- Page 1 Infoblox Installation Guide for Infoblox IB-4010 Platforms Network Insight ND-4000 Platform...
-
Page 2: Table Of Contents
1.5 Network Insight ND-4000 Hardware Components ............13 2. Installing the Infoblox-4010/Network Insight ND-4000 . -
Page 3: Introduction
Both Infoblox-4010 Rev-1 and Rev-2 appliances support the same NIOS features. They are different in physical appearances and CPU speeds. You can identify the Infoblox-4010 version by looking at its physical appearance and the serial number in which Rev-1 starts with a 40 prefix and Rev-2 with a 4835 prefix. - Page 4 The front panel components are described in Table 1 Table 1 Front Panel Components for Infoblox-4010 Rev-1 Component Description UID LED and The unit identification button and LED. Button Note: Pressing the UID button illuminates the blue UID LEDs on the front and rear panels. In a rack environment, the UID feature enables easier location of a server when moving between the front and rear of the rack.
- Page 5 The Infoblox-4010 Rev-1 provides four (4) RJ-45 Gigabit Ethernet interfaces that operate as Infoblox MGMT port, LAN1 port, High Availability (HA) port and LAN2 port in the Infoblox system. It also provides an option for four (4) SFP ports. With the SFP ports installed, the RJ-45 ports on the rear of the Infoblox-4010 chassis will be deactivated.
- Page 6 Minimum: -3 dBm Optical Receive Sensitivity Maximum: -20 dBm Figure 4 for optical port assignments in the Infoblox-4010 system. Port assignments are Infoblox-specific and are also described in Table 3 elow. Figure4 Infoblox-4010 Rev-1,RearViewwithSFP1GbE Interfaces SFP LAN1, LAN2, HA and MGMT ports operate as described in Table 3 .
- Page 7 An RJ-45 or SFP Gigabit Ethernet port that connects a NIOS appliance to the network. The LAN2G port is not enabled by default. You can enable the LAN2 port and define its use through the Infoblox GUI after initial setup.
- Page 8 Infoblox-4010 Rev-1 System, Environmental, and Power Specifications System specifications describe the physical characteristics of each appliance. Environmental specifications describe the temperature and moisture limits it can withstand. Power specifications describe the electrical range within which the appliance circuitry can operate.
-
Page 9: Infoblox-4010 Rev-2
Infoblox-4010/Network Insight ND-4000 The Infoblox-4010 Rev-2 front panel comes with an optional front cover that you can install when you first set up the appliance. Refer to the installation instructions that ship with each system for information about how to install the front cover. - Page 10 LEDs through their color and illumination (steady glow or blinking). Figure 8 Ethernet Port LEDs (inc. SFP+ interfaces where noted) Infoblox-4010 Rev-2 Disk Drive Front Panel LEDs Disk drives are located on the appliance front panel. To the right of each drive, two LEDs display connection and activity status.
- Page 11 Infoblox-4010 Rev-2 Rear Panel The Infoblox-4010 Rev-2 appliance offers a choice of dual AC power supplies, or dual DC power supplies with or without NEBS-3 compliance. In all cases, power supplies are hot swappable; any single power supply can be replaced without disrupting the operations of the appliance.
- Page 12 10GbE optical or copper connectivity. In select configurations, Infoblox 1GbE SFP or 10GbE SFP+ ports replace the functionality in the original system MGMT, LAN1, HA and LAN2 ports, thereby disabling the original system MGMT, LAN1, HA and LAN2 ports.
-
Page 13: Network Insight Nd-4000 Product Overview
The Network Insight ND-4000 provides three (3) RJ-45 Gigabit Ethernet interfaces that operate as the MGMT port, LAN1 port and LAN2 port in the Infoblox system. (The HA port is inactive and cannot be used for networking applications.) The three port assignments are from left to right... - Page 14 In all cases, Network Insight appliances use the LAN1 and LAN2 ports for connectivity to networks for device discovery, and the MGMT port is reserved for appliance management. In select configurations, Infoblox 1GbE SFP or 10GbE SFP+ ports replace the functionality in the original system MGMT, LAN1, HA and LAN2 ports, thereby disabling the original system MGMT, LAN1, HA and LAN2 ports.
- Page 15 Dedicated Ethernet port used for LOM (integrated Lights Out Management) with specific releases of NIOS. Ensure that the IPMI Port port is properly connected to the network before you configure LOM through the Infoblox GUI for remote management. VGA Port This port is not supported.
-
Page 16: Installing The Infoblox-4010/Network Insight Nd-4000
Minimum clearance of 121.9 cm (48 in) from the back of the rack to the back of another rack or row of racks The Infoblox appliance draws air in through the front of the chassis and expels air through the rear. Adequate ventilation is required to allow ambient room air to enter the system chassis and to be expelled from the rear of the chassis. - Page 17 10. Snap the Infoblox-4010 appliance into place, and fasten it to the rack using the retainer screws provided in the accessory kit. (For further information, refer to the instructions shipped with the accessory kit.) 11.
-
Page 18: Ground Lug Installation (For Dc Power Supply Only)
Guide. The ground lug, with two star washers, is provided in the accessory kit bundled with the Infoblox appliance. The star washers are used with the ground lug to ensure a snug fit. To install the ground lug, do the following: Remove the ground lug nut from the rear of the chassis. -
Page 19: Accessing The Appliance
MGMT, and LAN2 ports do not have default network settings). To change these settings to suit your network, use the console port. Console Port The Infoblox appliance has a male DB-9 console port on the rear panel. You can log in to the appliance through this port and specify initial network settings using the Infoblox CLI. -
Page 20: Auto Provisioning Nios Appliances
Failure to do so may result in damage to the serial console port of the Infoblox appliance. Infoblox is not responsible for such damage. Connect a console cable from the console port of the management system to the console port of the Infoblox appliance. -
Page 21: Specifying Appliance Settings
You can deploy appliances individually or in an HA (high availability) pair, for hardware redundancy. A single appliance or an HA pair without a Grid license runs independently from a grid. A grid is a group of two or more Infoblox appliances that share sections of a common, distributed, built-in database and which you configure and monitor through a single, secure point of access —... -
Page 22: Infoblox Gui
You can view data and configuration settings and make configuration changes through the Infoblox GUI. When an Infoblox appliance functions as an independent appliance, you launch System Manager to access the Infoblox GUI. When the appliance is in a grid, you log in to the grid master and launch Grid Manager. -
Page 23: Infoblox Cli
.) You can also enable remote console access — that is, SSHv2 (Secure Shell version 2) access — through the Infoblox GUI or CLI, and then access the CLI from a remote location using an SSHv2 client. (For more information, refer to the... -
Page 24: Field Replaceable Units
Note: Infoblox-4010 Rev-1 hardware and FRUs (field replaceable units), such as power supplies and fan units, are not compatible with Infoblox-4010 Rev-2 hardware and FRUs, and vice versa. Ensure that you use the correct FRUs for your Infoblox-4010 version. For information... - Page 25 The Infoblox GUI also displays detailed status of the RAID array. In the event of a disk failure, you must replace the failed disk with one that is qualified and shipped from Infoblox and has the same disk type as the rest of the disks in the array.
-
Page 26: Hard Disk Replacement
24 hours. Replace a failed or mismatched disk only with a replacement disk shipped from Infoblox. When you request a replacement disk, report the disk type displayed in the Detailed Status panel of the Infoblox GUI or the Infoblox part number on the disk. -
Page 27: Changing Ac Power Supplies
When a power supply fails for any reason, NIOS displays a power supply alarm. The Infoblox NIOS Dashboard will also display an error under Grid Status. The appliance also sens an email notification and an SNMP trap. -
Page 28: Changing Dc Power Supplies
Changing DC Power Supplies In their DC power configuration, the Infoblox-4010 and Network Insight ND-4000 ship with two redundant, auto-switching DC power supplies. The power supplies are "hot-swappable", so you can remove or replace one power supply without interrupting appliance operation and network services. -
Page 29: Internal System Fan Replacement
Rev-1 or Rev-2 Infoblox-4010 or Network Insight ND-4000 appliances. Note: The IB-4010 appliance reports all system fans, numbered 1 through 6, as individual units, and each fan may be individually replaced as needed. Each fan is numerically labeled inside the chassis. - Page 30 Figure 27 Gently pull latch to remove top panel for Infoblox-4010 Rev-2/Network Insight ND-4000 5. Slide the top panel off and visually inspect the fans to determine which unit has stopped spinning and must be replaced. 6. Figure 28 shows a six-fan-module configuration on the Rev-1 appliance, and...
- Page 31 7. Place the new fan in the system. Note that the fans can be installed correctly in only one direction, as shown in Figure 30 Figure 31 Figure 30 Fan blades point towards rear of chassis for Infoblox-4010 Rev-1 Copyright ©2018, Infoblox, Inc.All right reserved.
-
Page 32: Ib-4000/Nd-4000 Series Replaceable Units
8. Replace the top lid of the system and replace it in the rack before restoring power. IB-4000/ND-4000 Series Replaceable Units Table 10 lists field replaceable units for the Infoblox 4000 Series Rev-1 appliances. Contact your Infoblox field representative or Infoblox Technical Support for more information. Table 10 Field-Replaceable Unit Part Numbers for IB-4010 Rev-1 (only) -
Page 33: Ib-4000/Nd-4000 Series Sfp/Sfp+ Transceivers
Infoblox IB-4000 Series fan set (Rev-2) IB-4000-R2-FAN FRU only *TR-4000 is the Trinzic Reporting 4000 appliance. For information about the appliance and its specifications, refer to the Infoblox Installation Guide for the Trinz ic Reporting 4000 Appliance IB-4000/ND-4000 Series SFP/SFP+ Transceivers Infoblox offers SFP/SFP+ transceivers of various types for 1GbE and 10GbE networking applications.
