- Page 1 CS 550/150RC Towplow Spreader Joystick Controller Operator Manual...
-
Page 2: Table Of Contents
Error Codes Warning Bosch Rexroth Canada Corp. reserves the right to revise this information at any time and for any reason and reserves the right to make changes at any time, without notice or obligation, to any of the information contained in this piece of literature. The information shown in this manual features the latest version of software as of publication;... -
Page 3: Panel Controls
3/17 Panel Controls Turn knobs clockwise to increase. Bosch Rexroth Canada ı August.2018 ı Revision 2.0... -
Page 4: Operation Screen Layout
Spinner Label Solid Name Liquid Name Spread Width % Gate Mode/Solid Rate Liquid Rate Spinner Setpoint Gate Position/Conv Set. Liquid Setpoint Spinner Mode Conveyor Mode Liquid Mode Pause Button Blast Button Reverse Button Bosch Rexroth Canada ı August.2018 ı Revision 2.0... -
Page 5: Screen Controls
Press the Blast button to increase the spreading output, and press again to resume regular rate. 3.3 Reverse Press and hold the Reverse button to change the direction of the Auger (an optional feature to dislodge obstructions). Release the button to resume spreading. Bosch Rexroth Canada ı August.2018 ı Revision 2.0... -
Page 6: Change Solid /Prewet Material
For Manual Gate operation ONLY. Press the Gate Position Number to select the gate adjustment mode. Use the up and down arrows to adjust. Press the Gate Position again to verify the selection. Bosch Rexroth Canada ı August.2018 ı Revision 2.0... -
Page 7: Simulated Ground Speed
5. 3.7 Error Messages During the operation when an error occurs, a message will appear in the centre of the screen. Tap anywhere on the message to clear the window. Bosch Rexroth Canada ı August.2018 ı Revision 2.0... -
Page 8: Tow 3Boom Anti-Icing (Dla)
Boom Boom Boom ‘Gear’ To check the read-time status of the TOW 3Boom Anti-icing press the symbol at the top right of the screen when a vehicle is moving. Truck Status Status Bosch Rexroth Canada ı August.2018 ı Revision 2.0... -
Page 9: Symbol Actions
A program key is required to clear the error log; hold the button for >5 seconds. ‘Gear’ When a vehicle is moving press the symbol to display the real-time status of spreading. Bosch Rexroth Canada ı August.2018 ı Revision 2.0... -
Page 10: Unloading - Unload Symbol
It will automatically resume when the truck is stopped again. 4.3 Data Retrieval/Clear Trip Summary With a ‘LOG DATA KEY’ inserted ‘USB’ Press the symbol to transfer the log data. Bosch Rexroth Canada ı August.2018 ı Revision 2.0... -
Page 11: Brightness/Volume Adjustment - Backlight Symbol
‘Cylinder’ Press the symbol to select the gate adjustment mode. Use the up and down arrows to adjust. ‘Cylinder’ Press the symbol again to end the gate adjustment. 4.6 Sync /Programming Mode Bosch Rexroth Canada ı August.2018 ı Revision 2.0... -
Page 12: Programming Mode - Lock Symbol
(Note: Key needs to be removed) ‘Lock’ symbol to enter into programming mode. (Note: A valid ‘PROGRAMMING Press the KEY’ must be inserted into the USB port.) See Calibration Manual for programming details. Bosch Rexroth Canada ı August.2018 ı Revision 2.0... -
Page 13: Operator Id Input
Screen flips when the Deadman Trigger is pressed. When the trigger is released, the screen reverts back to the spreader layout. Note: The joystick will only operate while the Deadman Trigger is pulled. The default spreader or joystick screen is selectable on USER setup screen. Bosch Rexroth Canada ı August.2018 ı Revision 2.0... -
Page 14: Button Status
When the “R” button is pressed the controller would ramp down the spinner from the speed selected and ramp up to the opposite direction to the speed selected. Bosch Rexroth Canada ı August.2018 ı Revision 2.0... -
Page 15: Air Gate Mode
ERROR NO LIQ DETECT Load material, check sensor ERROR NO GROUNDSPEED Check cable/sensor ERROR NO CONVEYOR Check cable/sensor ERROR NO LIQUID Check cable/sensor ERROR NO DEICE Check cable/sensor Warning Messages Suggested Solution Bosch Rexroth Canada ı August.2018 ı Revision 2.0... - Page 16 PREWET PULSES/GAL TOO LOW Check prewet sensor, and calibrate again PREWET PULSES/GAL TOO HIGH Check prewet sensor, and calibrate again ANTI-ICING PULSES/GAL TOO LOW Check anti-icing sensor, and calibrate again Warning Messages Suggested Solution Bosch Rexroth Canada ı August.2018 ı Revision 2.0...
-
Page 17: Warning
If the glass chips or cracks, discontinue use and contact Bosch Rexroth Canada to have it replaced - do not touch or attempt to remove the broken glass. Any misuse/abuse causing damage, whether intended or not, will become the sole responsibility of the owner/buyer which will render the warranty of this product, void.
