- Page 1 High Capacity Electronic Balances BH350 & BH370 Impact Test Equipment Ltd www.impact-test.co.uk & www.impact-test.com User Guide User Guide...
- Page 2 Impact Test Equipment Ltd. Building 21 Stevenston Ind. Est. Stevenston Ayrshire KA20 3LR T: 01294 602626 F: 01294 461168 E: sales@impact-test.co.uk Test Equipment Web Site www.impact-test.co.uk Test Sieves & Accessories Web Site www.impact-test.com...
- Page 3 INSTRUCTION MANUAL Explorer Pro Balances...
- Page 4 Ohaus Corporation, 19A Chapin Road, Pine Brook, New Jersey, 07058-9878, USA Declaration of Conformity We, Ohaus Corporation, declare under our sole responsibility that the balance models listed below marked with “CE” - are in conformity with the directives and standards mentioned. Konformitätserkärung Wir, die Ohaus Corporation, erklären in alleiniger Verantwortung, dass die untenstehenden Waagentypen, gekennzeichnet mit “CE”...
- Page 5 Notice Certified scales,scales used for legal applications have the general type designation E...5 / V...5 and EU type Approval (T2914). The year of the initial verification is shown next to the CE mark. Such scales are verified in the factory and carry the "M" mark on the actual scale and the packaging.
- Page 6 NOTE: THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS A DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES. THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A COMMERCIAL ENVIRONMENT.
-
Page 7: Table Of Contents
TABLE OF CONTENTS OVERVIEW OF CONTROLS .......................... 1 GETTING TO KNOW YOUR BALANCE ......................2 Introduction ............................... 2 INSTALLATION ............................2 Unpacking and Checking the Standard Equipment ..................2 Selecting the Location ..........................3 Setting Up and Leveling the Balance ......................3 Connecting Power ............................ - Page 8 TABLE OF CONTENTS (Cont.) 3.14.3 Improving the Accuracy of the Result of Solid Density Determinations ............. 31 3.14.4 Liquid Density Determinations ........................31 3.15 Library ..............................32 3.16 Printing Data ............................33 SETTING UP YOUR BALANCE ........................35 Readout ..............................35 Interface ..............................
-
Page 9: Overview Of Controls
Explorer Pro OVERVIEW OF CONTROLS On/Off WEIGHT 100% Go Back Help Print Enter GRAMS STABLE MOVE HIGHLIGHT MAIN MENU CONTRAST CONTRAST Designation Function LCD display on off button. Go Back button Permits going back in menus. Help button Provides additional information on subject displayed in the current menu. Print button When pressed, prints data either on an external printer or computer. -
Page 10: Getting To Know Your Balance
Explorer Pro GETTING TO KNOW YOUR BALANCE Please read through this section carefully, as it contains important information for safe and economical operation of your Explorer Pro Balance. Introduction Thank you for deciding to purchase a Explorer Pro Balance from Ohaus. Thanks to a new modular design, your Explorer Pro Balance lets you adapt the balance to your changing needs. -
Page 11: Selecting The Location
Explorer Pro Selecting the Location The balance should always be used in an environment which is free from excessive air currents, corrosives, vibration, and temperature or humidity extremes. These factors will affect displayed weight readings. DO NOT install the balance: •... -
Page 12: Connecting Power
Explorer Pro Connecting Power Connect the AC Adapter supplied to the three pin connector located at the left side of the balance. The balance is now ready for operation. AC Adapter Connection Left Side of Balance... -
Page 13: Operating Your Balance
Explorer Pro OPERATING YOUR BALANCE Main Menu The Explorer Pro Balance has one main menu from which all selections are made. Shown below is the normal weighing display screen and the main menu screen. On/Off On/Off MAIN MENU WEIGHT 100% Go Back Go Back CHANGE MODE... -
Page 14: Turning On The Balance
Explorer Pro Turning On the Balance The Explorer Pro Balance is ready to operate after the the installation procedures are performed. When the balance is first turned on and it completes its checks, and is calibrated, it can be used to weigh or tare materials without setting the menus. The balance is preset at the factory to weigh in grams. -
Page 15: Auto Calibration (Autocal )
Explorer Pro 3.3.1 Auto Calibration (AutoCal On Explorer Pro Balances equipped with the AutoCal feature, calibration can be accomplished using an internal calibration mass. Auto calibration can be performed at any time providing the balance has warmed up to operating temperature. PROCEDURE •... -
Page 16: Span Calibration
Explorer Pro 3.3.2 Span Calibration Span calibration normally requires that calibration be made using a mass equal to the full capacity of the balance, however, the Explorer Pro Balance can be calibrated using other lesser values as specified on the display. PROCEDURE •... -
Page 17: Linearity Calibration
Explorer Pro 3.3.3 Linearity Calibration Linearity calibration utilizes three calibration points, one at zero, center span and full span. This method minimizes deviation between actual and displayed weights within the balance's weighing range. Three weight values are used; zero, a weight value at midpoint of the balance's weighing range and a weight value at or near the specified capacity. -
Page 18: User Calibration
Explorer Pro 3.3.4 User Calibration User calibration is used when it is desired to calibrate the balance using a mass of known value. To use this calibration feature, proceed as follows: PROCEDURE On/Off • Press arrow button to select MAIN MENU. WEIGHT Go Back 100%... -
Page 19: Calibration Test
Explorer Pro 3.3.5 Calibration Test Calibration test feature allows a check of a known calibration mass against the last stored calibration information in the balance. The sample displays shown are for a 12 kilogram balance. PROCEDURE • Press arrow button to select MAIN MENU. On/Off WEIGHT Go Back... -
Page 20: Setting Measuring Unit
Explorer Pro Setting Measuring Unit Before using the balance for the first time, the desired measuring unit should be set first. The following measuring units are available: GRAMS, KILOGRAMS, PENNY WEIGHTS, CARATS, OUNCES, TROY OUNCES, MOMMES, GRAINS, HONG KONG TAELS, SINGAPORE TAELS, ROC TAELS, NEWTONS, TICALS and CUSTOM UNITS. -
Page 21: Custom Unit
Explorer Pro 3.4.1 Custom Unit Custom Unit is enabled when Custom Units is selected under the Change Units menu. This feature can be used to create your own custom weighing unit. It permits entering a conversion factor which the balance will use to convert grams to the desired unit of measure. - Page 22 Explorer Pro 3.4.1 Custom Unit (Cont.) Procedure (Cont.) MAIN MENU CHANGE UNITS GRAINS SELECT CUSTOM UNIT • Press arrow button and select CUSTOM UNIT 1. HONG KONG TAELS CUSTOM UNIT 1 SINGAPORE TAELS CHANGE UNITS CHANGE MODE SET BALANCE CUSTOM UNIT 2 ROC TAELS CUSTOM UNIT 3 •...
- Page 23 Explorer Pro 3.4.1 Custom Unit (Cont.) Procedure (Cont.) • Press arrow button and select LSD. MAIN MENU CHANGE UNITS • Press Enter button,SELECT LSD is displayed. There are 6 GRAINS SELECT CUSTOM UNIT LSD (least significant digit) settings you can choose from HONG KONG TAELS CUSTOM UNIT 1 CUSTOM UNITS...
-
Page 24: Basic Weighing
Explorer Pro Basic Weighing Explorer Pro Balances are shipped with grams enabled. When the balance is to be used with other Type Approved/Legal for Trade units of measure, the desired unit must be enabled. For weigh below applications, refer to section on Density measurements. MAIN MENU On/Off WEIGHT... -
Page 25: Parts Counting
Explorer Pro Parts Counting The Explorer Pro Balance can be set to either an Easy Count or Advanced Count parts counting method. Easy Count setting enables a simplified method for counting parts. When selected, Easy Count displays a screen which requires that the number of sample parts be entered. -
Page 26: Advanced Counting
Explorer Pro 3.6.2 Advanced Counting Advanced Count setting contains a number of entry screens which include assigning a library name, filling and sorting applications and statisical information which can be printed. Refer to screen 4 below which contains the LIBRARY NAME - A name up to 10 characters can be entered and stored to identify the item to be counted. -
Page 27: Filling
Explorer Pro Filling Filling or Fill weighing permits you to enter a target weight, then view other loads as a percentage of the reference which has been set in the balance parameters. The load you place on the platform is displayed as a percentage of what was entered into the balance. -
Page 28: Animal Weighing
Explorer Pro Animal Weighing Animal weighing permits you to weigh small animals directly on the balance. To compensate for active subjects, a setup menu permits you to enter a smoothing filter labeled Good, Better and Best which averages the subjects movements and displays an accurate weight. -
Page 29: Check Weighing
Explorer Pro Check Weighing Check weighing mode permits you to weigh an item, set balance parmeters such as the nominal weight, over weight, under weight and assign a library name. This can then be recalled later eliminating the need to enter weighing parameters again. This type of weighing is where individual items must be checked against preset parameters. -
Page 30: Differential Weighing
Explorer Pro 3.10 Differential Weighing Differential weighing stores tare and weight values so a sample can be dried and the difference calculated at a later time. Up to 5 batches with up to 80 samples per batch can be stored. Samples can be added to the applications library. Batch and individual samples can be accommodated. - Page 31 Explorer Pro Procedure (Cont.) 3.10 Differential Weighing (Cont.) First, the container is tared and stored, then the product is Initial Weighing intially weighed in the container and stored for each sample. DIFF WEIGHING - - NAME -- SAMPLE 1 A name is given to the samples which is stored in the balance. After all samples have been weighed and entered, a summary 100% table indicates the weight of the containers and each sample.
-
Page 32: Formulation
Explorer Pro 3.11 Formulation The Explorer Pro Balance can store between 200 minimum and 500 formulations limited only by the memory capacity of the resident library. Each formulation can be named and have up to 10 components specified and identified by name. Once the formulations are stored in the balance library, they may be recalled and used at any time. - Page 33 Explorer Pro 3.11 Formulation (Cont.) Procedure (Cont.) FORMULATIONS BY WEIGHT (cont.) MAIN MENU CHANGE MODE • Press Enter button, a NAME menu appears with the value FORMULATION BASIC WEIGHING shaded. FORMULA SETUP PARTS COUNTING SETUP FILL CHANGE MODE CHANGE UNITS SET BALANCE LIBRARY NAME MAIN MENU...
- Page 34 Explorer Pro 3.11 Formulation (Cont.) Procedure FORMULATIONS BY PERCENTAGE Formulations can be done by using percentages instead of weight values. See page 21 and repeat procedure up to where screen choice for WEIGH TYPE is displayed. Then continue as follows: •...
-
Page 35: Quick Check Weighing
Explorer Pro 3.12 Quick Check Weighing Quick check weighing permits you to place a reference sample or a sample weight on the balance pan which is used as a reference weight to measure against similar samples. A single bar display indicates up to 100% of the capacity of the balance, the difference in weight between the original sample and suceeding samples is displayed. -
Page 36: Statistics
Explorer Pro 3.13 Statistics Statistics is used when it is desired to compare a number of samples and examine the relative deviation of the samples along with other statistical data such as mean, sum, maximum and minimum and difference. A minimum of three samples is required in this program. -
Page 37: Density
Explorer Pro 3.14 Density Density determinations of solids and liquids can be made with the Explorer Pro Balance. The Explorer Pro Balance contains built in reference density tables for water and ethanol at temperatures between 10 °C and 30 °C. It is not necessary to refer to any external tables to calculate density. - Page 38 Explorer Pro 3.14 Density (Cont.) 3.14.2 Solid Density Determinations (Cont.) Procedure • Press arrow button to select MAIN MENU. On/Off WEIGHT • Press Enter button. 100% Go Back • Using the arrow buttons, select CHANGE MODE. Help • Press Enter button. Print Enter •...
-
Page 39: 3.14.3 Improving The Accuracy Of The Result Of Solid Density Determinations
Explorer Pro 3.14 Density (Cont.) 3.14.3 Improving the Accuracy of the Result of Solid Density Determinations The following tips should help you improve the accuracy of the results in the density determination of solids. Temperature Solids are generally so insensitive to temperature fluctuations that the corresponding density changes are of no consequence. However, as work is performed with an auxiliary liquid in the density determination of solids, their temperature must be taken into account as the temperature has a greater effect with liquids and causes density changes in the order of magnitude 0.1 to 1% per °C. -
Page 40: Library
Explorer Pro 3.15 Library The Explorer Pro Balance can store approximately 200 names in the library. Six functions in the balance have provisions for storing a library name, they are: Advanced Counting, Check Weighing, Differential Weighing, Formulation, Density and SQC. When a library name is selected, the associated function is also displayed along with the percentage of memory used for the entry. -
Page 41: Printing Data
Explorer Pro 3.16 Printing Data Printing data to an external computer or printer requires that the communications parameters be set first. Refer to Section 4, Setting up Your Balance. Procedure • Press the Print button. Printing to an external printer or On/Off WEIGHT computer will occur each time the Print button is pressed... - Page 42 Explorer Pro 3.16 Printing Data (Cont.) SAMPLE PRINTOUTS Span Calibration Printout When performing a Span calibration, a printout is automati- - - - - - SPAN CAL - - - - - - cally made after the calibration mass is placed on the pan and 7/01/97 1:00:00 PM the Print button is pressed.
-
Page 43: Setting Up Your Balance
Explorer Pro SETTING UP YOUR BALANCE The Explorer Pro Balance has ten menus under SET BALANCE which AUTOCAL - Function can be set ON or OFF. are listed as follows: PRINT CURRENT SETTINGS - When selected, print data to external READOUT - User menu is used to adapt the balance to environmental printer or computer. -
Page 44: Interface
Explorer Pro Interface The Interface menu enables you to set the balance communication parameters for an RS 232 interface. The baud rate, data bits, parity and stop bits can be set to match the communication requirements of external printers or computers. Procedure On/Off •... -
Page 45: Print Option
Explorer Pro Print Option The Print Option menu contains various print features which can be set ON or OFF and include Auto Print, Stable Data only, Numeric Data only, Date, Time and Reference data. Procedure Auto Print On/Off WEIGHT When enabled, Auto Print causes the balance to automatically output display data in one of three ways: continuously, at user Go Back 100%... - Page 46 Explorer Pro Print Option (Cont.) Procedure MAIN MENU Numeric Data When set ON, only numeric data will be output. SET BALANCE CHANGE MODE CHANGE UNITS MAIN MENU SETUP BALANCE • Press arrow button to select MAIN MENU. READOUT INTERFACE CALIBRATION LIBRARY CUSTOM MENU PRINT OPTION...
- Page 47 Explorer Pro Print Option (Cont.) Procedure MAIN MENU Print Time When Print Time is turned ON, current time will be output to the CHANGE MODE CHANGE UNITS SET BALANCE MAIN MENU SETUP BALANCE printer. READOUT INTERFACE PRINT OPTION CHANGE MODE CHANGE UNITS SET BALANCE •...
-
Page 48: Setup Glp
Explorer Pro Setup GLP Setup GLP (Good Laboratory Practices) menu allows the selection of Time & Date, Balance Identification Number, Project On/Off WEIGHT Name, User Name and Calibration data to be printed. The pur- pose of this menu is to permit the printing of the above select- Go Back 100% ed items. -
Page 49: Set Time/Date
Explorer Pro Set Time/Date Permits entering time and date into the balance. A battery backup is used for the memory, time and date information. The life of the battery is up to five years. Time and date information appears on printed data and to an external computer when connected to the balance. -
Page 50: Auto Calibration
Explorer Pro Auto Calibration Automatic calibration of the balance can be accomplished when equipped with this option. On balances which do not contain AutoCal , the automatic calibration function is inoperative. On balances equipped with AutoCal , a second screen permits turning this function ON or OFF. -
Page 51: Print Current Settings
Explorer Pro Print Current Settings When this function is selected, and the Enter button is pressed, all settings which were made in the balance are sent to an external printer or computer. This is a quick method of checking the balance settings. Procedure •... -
Page 52: Reset
Explorer Pro Reset When this function is selected, and the Enter button is pressed, settings which were made in Readouts, RS232, Print Option and GLP Print Option can be reset to factory settings. See table below for factory settings. Procedure •... -
Page 53: Lock Out
Explorer Pro Lock Out Lock Out when selected, permits measurement units, calibration methods, and balance functions to be turned on or off. When the balance is set for Legal For Trade operation (LFT ON), and the Lockswitch is set ON underneath the balance and sealed in accordance with paragraph 4.11, all selections made become locked and cannot be changed. -
Page 54: Custom Menu
Explorer Pro 4.10 Custom Menu Custom menu provides a convenient way of selecting one or more balance functions. By entering the Custom menu, you can quickly select your most used function and operate the balance. The FUNCTION LIST menu parallels the menus in the CHANGE MODE and SET BALANCE menus and is listed with the associated paragraphs in the manual at the bottom of the page. -
Page 55: Menu Lock-Out Protection
Explorer Pro 4.11 Menu Lock-Out Protection Access to the various menus can be disabled setting the Lockswitch located on the PC board inside the balance to OFF position. The Lockswitch locks out certain menus when Legal For Trade is turned ON. The default setting for the Lockswitch is OFF. Procedure Type Approved/Legal for Trade Balance Sealing All Explorer Pro Balances may be sealed for type approved/... -
Page 56: Legal For Trade (Lft)
Explorer Pro 4.12 Legal for Trade (LFT) Legal for trade (LFT) is a software controlled option which can be set Legal For Trade ON or OFF. When set ON, certain items in the Calibration and Set Balance menus are automatically preset and locked to permit the balance to operate in a legal for trade application and works in conjunction with a Lock Out switch. -
Page 57: Care And Maintenance
Explorer Pro CARE AND MAINTENANCE To keep the balance operating properly, the housing and platform should be kept clean and free from foreign material. If necessary, a cloth dampened with a mild detergent may be used. Keep calibration masses in a safe dry place. Troubleshooting SYMPTOM PROBABLE CAUSE(S) -
Page 58: Rs232 Interface
Explorer Pro RS232 Interface Explorer Pro Balances are equipped with a bi-directional RS232 compatible interface for communication with printers and RS232 Connector computers. When the balance is connected directly to a printer, displayed data can be output at any time by simply pressing PRINT. - Page 59 Explorer Pro RS232 Interface (Cont.) RS232 COMMAND TABLE (Cont.) Command Character Description Set 1 second print delay (set x = 0 for OFF, or x = 1 for ON) Print current function. minimum level Set Averaging Filter Level to “x”, where x = 0 to 9 (see table).
- Page 60 Explorer Pro RS232 COMMAND TABLE (Cont.) Command Character Description Esc R Resets Setup and Print menus to factory defaults. CAUTION: This will reset RS232 configuration. Turns balance on. Turns balance off. Print current weigh mode. Print current Parts Count Reference Weigh. Print current Percent Reference Weigh.
-
Page 61: Error Codes List
Explorer Pro Error Codes List The following list describes the various error codes and which can appear on the display and the suggested remedy. Data Errors Transient error (hardware error, probably static discharge). If error persists, the balance must be serviced. Balance temperature transducer hardware error. -
Page 62: Service Information
RS232 Interface Cable, Blunt end (user defined) AS017-01 80850013 ® RS232 Interface Cable, IBM - PC 25 Pin AS017-02 80850014 RS232 Interface Cable, (connects impact printer) 80500570 80500570 RS232 Interface Cable, IBM ® - PC 9 Pin AS017-09 80850015 RS232 Interface Cable, Apple ®... -
Page 63: Specifications
Explorer Pro Specifications Capacity (g) 12,000 22,000 32,0000 Readability (g) Weighing modes g, kg, lbs, oz, oz t, ct, dwt, taels (3), mommes, gn, ti, N, custom unit Functions Parts counting, differential weighing, quick check, statistics, formulation, filling, animal weighing, percent formulation, check weighing, density determination, SQC &... - Page 64 Explorer Pro NOTES:...
- Page 65 LIMITED WARRANTY Ohaus products are warranted against defects in materials and workmanship from the date of delivery through the duration of the warranty period. During the warranty period Ohaus will repair, or, at its option, replace any component(s) that proves to be defective at no charge, provided that the product is returned, freight prepaid, to Ohaus.
- Page 66 Ohaus Corporation Ohaus Europe Ltd. 19A Chapin Road, 64 Boston Road Pine Brook, NJ 07058-9878, USA Beaumont Leys, England Tel: (973) 377-9000 Tel: +44 (0) 1954 251343, Fax: (973) 593-0359 Fax: +44 (0) 1954 250205 With offices worldwide http://www.ohaus.com *80250963* ©...
