Modern Office MJ Assembly Instructions

Peninsula Desk Assembly Instructions
MJ/ML/WH
Cherry/Maple/White Peninsula Desk
Applies to:
FL/MJ/ML/WH2047
List of Hardware:
Part
Part
:
0
�
Cap
Wood Dowel
c!
i
M6 Screw
Leveling Glide
��
Cam Lock
& Pin Set
Tools Needed:
-Phillips Screwdriver
-A helper!
www.modernofficefurniture.com
FL2047
Mocha Peninsula Desk
1.) Assemble on carpet or cardboard
to protect parts during assembly.
Assembly will require 2 people for
safety.
2.) Locate Post Leg. (You may need to
tighten the connecting plate by tightening
the screw inside the leg). Using the 4
M6 Machine Screws provided.and screw
the top of the leg into the underside of
the peninsula desktop. The holes are
piloted.
3.) Next, insert all dowels, cam pins and
cam locks into the desktop, Side Panel
and Support.
4a.) If you have a Cherry, Maple or White
Peninsula desk, attach the Support and
Side Panel together. Insert the dowels
and cam pins into the corresponding
holes and twist the cam locks with your
screwdriver to secure. (Fig. 1)
4b) If you have a Mocha Peninsula Desk,
Attach the Support to the Post leg
and Desktop first.
Special Note:
Location & number of cam pin, cam lock
and dowel holes may vary.
Side anel
Cherry/Maple/White
Peninsula Desks have a recessed support
Desktop
�·· ..
Figure //
)
. .
.
o . . ::"\
,
.
.
. .
.
i
\ _ , <N
,.
Ca\n Lock
\
. . . ,
_
. .
·
·
· · · ·-.. . . . . ·· ·-····· -�
5a) If you have a Cherry, Maple or White Peninsula Desk, your next
step will be to attach the Support/Side Panel assembly to the desktop
using the same hardware method.
5b) If you have a Mocha Peninsula Desk, your next step will be to
attach the Side Panel to the Support and Desktop.
6) Insert all Leveling Glides and with a helper, carefully turn the desk
upright.
7) Once in place, cover all Cam Locks with the Caps provided.
Questions? Please call 1-800-443-5117.
Customer Service available 8:30 - 5:00 Central Time, Monday - Friday
Side anel
Mocha Peninsula Desks have a full
support panel that attached to the post leg
D es op kt
with 3 cam pins amt 3 cam locks
j ; /\,
. ..
._
1
/ Camp}
\
i
..
)0
.
.......
/
,.
I
Wood D. DVJ el
·
J
· ·· · · ·.,-·
'
·
