: Performance Data
Performance Data Sheet: The VRO-3Q and the VRO-4Q have been tested and certified by NSF International according to NSF/ANSI 42 and 58 and the VRO-5Q has been tested and certified by NSF International according to NSF/ANSI 58 for the reduction of the substances listed below. -
Page 20: Replacement Parts List
Replacement Parts List: VRO-3Q S/N Description Part # S/N Description Part # Storage Tank YY.VRO3Q-1 Small O-ring, Filter Housing YY.VRO3Q-15 Tank Ball Valve YY.VRO3Q-2 Big O-ring, Filter Housing YY.VRO3Q-16 6’ of 1/4" Yellow Tubing YY.VRO3Q-3 Carbon Block Filter VRFQ-CTO Saddle Drain Clamp Set YY.VRO3Q-4... - Page 21 Replacement Parts List: VRO-4Q S/N Description Part # S/N Description Part # Storage Tank YY.VRO4Q-1 Metal Bracket YY.VRO4Q-16 Tank Ball Valve YY.VRO4Q-2 Flow Restrictor, 300 mL YY.VRO4Q-17 6’ of 1/4" Yellow Tubing YY.VRO4Q-3 1/4" QC Elbow YY.VRO4Q-18 Saddle Drain Clamp Set YY.VRO4Q-4 1/4"...
-
Page 22: Replacement Parts List
Replacement Parts List: VRO-5Q S/N Description Part # S/N Description Part # Storage Tank YY.VRO5Q-1 Flow Restrictor, 300 mL YY.VRO5Q-17 Tank Ball Valve YY.VRO5Q-2 Mounting Screw, Bracket YY.VRO5Q-18 6’ of 1/4" Yellow Tubing YY.VRO5Q-3 Metal Bracket YY.VRO5Q-19 Saddle Drain Clamp Set YY.VRO5Q-4 Mounting Screw, Filter Head YY.VRO5Q-20... -
Page 23: Limited Warranty
Warranty: Limited Warranty: This limited warranty is extended to the original retail purchaser of this filtration system and warrants against any defect in material and workmanship for a period of one (1) year from the date of retail sale. GHP Group, Inc., at its option, will either provide replacement parts or replace the unit, when properly returned to the retailer where purchased or one of our service centers as directed by GHP Group, Inc., within one (1) year of retail purchase.
