The Modular & Programmable Drone USER MANUAL...
Page 3
Table of Contents Downloading the Software Introduction to Stickers Parts List Aircraft Mode User Guide ·Operating Environment ·Items to Note ·Installation Steps ·Controls Introduction to Master Controller Module Hovercraft Mode User Guide ·Operating Environment ·Items to Note ·Installation Steps ·Controls Introduction to Battery Custom Mode User Guide ·Methods to Use ·Operating Environment...
Page 4
Downloading the Software A tablet or smartphone is required to control the Airblock. App Store Download Search "Makeblock" and install the application from app store. Official Website Download http://learn.makeblock.com/en/software/ Login to download the corresponding version of application. System and Device Requirements iOS devices (including iPhone5, iPad mini, iPad 3 or later models)need to support iOS 9.0 or...
Page 5
Parts List Battery Master Controller Module Charger Charging Cable Power Modules Hovercraft Base Protective Cover...
Page 6
Introduction to Master Controller Module The master controller module includes components such as Colored Light 6 power module plug-in sockets, 3 colored light indicators, Indicator ultrasonic sensor, barometer, gyroscope, Bluetooth, Front View microcontroller chip, etc. Ultrasonic sensor: for measuring distance. Works together with the barometer to sense the height change value of the aircraft.
Page 7
Battery Airblock does not have a power switch. When a battery with Battery sufficient power is inserted into master controller module, the master controller module automatically enters standby mode. When inserting battery into master controller module or battery charger, please ensure that the contact points are placed in the correct direction.
Page 8
Power Module Introduction to structure The Power Module is made up of parts such as the motor, Foot Pad Frame propellers, plug, frame, etc. Indicator light installed within the frame will light up when motor starts running. Motor The light indicator and foot pad of the aircraft head power module are red.
Page 9
Power Module Introduction to Operating Principles In order to offset the self-rotation of the aircraft, the propellers are classified as black clockwise rotating Direction of thrust Direction of thrust propellers and red counter-clockwise rotating propellers; the motors are classified as clockwise rotating and Clockwise rotation Counter-clockwise rotation...
Page 10
Power Module Installation Angle Each power module may be installed onto its corresponding port on the master controller module at 4 different angles. 180° 90° 270° Standard Angle...
Page 11
Power Module Port Numbers Install red propeller power module onto Port 1, 3, 5 respectively (aircraft head module with red foot pad will be installed onto Port 1). Install black propeller power module onto Port 2, 4, 6 respectively.
Page 12
Stickers Power Module Stickers Hovercraft Stickers Fuselage Stickers(Random gift. The picture is for reference only, please make the object as the standard.)...
Page 13
Stickers Power Module Stickers: Attach to the side of power module, in order to better distinguish the direction of fuselage in flight. It is recommended to attach red sticker to the aircraft head power module (Position 1) and green sticker to a black propeller power module (Position 4).
Page 15
Motor and propellers rotating at high speeds may cut people or animals, or become entangled in their hair or fur. Please move away from people and animals before operating Airblock. Dust, hair, fur, or water trapped in Airblock may result in motor malfunction or damage to electronic parts.
Page 16
Aircraft User Guide Installation Step 1 Installing the aircraft head power module Install aircraft head power module with red foot pad onto Port 1 of the master controller module. ! Note: If head module is installed in the incorrect position, it will not properly control the direction of flight.
Page 17
Aircraft User Guide Installation Step 2 Installing the other power modules Install the remaining power modules in sequence onto the master controller module.
Page 18
! Items to Note: Before actually taking off, please ensure Airblock has its top facing upward and is placed on flat ground. The picture on the right shows the bottom part of Airblock.
Page 19
New User Guide to familiarize yourself with paired automatically. If connection is not successful, tap the list the functions of the different keys and learn how to use Airblock. " " icon on the bottom right hand side of the touchscreen and select manually.
Page 21
Motor and propellers rotating at high speeds may cut people or animals, or become entangled in their hair or fur. Please move away from people and animals before operating Airblock. Dust, hair, fur, or water trapped in Airblock may result in motor malfunction or damage to electronic parts.
Page 22
Hovercraft User Guide Installation Step 1 Installing the battery Direction of battery contact points...
Page 23
Hovercraft User Guide Installation Step 2 Installing the protective cover Installation of protective covers is required in Hovercraft mode to protect propellers from damage and to prevent propellers from causing damage. Protective covers are required only on top part of the power modules at Port 1 and 4.
Page 24
Hovercraft User Guide Installation Step 3 Connect the aircraft head power module and a black propeller power module to Port 1 and 4 on the master controller module respectively.
Page 25
Hovercraft User Guide Installation Step 4 After connecting power modules to the master controller module, fit the master controller module onto the hovercraft hull. ! Note: Port 1 faces forwards (the smaller end of the hull is the bow) If the master controller module is installed in the incorrect direction, it will not be able to control the direction of the hovercraft.
Page 26
Hovercraft User Guide Installation Step 5 Protective covers are required on both the top and bottom parts of the other power modules. There are two types of protective covers; take note during installation. Bottom...
Page 27
Hovercraft User Guide Installation Step 6 After fitting the protective covers, attach the 4 power modules onto master controller module according to the directions in diagram below. Check that the protective covers are fitted in the accurate places and that the power modules are attached securely to the master controller module.
Page 28
Incorrect mode selection may distance to running Airblock, Bluetooth connection should be cause safety problems; pay attention! Software interface or icons paired automatically. If connection is not successful, tap the list may vary after each software update.
Page 29
Methods to Use You may connect the power modules to the master controller module at different angles and use the Airblock as a propeller and blower according to your own creativity. Propulsion forces in different directions and wind speeds of varying intensity may be achieved by setting the motor at different rotating speeds in the programming application.
Page 30
Land surfaces: it is best to use Airblock on smooth, flat, and level land surfaces. Water surfaces: only the hovercraft may be placed in the water. Use of Airblock in other forms on water surfaces must not be in contact with water. Dropping the Airblock into water by accident may result in fire damage due to a short circuit.
Page 31
Airblock. download and install the application. Open the Makeblock application and move tablet or smartphone within close distance to running Airblock, Bluetooth connection should be paired automatically. If connection is not successful, tap the list "...
Page 32
Custom Mode User Guide Step 3 In "DESIGN" mode, drag and drop required keys modules into the edit section on the right. Tap on the module to enter into "Code" mode. Step 4 In "Code" mode, drag the motor speed block to "When button pressed"...
Page 33
Common Problems Direction is incorrect Propellers are not spinning Poor connection Aircraft head module is installed in the wrong position 1. Check if the connection of the power module and master 1. When in Aircraft mode, if you encounter problems controller module is too widely-spaced, if connection is controlling the direction, check if aircraft head module with uneven, or if foreign matter is present.
Page 34
Common Problems Power supply indicator light does not light up Aircraft is unable to take off Battery has no power Power supply is insufficient Try again after charging battery for half an hour or longer. After successful connection to the application, you may check the power supply level in the control interface.
Page 35
Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device,pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
