Page 2
Welcome! The Greet Universal Smart Doorbell allows you to answer your door from any location. The Greet Universal is powered by an indoor chime, which is installed in the inside of your home. This quick start guide will help you configure your Greet Universal for initial use.
What’s in the box: Interchangeable Greet Universal / Screwdriver & Faceplate Indoor Chime Interchangeable (Only included in select configurations) Masonry Mounting Screws Spare Security Mounting Level & Anchors (x8) Drill Bit Screws Greet Universal Quick Start Guide Power Cable Power Adapter...
Page 4
0.8 inch in diameter. You will feed the provided power cable through this hole to connect the Indoor Chime and Greet Universal. Please see Figure 1. You will need to connect your Indoor Chime to a nearby power outlet using the provided power adapter.
Page 5
Drilling the power cable hole If you wish to install your Greet Universal at the location of your existing doorbell, please follow the steps below to drill the 0.8 inch hole for the power cable. IMPORTANT! Before you begin, make sure that the power to your doorbell is turned off.
Page 6
Mounting the Indoor Chime Remove the mounting bracket from your chime. Take your Indoor Chime out of the packaging and slide down to remove the mounting bracket as shown below: Slide down Mark and drill the appropriate holes in the wall for the mounting bracket.
Page 7
Fasten the mounting bracket onto the wall. Gently tap the wall anchors into the holes with a hammer until the anchors are flush against the wall. Using the Philips tip for the provided screwdriver and the provided screws, fasten the bracket into place. Feed the power cable through the 0.8 inch hole and connect the cable to the back of the Indoor Chime.
Page 8
Slide down Mounting the Greet Universal Remove the mounting bracket and plastic cover from your Greet Universal. Take your Greet Universal from the packaging and slide down to remove the mounting bracket, then pop off the plastic cover. Slide down...
Page 9
Snap the provided level onto the mounting bracket and align the bracket against the wall where you would like to install your Greet Universal. Make sure that the hole in the bracket lines up with the 0.8 inch hole that you drilled in the first part of the installation.
Page 10
Fasten the security screws and snap on the plastic cover. Tighten the two security screws on the bottom of the Greet Universal until secure, and snap the plastic cover onto the Greet Universal. Using the provided power adapter, power on the Indoor Chime.
Make sure you know the SSID (WiFi network name) and password of the 2.4GHz WPA-PSK/WPA2-PSK WiFi network that you want your Greet Universal to connect to. Your network cannot be hidden. Make sure your network has at least 2Mbps upload speed for each device when live viewing or 4Mbps upload speed for each device when using the Zmodo Cloud Service.
Page 12
This device can be set up with a Zmodo Beam. If you own a Connect with Beam, please follow the instructions in your Beam quick guide to Beam connect your device instead. Log in and press in the upper right corner. Select "Add Device".
Page 13
√ to proceed (If you’re setting up multiple devices at once, tap add additional units). Follow the on-screen instructions and select “Tap here to begin setup” to go to the WiFi settings page on your smartphone. Note: If you are using an iOS device, you will need to manually go to the WiFi settings page on your smartphone.
Page 14
Return to the Zmodo app page and select or enter the SSID and password of the WiFi network that you want your Greet Universal to connect to. Note: The WiFi name and password are case- sensitive. √ to proceed. If you see this screen, the app will connect your Greet Universal to your WiFi network.
Page 15
Tap to proceed. Note: The password provides an additional layer of security for your devices. You will not need to use this password when accessing your devices from the Zmodo app. It is not required, but it is highly recommended.
You can access your Greet Universal's full features by ® using the Zmodo app on your Android or iOS smartphone You can also view your Greet Universal using any web browser by logging into user.zmodo.com with your Zmodo account information.
Page 17
Universal's live view by swiping your finger to the left or right. Receive calls on your smartphone When someone rings Greet Universal, your Indoor Chime will sound and you will receive a call on your smartphone. You can choose to accept the call, decline it, or select a customized voice message to play for your visitor.
Page 18
Schedule notifications and record messages Schedule when to receive notifications and calls from Greet Universal in the device settings. You can also silence your chime for a restful night, and record up to 5 voice messages to play for visitors when you decide not to...
Page 19
Solid blue Your Greet Universal has successfully connected to the WiFi network. If you were unable to connect your Greet Universal successfully: Make sure that you are connecting to a 2.4GHz WPA- PSK/WPA2-PSK WiFi network, and that your network is not hidden.
Page 20
Support Having difficulty? You can use the Live Chat function in the Zmodo app if you have any technical problems. Please follow the steps below: Go to "Me" in the bottom right corner in Zmodo app and select "Zmodo Support".
