- Page 1 User manual LED Quadscan 4x10W...
-
Page 2: Table Of Contents
Table of contents Safety instructions ..........................3 1.1. FOR SAFE AND EFFICIENT OPERATION ................3 Advantages ............................4 Operating ............................4 3.1. Display ............................. 4 DMX Chart ............................5 Technical Data ..........................7 2 / 7... -
Page 3: Safety Instructions
1. Safety instructions • This device is suitable for indoor use only. • All modifications to the device will void the warranty. • Repairs are to carry out by skilled personnel only. • Use only fuses of the same type and original parts as spare parts. •... -
Page 4: Advantages
Important: Damages caused by the disregard of this user manual are not subject to warranty. The dealer will not accept liability for any resulting defects or problems. Make sure the electrical connection is carried out by qualified personnel. All electrical and mechanical connections have to be carried out according to the European safety standards. -
Page 5: Dmx Chart
4. DMX Chart 9 Channel mode: Black out 8-200 Dimmer 201-247 Strobe 248-255 Full bright 1-255 RGBW color mixation 0-255 X-axis motor 0-255 Y-axis Motor Black out 8-255 Led lamp run effect 0-255 Led lamp run effect speed Black out 8-255 Motor run 0-255... - Page 6 12 channel Mode: Black out 8-24 first 25-41 Green head 42-57 Blue color 58-74 White 75-90 Red Green 91-107 Red Blue 108-123 Red White 124-140 Green Blue 141-156 Green White 157-173 Blue White 174-189 Red Blue Green 190-206 Blue Green White 207-222 Red Blue White 223-239...
-
Page 7: Technical Data
5. Technical Data Power supply AC 100 – 240 V 50/60Hz Power consumption 100W Lightsource 4 x 12W RGBW Cree LEDs Gobo measurements 20,5mm / 12mm visible 9 or 12 channels Measures 55 x 38 x 18,5 Weight 6,3kg Importer: B &...
