- Page 1 VivoMini VC66-C Series User Manual...
- Page 2 Copyright © 2018 ASUSTeK COMPUTER INC. All Rights Reserved. LIMITATION OF LIABILITY Circumstances may arise where because of a default on ASUS’ part or other liability, you are entitled to recover damages from ASUS. In each such instance, regardless of the basis on which you are entitled to claim damages from ASUS, ASUS is liable for no more than damages for bodily injury (including death) and damage to real property and tangible personal property;...
-
Page 3: Table Of Contents
Installing memory modules ....................28 Installing the M.2 SSD ......................32 Installing the wireless card ....................33 Installing 2.5” HDD or SSD ....................34 Appendix Safety information .........................38 Setting up your system .......................38 Care during use ........................38 Regulatory notices ........................40 ASUS contact information ....................45 VC66-C Series... -
Page 4: About This Manual
About this manual This manual provides information about the hardware and software features of your PC, organized through the following chapters: Chapter 1: Getting to know your VivoMini This chapter details the hardware components of your VivoMini. Chapter 2: Using your VivoMini This chapter provides you with information on using your VivoMini. -
Page 5: Conventions Used In This Manual
Conventions used in this manual To highlight key information in this manual, some text are presented as follows: IMPORTANT! This message contains vital information that must be followed to complete a task. NOTE: This message contains additional information and tips that can help complete tasks. -
Page 6: Package Contents
Package contents Your VivoMini package contains the following items: VivoMini AC power adapter* Power cord* Technical documents VC66-C Series... - Page 7 For details on these accessories, refer to their respective user manuals. • T he device illustration is for reference only. Actual product specifications may vary with models. • I f the device or its components fail or malfunction during normal and proper use within the warranty period, bring the warranty card to the ASUS Service Center for replacement of the defective components. VC66-C Series...
- Page 8 VC66-C Series...
-
Page 9: Getting To Know Your Vivomini
Getting to know your VivoMini... -
Page 10: Features
Features Front view Top cover The removable top cover allows you access to the hard disk drive and the memory modules. IMPORTANT! Before removing the top cover, turn off your VivoMini and unplug the power cable. NOTE: This port may vary per model. Optical Drive (on selected models) Your VivoMini’s optical drive may support several disc formats such as CDs, DVDs, recordable discs, or rewritable discs. - Page 11 Blu-ray Drive (on selected models) Your VivoMini’s optical drive may support several disc formats such as CDs, DVDs, Blu-ray discs, recordable discs, or rewritable discs. NOTE: Ensure to use a Blu-ray compatible media player when playing the contents of a Blu-ray disc. Headphone jack This port allows you to connect amplified speakers or headphones.
-
Page 12: Left View
Left view Air vents The air vents allow air to enter your VivoMini chassis. IMPORTANT! For optimum air flow, ensure that the air vents are free from obstructions. VC66-C Series... -
Page 13: Right View
Right view Air vents The air vents allow air to enter your VivoMini chassis. IMPORTANT! For optimum air flow, ensure that the air vents are free from obstructions. VC66-C Series... -
Page 14: Rear View
Rear view Kensington® security slot The Kensington® security slot allows you to secure your VivoMini using Kensington® compatible VivoMini security products. Power input The bundled power adapter converts AC power to DC power for use with this jack. Power supplied through this jack supplies power to the VivoMini. - Page 15 DVI port This port allows you to connect your VivoMini to an external display. Serial (COM) connector The 9-pin serial (COM) connector allows you to connect devices that have serial ports such as mouse, modem, or printers. HDMI port The HDMI (High Definition Multimedia Interface) port supports a Full-HD device such as an LCD TV or monitor to allow viewing on a larger external display.
- Page 16 VC66-C Series...
-
Page 17: Using Your Vivomini
Using your VivoMini... -
Page 18: Getting Started
Getting started Connect the AC power adapter to your VivoMini To connect the AC power adapter to your VivoMini: A. Connect the power cord to the AC power adapter. Connect the DC power connector into your VivoMini’s power (DC) input. C. - Page 19 IMPORTANT! • W e strongly recommend that you use only the AC power adapter and cable that came with your VivoMini. • W e strongly recommend that you use a grounded wall socket while using your VivoMini. • T he socket outlet must be easily accessible and near your VivoMini. • T o disconnect your VivoMini from its main power supply, unplug your VivoMini from the power socket. NOTE: The power adapter may vary between models and territories, please refer to the following for more information on the different adapters: 120W Power adapter •...
-
Page 20: Connect A Display Panel To Your Vivomini
Connect a display panel to your VivoMini You can connect a display panel or projector to your VivoMini that has the following connectors: • DVI connector • DisplayPort • HDMI connector To connect a display panel to your VivoMini: Connect one end of a DVI, DisplayPort, or an HDMI, cable to an external display, and the other end of the cable to your VivoMini’s DVI port, DisplayPort, or an HDMI port. - Page 21 Connect display via DisplayPort Connect display via HDMI port VC66-C Series...
-
Page 22: Connect The Usb Cable From Keyboard Or Mouse
Connect the USB cable from keyboard or mouse You can connect generally any USB keyboard and mouse to your VivoMini. You can also connect a USB dongle for a wireless keyboard and mouse set. To connect a keyboard and mouse to your VivoMini: Connect the USB cable from your keyboard and mouse to any of the USB ports of your VivoMini. -
Page 23: Turn On Your Vivomini
Turn on your VivoMini Press the power button to turn on your VivoMini. VC66-C Series... -
Page 24: Turning Your Vivomini Off
Turning your VivoMini off If your VivoMini is unresponsive, press and hold the power button for at least four (4) seconds until your VivoMini turns off. Putting your VivoMini to sleep To put your VivoMini on Sleep mode, press the Power button once. Entering the BIOS Setup BIOS (Basic Input and Output System) stores system hardware settings that are needed for system startup in the VivoMini. -
Page 25: Load Default Bios Settings
Load default BIOS settings To load the default values for each of the parameters in your BIOS: • Enter the BIOS by pressing <F2> or <DEL> on the POST screen. NOTE: POST (Power-On Self Test) is a series of software controlled diagnostic tests that run when you turn on your VivoMini. •... - Page 26 VC66-C Series...
-
Page 27: Upgrading Your Vivomini
Upgrading your VivoMini... -
Page 28: Installing Memory Modules
IMPORTANT! • I t is recommended that you install or upgrade the memory modules, wireless card, and solid state drive (SSD), under professional supervision. Visit an ASUS service center for further assistance. • E nsure that your hands are dry before proceeding with the rest of the installation process. Before installing any of the features in this guide, use a grounded wrist strap or touch a safely grounded object or metal object to avoid damaging them due to static electricity. - Page 29 Lift and remove the top cover and set it aside. IMPORTANT! Remove the top cover carefully to prevent pulling on and causing damage to the cables connected. This may vary per model. Remove the screw from the HDD layer. VC66-C Series...
- Page 30 Lift open the HDD layer. IMPORTANT! Lift the HDD layer carefully to prevent pulling on and causing damage to the cables connected. Align and insert the memory module into the slot and press it down (A) until the retaining clips snaps back into place and it is securely seated in place.
- Page 31 Replace the HDD layer. NOTE: Ensure to organize the cables to prevent any damage to your VivoMini and to ensure the HDD layer can be replaced successfully. Replace the screw to secure the HDD layer. VC66-C Series...
-
Page 32: Installing The M.2 Ssd
Installing the M.2 SSD Align and insert the M.2 SSD into its slot inside the VivoMini, then secure it with a screw. VC66-C Series... -
Page 33: Installing The Wireless Card
Installing the wireless card Align and insert the wireless card into its slot inside the VivoMini (A), then secure it with a screw (B). Connect the black antenna to MAIN or and the white antenna to AUX on the wireless card (C). VC66-C Series... -
Page 34: Installing 2.5" Hdd Or Ssd
Installing 2.5” HDD or SSD NOTE: • This bay supports 7mm/9.5mm 2.5” HDDs/SSDs. • Some models may only support one (1) HDD/SSD. Remove four (4) screws from the HDD/SSD bracket. Remove the HDD/SSD bracket. Remove the cable from the holder, then remove the holder from the HDD/SSD bracket. NOTE: • E nsure to remove the holder from the bracket when installing an HDD/SDD to the bracket. - Page 35 To install a new HDD/SSD, secure the HDD/SSD to the bracket using the bundled four (4) screws. Connect the cable to the HDD/SSD, then align the bracket to the HDD/ SSD compartment of your VivoMini and secure the bracket with the screws previously removed.
- Page 36 VC66-C Series...
-
Page 37: Appendix
Appendix... -
Page 38: Safety Information
Safety information Your VivoMini is designed and tested to meet the latest standards of safety for information technology equipment. However, to ensure your safety, it is important that you read the following safety instructions. Setting up your system • Read and follow all instructions in the documentation before you operate your system. • Do not use this product near water or a heated source. • Set up the system on a stable surface. • Openings on the chassis are for ventilation. Do not block or cover these openings. Make sure you leave plenty of space around the system for ventilation. - Page 39 • If you encounter the following technical problems with the product, unplug the power cord and contact a qualified service technician or your retailer. – The power cord or plug is damaged. – Liquid has been spilled into the system. – The system does not function properly even if you follow the operating instructions. – The system was dropped or the cabinet is damaged. – The system performance changes.
-
Page 40: Regulatory Notices
ASUS REACH website at http://csr.asus.com/ english/REACH.htm ASUS Recycling/Takeback Services ASUS recycling and takeback programs come from our commitment to the highest standards for protecting our environment. We believe in providing solutions for you to be able to responsibly recycle our products, batteries, other components, as well as the packaging materials. - Page 41 Federal Communications Commission Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: • This device may not cause harmful interference, and • This device must accept any interference received including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 42 ISED Radiation Exposure Statement for Canada This equipment complies with ISED radiation exposure limits set forth for an uncontrolled environment. To maintain compliance with ISED RF exposure compliance requirements, please avoid direct contact to the transmitting antenna during transmitting. End users must follow the specific operating instructions for satisfying RF exposure compliance. Operation is subject to the following two conditions: •...
- Page 43 2.412-2.484 GHz Ch01 through Ch14 Europe ETSI 2.412-2.472 GHz Ch01 through Ch13 Regional notice for Singapore Complies with This ASUS product complies with IMDA Standards. IMDA Standards DB103778 Regional notice for California WARNING Cancer and Reproductive Harm - www.P65Warnings.ca.gov Regional notice for Malaysia...
- Page 44 Agency and the U.S. Department of Energy helping us all save money and protect the environment through energy efficient products and practices. All ASUS products with the ENERGY STAR logo comply with the ENERGY STAR standard, and the power management feature is enabled by default.
-
Page 45: Asus Contact Information
+1-510-608-4555 Web site http://www.asus.com/us/ Technical Support Support fax +1-812-284-0883 Telephone +1-812-282-2787 Online support https://www.asus.com/support/Product/ ContactUs/Services/questionform/?lang=en-us ASUS COMPUTER GmbH (Germany and Austria) Address Harkort Str. 21-23, 40880 Ratingen, Germany +49-2102-959931 Web site http://www.asus.com/de Online contact http://eu-rma.asus.com/sales Technical Support Telephone +49-2102-5789555 Support Fax... - Page 46 VC66-C Series...
