Foam marker

Advertisement

02
FOAM MARKER
520005
520005C
5200052
5200052C
INSTALLATION, uSE AND MAINTENANCE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 520005 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ARAG 520005

  • Page 1 FOAM MARKER 520005 520005C 5200052 5200052C INSTALLATION, uSE AND MAINTENANCE...
  • Page 2: Legend Symbols

    This manual is an integral part of the equipment to which it refers and must accompany the equipment in case of sale or change of ownership. Keep it for future reference; ARAG reserves the right to modify the specifications and instructions regarding the product at any time and without prior notice.
  • Page 3: Table Of Contents

    CONTENTS Legend symbols ..........................2 1 Product description ........................4 Intended use ......................... 4 2 precautions ............................. 4 3 Identification ........................... 4 4 Contents of the packaging ......................5 5 Installation ............................5 Precautions ..........................5 Overall dimensions - mm (inches) ..................
  • Page 4: Product Description

    • Comply with the specific power supply voltage (12 Vdc). • In case of electric arc welding, make sure that the power supply to the device is disconnected; if necessary, disconnect the power supply cables. • Use only original ARAG spare parts or accessories. identification On all request for spare parts,...
  • Page 5: Contents Of The Packaging

    contents of the Packaging Fig. 2 Tank plug with max. pressure valve 7 Accessory/spare part kit 8 Instructions handbook Foaming liquid tank 9 Tank holder basket Foam markers Vertical foam marker brackets 10 Compressor/solenoid valve unit 11 Complete harnesses Air-liquid connecting pipes Control box installation Precautions...
  • Page 6: Overall Dimensions - Mm (Inches)

    Overall dimensions - mm (inches) Fig. 4 Assembly diagram Fig. 5 1 Control box 2 Tank and compressor unit 3 Foam makers...
  • Page 7: Installing Tank And Compressor Unit

    Installing tank and compressor unit Tank and compressor unit can be installed onto the machine in two different ways: 1 Fix the compressor unit (C) to the tank holder basket (B) and then install the assembly onto the machine. 2 Install compressor unit (C) and tank holder basket (B) separately.
  • Page 8: Mounting The Pneumo-Hydraulic Circuit

    Vertical foam markers • Drill two Ø 6 mm holes at a distance of 100 mm on bar (A). • Fix the bracket (B) to the bar with the supplied M6 screws. • Fit the foam maker (D) onto the knurled section of the bar (B) and fix with the supplied screw (E).
  • Page 9: Installing The Control Box

    Accessory connections: positioning the foam marker control kit To use the foam marker with a BRAVO computer install the foam marker kit as de- scribed in the instructions supplied with the very kit (please refer to ARAG General Catalogue for part numbers).
  • Page 10: Use

    Discharging remaining pressure Fully depressurize the system as described below before removing the tank plug: • Cut off the supply to the foam marker. • Pull the red pin of the relief valve onto the tank plug and then discharge any residue pressure as shown in the figure.
  • Page 11: Starting And Operating

    • Refill with liquid, observing the procedures described in the par. 6.4 - Preparing foaming solution. • Use only ARAG foaming agents. • IN CASE OF DAMAGES TO THE FOAM MARKER CAUSED BY NON AUTHORIZED FOAMING AGENTS, ALL WARRANTY CLAUSES WILL BECOME NULL AND VOID.
  • Page 12: Maintenance / Diagnostics / Repairs

    Maintenance / diagnostics / rePairs Max. pressure valve Max. pressure valve onto the tank plug is maintenance free. The action of the pressure discharge pin onto the tank plug avoids any clogging of the relief valve and - at the same time - ensures its proper operation. Machine down for up to 7 days For periods of disuse up to 7 days, proceed as follows: Horizontal foam markers...
  • Page 13: Machine Down For Up To 30 Days

    Machine down for up to 30 days For periods of disuse up to 30 days, proceed as follows: • Depressurize the tank as indicated in par. 6.1 - Discharging remaining pressure. • Slacken and remove the cap (C). • Remove tank (A) and wash with clean water. • Wash the bottom filter (D) with clean water.
  • Page 14: Reactive Maintenance

    To ensure dense and lasting formation of foam, replace the sponges code 520000.160 (D, Fig. 14a +14b) every year. Pipe repairs If the hoses break, repair them with one of the snap fittings (code 520005.352 or 520005.353) provided with the package. Proceed as follows: • Use a pair of scissors to trim the...
  • Page 15: Troubleshooting

    Troubleshooting DEFECT CAUSE REMEDY • Check the fuse. No power to the control box • Check the electrical connections of the control box. The compressor unit does not work, the warning lights do not turn on • Check the connections between the Electric connection between control control box and the electric compres- box and compressor cut off sor.
  • Page 16: Problems Due To The Solenoid Valves Locking Up

    17,5 kg Noise level 70 dB (A) * Using foaming agent ARAG at the concentration given on the package, (see par. 6.6.1.) end of life disPosal To be disposed in compliance with the legislation in force in the country in question.
  • Page 17: Spare Parts

    Parts 520005 - 5200052 - 520005C - 5200052C - 520005.900...
  • Page 18 520005.060...
  • Page 19 520005.080...
  • Page 20 520004.262 520005.260...
  • Page 21 520005.390...
  • Page 22: Guarantee Terms

    1. ARAG s.r.l. guarantees this apparatus for a period of 360 day (1 year) from the date of sale to the client user (date of the goods delivery note). The components of the apparatus, that in the unappealable opinion of ARAG are faulty due to an original defect in the material or production process, will be repaired or replaced free of charge at the nearest Assistance Centre operating at the moment the request for intervention is made.
  • Page 23 C o n f o r m i t y D e c l a r a t i o n ARAG s.r.l. Via Palladio, 5/A 42048 Rubiera (RE) - Italy P.IVA 01801480359 Dichiara che il prodotto descrizione: Tracciafile modello: serie: 520xxx risponde ai requisiti di conformità...
  • Page 24 Only use original ARAG accessories and spare parts, to maintain safety conditions foreseen by the constructor. Always refer to the ARAG spare parts catalogue. 42048 RUBIERA (Reggio Emilia) - ITALY Via Palladio, 5/A Tel. 0522 622011 Fax 0522 628944 http://www.aragnet.com...
