Bondline SL3 Instruction Manual

SL3 Electrostatic Field Meter
SL3 fieldmeter is an accurate, compact electrostatic fieldmeter used for location
and measuring static charge potentials

Features:

● Pocket Size convenience
● Sample and hold measurements modes
● Distance ranging lights
● Conductive case and ground snaps
● Digital Display
● 9 Volt Battery powered
● Analog Output
● Designed for use in ionized areas
The fieldmeter features both SAMPLE and HOLD measurements modes that allow
measurements to be made in places that would be difficult to reach or see with other
instruments. A set of ranging lights ensure accurate and repeatable measurement. No
range switching is required as the digital display covers the range of 0 to + 19.99
kilovolts. An analog output jack provides a 1 volt output corresponding to a 10
kilovolt reading on the meter display. The circuitry has been designed to make
accurate measurements in areas using air ionization.

Operation:

1. Controls: The model S2001 fieldmeter has a slide switch for ON/OFF and a
push button switch for modes. The ZERO knob can be turned to the left or
right to change the zero settings of the display.
2. Turning the meter on and off: Push the slide switch actuator into its upper
(ON) position. The display will come on. To turn the meter OFF, slide the
switch down to its lower (OFF) position. The display should now turn off.
3. Battery check: After turning on power to the meter, check the display and
make sure that the low battery indicator BAT is not showing on the display. If
the BAT indicator is lit, replace the battery as described below before using
the meter.
4. Zero the meter: Turn on the meter with the on/off switch. Put the meter in the
SAMPLE mode (up position). Place the meter 1 inch from a GROUNDED
metal surface. If necessary, adjust the ZERO control until the display reads
zero.
