- Page 1 MT7010 User’s Manual...
-
Page 2: Table Of Contents
....................................9 NVIRONMENT ....................................10 I/O P ORTS ................................ 11 IMENSION AND EIGHT MT7010 Standard ..................................11 .................................... 12 ACKAGE CHAPTER 2. HARDWARE MOUNTING ......................13 CHAPTER 3. START UP ............................14 ................................ 14 OWERING THE YSTEM Connector Power ..................................14 Power source from car power cable .......................... - Page 3 MT7010 ........................ 21 XTERNAL ONNECTORS SSIGNMENTS Power Connector ..................................21 RS-232 Port ....................................22 USB and RS-232/422/485 Port ............................23 GPIO and CANbus Port ................................24 V1.0...
-
Page 4: Safety Precautions
MT7010 Safety Precautions Read these safety instructions carefully. Keep this user’s manual for later reference. Disconnect this equipment from any AC outlet before cleaning. Use a damp cloth. Do not use liquid or spray detergents for cleaning. ... - Page 5 MT7010 d. The equipment does not work well, or you cannot get it to work according to the user’s manual. e. The equipment has been dropped and damaged. f. The equipment has obvious signs of breakage. 16. Do not place heavy objects on the equipment.
-
Page 6: Regulatory And Certification
MT7010 Regulatory and Certification This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation. -
Page 7: Ce Marking
MT7010 RF exposure warning This equipment must be installed and operated in accordance with provided instructions and the antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. -
Page 8: Chapter 1. Product Introduction
MT7010 Chapter 1. Product Introduction MT7010 is the in-vehicle terminal with 7” high resolution display with 500nits brightness and flexible to expand varied wireless connection capability designed, it’s for the fleet management, asset management, EOBR and ELDs application. This includes ISO 7637-2, SAE J1455 and SAE J1113 compliance and optimized power system design for cold cranking, load dump, transient voltage and ESD. -
Page 9: Operating System Support
MT7010 Operating System Support Android 5.1 Environment Operating temperature: -20°C (-4°F) to 60°C (140°F) In accordance withMIL-STD-810G CHANGE1 Method 501.6 High Temperature Procedure II - Operation In accordance with MIL-STD-810G CHANGE1 Method 502.6 Low Temperature Procedure II –... -
Page 10: I/O Ports
MT7010 I/O Ports Item Description 1 x RS-232 (RX, TX)/422/485, non isolation (COM1) Serial RS-232, with 5V/600mA & 12V/300mA x 1 (COM2) USB 2.0 for host A-type connector (500mA) x 1 Ethernet Gigabit RJ45 x 1 DI/ DO x 2... -
Page 11: Dimension And Weight
MT7010 Dimension and Weight MT7010 Standard Dimension: 219.98 x 151.98 x 40.8mm / 8.66 x 5.98 x 1.60in. (W x H x D) Weight: 1.25 kg/ 2.76 lbs. Front View Dimension Side View Dimension V1.0... -
Page 12: Package List
Contact your representative if there are any missing or damaged items. Please verify the delivery of the contents upon receipt MT7010 in-vehicle terminal Bare wire power cable with circular power code NOTE: The packaging material has been selected to optimally protect your device. After unpacking, store the original packaging material in the event that you need to return shipment. -
Page 13: Chapter 2. Hardware Mounting
MT7010 Chapter 2. Hardware Mounting The MT7010 supports a standard VESA version MIS-D, 75, C (75mm distance quadrate order, M5 thread, deepness 6mm) through the four drill holes on the back side of the device. Notes: To prevent any damage or injury, make sure the mounting bracket is securely attached. -
Page 14: Chapter 3. Start Up
Powering the System Connector Power MT7010 allows a wide range of DC power input from 9~36V via a 5-pin M12 A-code power cord. There are two options to start up the MT7010 via car power cable or external power adapter. - Page 15 Top of the arrow mark 3. Twist the nut to lock the power connector to the device. 4. MT7010 will turn on automatically when the power supply is connected to the device. Power source from external power adapter If your power source is from external power adapter, the mean the power source doesn’t control by AAC/Ignition signal.
-
Page 16: Powering Down The System
MT7010 Powering Down the System MT7010 will be auto power off after one minute when the power supply is removed. If you use software to power off the system, please remember to remove the power supply too; otherwise, the device will auto reboot again. -
Page 17: Led Status
MT7010 LED Status The LEDs on MT7010 are status indicators that show the operating status of your system. The status indicators can help pinpoint possible failed hardware components causing specific symptoms. There are two status indicators in the front panel. Refer to the description below. -
Page 18: Adjust The Speaker Volume
When you are using MT7010, you may well encounter different lighting conditions that make it difficult to see the information on screen. MT7010 is built-in the ambient light sensor on the front panel to supports auto-dimming, you also can disable this function and manually adjust the brightness, the setting can be done via DashON. -
Page 19: Internal Microphone
Display turn on/off Internal MIC-in Power Management In additional to setting in Windows Control Panel, MT7010 also provide the utility, DashON, to set the configuration including power management and system setup. Please refer the Chapter 6 for configuration setting in DashON. -
Page 20: Chapter 4. Jumpers And Connectors
MT7010 Chapter 4. Jumpers and Connectors Bottom View Power Input Connector RS-232 with PWR GPIO, CANBus GPS Antenna Connector (SMA Jack) (COM1) USB, RS-232/422/485 (COM2) USB 2.0 V1.0... -
Page 21: External Connectors Pin Assignments
MT7010 External Connectors Pin Assignments Use this section as a reference for the pin assignments of the various ports available on the MT7010. Power Connector Signal ACC/ Ignition Note: Please refer the Chapter 4 section 1 for the external power cable to connect to power source. -
Page 22: Rs-232 Port
MT7010 RS-232 Port Signal Description Data carrier detect (input) Receive data (input) Transmit data (output) Data terminal ready (output) Signal/power ground Data set ready (input) Request to send (output) Clear to send (input) RI / PWR Bar code scanner power (1 A max) or Ring indicator (input) -
Page 23: Usb And Rs-232/422/485 Port
USB and RS-232/422/485 Port Signal RS-422 TX+ RS-422 RX+ RS-485 TX+ RS-232 TX RS-422 TX- RS-422 RX- RS-485 TX- USB 5V RS-232 RX USB DP USB DM USB 5V We provide Y-cable with DB15 male connector is the RS232/422/485 and USB converter. Please contact your local representative for ordering information... -
Page 24: Gpio And Canbus Port
GPIO and CANbus Port Signal CAN_H WHEELTICK CAN_L CARD POWER DIO_OUT1 (5V 10mA) DIO_IN1 (5V 100mA) DIO_IN2 (5V 100mA) DIO_OUT2 (5V 10mA) We provide the DB15 male connector to multiple pins without termination cable. Please contact your local representative for ordering information...
