Owner's Maintenance

The smoke detector is designed to require minimum maintenance. If the case becomes dusty,
vacuum with a small brush attachment. If the case is greasy, wipe the case gently with a soft
cloth slightly dampened with soapy water.
Never disassemble the smoke detector; there are no user serviceable parts inside the unit.
You may only remove detector from backplate to replace batteries if not serviced by
installer. When replacing the batteries, follow the instructions specified in the Installation
Instructions.
Never paint the unit. Paint may prevent smoke from entering the unit. If you are planning
renovations or repainting, take precautions to avoid dust, paint or chemical contamination
to the detector.
If the unit is located in an area where it is exposed to high levels of dust or insects and causes
false alarms, it may require service; contact your smoke detector installer or dealer.
Testing and maintenance procedures shall be in accordance with CAN/ULC-S552-14.

Specifications

Regulatory Listings: UL268/ULC-S531 PG9936
l
Diameter: 5 in (125 mm)
l
Height: 2.5 in (63 mm)
l
Weight (including battery): 8.75 oz (243 g)
l
Color: White
l
Spacing rating: 70 ft (21.3 m)
l
Alarm Sensitivity (threshold) PG9936 (cULus): 1.26 - 2.39 %/ foot obscuration
l
Alarm Sensitivity (threshold) PG4936 / PG8936: complies with EN14604
l
Audible Signal (ANSI Temporal 3): 85 dBA minimum in alarm
l
Operating Temperature: PG9936 40 ºF - 100 ºF (4.4 ºC - 37.8 ºC)
l
Operating Temperature with Heat Detector: 32 ºF - 100 ºF (0 ºC - 37.8 ºC)
l
Operating Temperature for Smoke Alarm:PG4936 41 ºF - 113 ºF (5 ºC - 45 ºC); Type A
l
Photoelectric Smoke Alarm (Australia)
Heat Alarm: 135 ºF (57 ºC);
l
Humidity: 15 % - 90 % RH, non-condensing
l
Approved Batteries: 3 AAA Energizer E92 or Duracell Procell PC2400
l
Alarm Silencing: PG4936 8 minutes automatically resettable
l
Supervisory Transmission Frequency:PG9936 64 minute intervals
l
Supervisory Transmission Frequency: PG4936 / PG8936 12 minute intervals
l
Maximum Tx Power: 433.22 MHz - 434.64 MHz: 10 mW, 868.0 MHz - 868.6 MHz: 14 mW,
l
868.7 MHz - 869.2 MHz: 14 mW.
Low Battery Detection: Low battery 14 days remaining
l

Limited Warranty

Digital Security Controls warrants that for a period of twelve months from the date of purchase, the product shall be free of
defects in materials and workmanship under normal use and that in fulfillment of any breach of such warranty, Digital Security
Controls shall, at its option, repair or replace the defective equipment upon return of the equipment to its repair depot. This
warranty applies only to defects in parts and workmanship and not to damage incurred in shipping or handling, or damage
due to causes beyond the control of Digital Security Controls such as lightning, excessive voltage, mechanical shock, water
damage, or damage arising out of abuse, alteration or improper application of the equipment.
The foregoing warranty shall apply only to the original buyer, and is and shall be in lieu of any and all other warranties,
whether expressed or implied and of all other obligations or liabilities on the part of Digital Security Controls. Digital Security
Controls neither assumes responsibility nor authorizes any other person purporting to act on its behalf to modify or to change
this warranty, nor to assume for it any other warranty or liability concerning this product.
In no event shall Digital Security Controls be liable for any direct, indirect or consequential damages, loss of anticipated profits,
loss of time or any other losses incurred by the buyer in connection with the purchase, installation or operation or failure of
this product.
Smoke Detectors: Smoke detectors that are a part of this system may not properly alert occupants of a fire for a number of
reasons, some of which follow. The smoke detectors may have been improperly installed or positioned. Smoke may not be
able to reach the smoke detectors, such as when the fire is in a chimney, walls or roofs, or on the other side of closed doors.
Smoke detectors may not detect smoke from fires on another level of the residence or building.
Every fire is different in the amount of smoke produced and the rate of burning. Smoke detectors cannot sense all types of
fires equally well. Smoke detectors may not provide timely warning of fires caused by carelessness or safety hazards such as
smoking in bed, violent explosions, escaping gas, improper storage of flammable materials, overloaded electrical circuits, chil-
dren playing with matches or arson.
Even if the smoke detector operates as intended, there may be circumstances when there is insufficient warning to allow all
occupants to escape in time to avoid injury or death.
Warning: Digital Security Controls recommends that the entire system be completely tested on a regular basis. However, des-
pite frequent testing, and due to, but not limited to, criminal tampering or electrical disruption, it is possible for this product to
fail to perform as expected.
Important Information: Changes or modifications not expressly approved by Digital Security Controls could void the user's
authority to operate this equipment.
EULA
IMPORTANT - READ CAREFULLY: DSC Software purchased with or without Products and Components is copy-
righted and is purchased under the following license terms:
This End-User License Agreement ("EULA") is a legal agreement between You (the company, individual or entity who
acquired the Software and any related Hardware) and Digital Security Controls, a division of Tyco Safety Products Canada
Ltd. ("DSC"), the manufacturer of the integrated security systems and the developer of the software and any related
products or components ("HARDWARE") which You acquired. If the DSC software product ("SOFTWARE PRODUCT" or
"SOFTWARE") is intended to be accompanied by HARDWARE, and is NOT accompanied by new HARDWARE, You may not
use, copy or install the SOFTWARE PRODUCT. The SOFTWARE PRODUCT includes computer software, and may include
associated media, printed materials, and "online" or electronic documentation. Any software provided along with the
SOFTWARE PRODUCT that is associated with a separate end-user license agreement is licensed to You under the terms of
that license agreement. By installing, copying, downloading, storing, accessing or otherwise using the SOFTWARE
PRODUCT, You agree unconditionally to be bound by the terms of this EULA, even if this EULA is deemed to be a modi-
fication of any previous arrangement or contract. If You do not agree to the terms of this EULA, DSC is unwilling to license
the SOFTWARE PRODUCT to You, and You have no right to use it.
