Rayne 5066 Water Softener
Owner's manual 5066
This manual contains information on setting the controller and normal operating maintenance required
by the owner for the following units: RG 1250, RXD 1000, RXD 1500, & RXD 1500D
Water Quality Association tested and certified under industry standards
Owner's Manual
Water Softener Assembly
Item #
RG-1 250
DESCRIPTION – Rayne Guardian
Advertisement
Table of Contents
Related Manuals for Rayne 5066
Summary of Contents for Rayne 5066
- Page 1 Rayne 5066 Water Softener Owner’s manual 5066 This manual contains information on setting the controller and normal operating maintenance required by the owner for the following units: RG 1250, RXD 1000, RXD 1500, & RXD 1500D Water Quality Association tested and certified under industry standards Owner’s Manual...
- Page 2 5066103 RXD Controller – Specify Tank Size 18259-02 RXD Front Cover 60049 Bypass, plastic with 1″ yoke RF0030 High Flow Distributor – Specify Tank Size 10 x 47 Mineral Tank 1/4 CF Filtrex Media 1-1/4 cf High Capacity Resin, Solvent Free 8 lbs.
- Page 3 Item # RG-1 250 DESCRIPTION C10772 BR 15″ x 17″ Complete Brine Tank Assembly B08802 BR 15″ x 17″, Black Brine Tank A10171 BR 15″ x 17″, Black Brine Tank Lid A11510 BR Brine Line A13940 BR Overflow Fitting A14120 BR Brine Well A05300 BR (2) Brine Well Lid...
- Page 4 Owner’s Manual Down Flow Control Valve Item No Quantity Part No Description 1 …………. ….1 ………..18815……………Valve Body, 5000, 1 “Dist. 2…………. ….1 ……….. 18264…………………..Spacer, End 3……….. ……4 ………..14241 …………………..Spacer 4…………….. ………..13242………………….. Seal 5…………… ………..18265………………….. Piston, Downflow 6…………….. ………..14309………………….. Retainer, Piston Rod 7……………..
- Page 5 ……….. 1 ………..11973 ………………….. Spring, Brine Valve …………1 ………..16098………………….. Washer, Plain, Nylon ……….. 1 ………..11981 01 ……….. Retaining Ring ……….. 1 ………..11183 ………………….. 0 Ring, 017 ………. 1 ………..2.4 GPM ……….. Flow Washer ……….. 1 ………..11385 01 ……….. Flow Control Housing, Plastic ………..
- Page 6 Item No Quantity Part No. Description 1 …….. ………..1 .. ….EB5066………. Electronic Board 2 …………… ….1 . …..60200-00 ……. Control Drive Assembly, Downflow 3 ……………..1 .. ….18217-10 ……. Motor Assembly 24V /60 Hz 4 ………….. …..2 …… 13602 ………… Screw, Rd Head, 6-32 x 5/16 5 …………….
- Page 7 Item No. Quantity Part No Description …..19797 ………………..Meter Assembly, Turbine …… . 13314 ………………..Screw, Hex Washer, 18-18 x 5/8 ………. 1 19569 ………………..Clip, Flow Meter ………. 1 19791-01 ……………Meter Cable Assembly, Turbine 5…………… ..13305 ………………..0 Ring, 119 ………. 4 14613 ………………..Flow Straightener Owner’s Manual By-Pass Assembly...
- Page 8 Item No. Quantity Part No Description 1 …………… .1 …. .. 19723 ……………………By Pass Valve Body, Plastic 2 …….. ………..1 … …11183………………………..0 Ring, 3 …….. ………..1 … …19724 ……………………….Cap, By Pass 4…………. ……2 . …..17512 ……………..Screw, Hex Washer Head, #624×3 5 …………….
- Page 9 2…………….. ………….. 19803……………….. Safety Brine Valve Arm Assembly 3…………….. ………….. 19804……………….. Stud, 1024 4…………….. ………….. 19805……………….. Nut, 1024 5…………….. ………….. 1965201 …………… Poppet & Seal 6…………….. ………….. 19649……………….. Flow Dispenser 7…………….. ………….. 11183 ……………….. 0 Ring, 017 8 …………….. ………….. 19647………………..
- Page 10 function. Make sure the control valve is returned to the service position. 11. Replace the control valve back cover. Set top leading edge of cover over the 2 legs and rotate down 12. Make sure there is enough brine in the brine tank.13. Plug cable into meter cover. 14.
- Page 11 Check for leaks at all seal areas. 14. Plug electrical cord into outlet. 15. Set time of day. Make sure the control valve is in the service position. 16. Plug cable into meter assembly. F. Replace Filtrex media 1. Approximately every 2 years contact your local Rayne Dealer. Owner’s Manual...
- Page 12 A.Controller improperly set, due A.Reset timer to Power failure B. Check battery. SYMPTOM Loss of capacity. PROBABLE CAUSE CORRECTION A.Increased raw water hardness. A.Connect to constant automatically. B.Brine concentration and for quantity. B.Keep full of salt at all times. Clean it yearly.
- Page 13 bed: Well gas eliminator Loose brine line. SYMPTOM Poor water quality. PROBABLE CAUSE CORRECTION Check items listed in #3. A. Check items listed in #3. Bypass valve open. B. Close bypass valve. Channeling. C. Check for too slow or high flow.
- Page 14 SYMPTOM Excessive water in brine tank and/or salty water to service. PROBABLE CAUSE CORRECTION A.Plugged Drain Line A.Check flow to drain, clean flow control. B.Dirty or damaged brine valve. B.Clean or replace brine valve. Plugged injector C.Clean injector and replace screen. D.Low inlet pressure.
- Page 15 for scratches and dents. SYMPTOM Control cycles continuously. PROBABLE CAUSE CORRECTION A.Faulty timer. A.Replace timer. SYMPTOM Continuous flow to drain. PROBABLE CAUSE CORRECTION A.Faulty timer. A Call dealer, clean valve, rebuild unit. B.Internal control leak. B. Same as above. Valve jammed in brine C.Same as above refill unit.
- Page 16 …………… 13302………….. 0 Ring, 014 …………… 16098 ………….. Washer, Plain, Nylon …………… 17978 ………….. Brine Valve Stem …………… 18755………….. 0 Ring, 201 6002212 ……… BLFC.1125 GPM 6002225 ……… BLFC.25 GPM 6002250 ……… BLFC.50 GPM – Standard 60022100 ……. BLFC 1.0 GPM …………..
- Page 17 182723……….. 1610 Injector Assy., 3, Yellow ………….10141 …………… 0 Ring, 010 ………….13771 …………… 0 Ring, 012 ………….18273…………… Vortex Generator …………..18274 XX……… Injector Nozzle ………….18275 XX……… Injector Throat 60280 0001610 Injector Kit, 000, Brown 6028000 1610 Injector Kit, 00, Violet 602800 1610 Injector Kit, 0, Red 602801 1610 Injector Kit, 1, White...
- Page 18 6070515 ….. DLFC 1.5 GPM 60705 17….. DLFC 1.7 GPM 6070520 ….. DLFC 2.0 GPM 6070524 ….. DLFC 2.4 GPM Model 1250 6070530 ….. DLFC 3.0 GPM 60705 35 …. DLFC3.5 GPM 60705 40 …. DLFC 4.0 GPM 6070545 ….. DLFC 4.5 GPM 6070550 …..
