CORDLESS SCREWDRIVER KIT – 3.6 VOLT
Model 47953
OPERATING INSTRUCTIONS
®
3491 Mission Oaks Blvd., Camarillo, CA 93011
Visit our Web site at: http://www.harborfreight.com
Copyright 2002 by Harbor Freight Tools
®
. All rights reserved. No portion of this
manual or any artwork contained herein may be reproduced in any shape or form
without the express written consent of Harbor Freight Tools.
For technical questions, please call 1-800-444-3353.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Harbor Freight Tools Chicago Electric 47953
Summary of Contents for Harbor Freight Tools Chicago Electric 47953
- Page 1 Copyright 2002 by Harbor Freight Tools ® . All rights reserved. No portion of this manual or any artwork contained herein may be reproduced in any shape or form without the express written consent of Harbor Freight Tools. For technical questions, please call 1-800-444-3353.
-
Page 2: Specifications Table
SPECIFICATIONS TABLE Item Description Input Electrical Requirements 120 Volts/60 Hz Output Voltage 3.6 Volts Power Switch Toggle Type (Forward & Reverse) Handle Locking Type (2 Positions) Accessories 25mm Screwdriver Bit (Qty: 84) 50mm Screwdriver Bit (Qty: 6) Nut Driver Bit (Qty: 9) Magnetic Bit Holder (Qty: 1) Tri-Fold Blow Mold Case (Qty: 1) Weight... - Page 3 REPLACEMENT PARTS AND ACCESSORIES: When servicing, use only identical replacement parts. Only use accessories intended for use with this product. Approved accessories are available from Harbor Freight Tools. MAINTAIN THIS PRODUCT WITH CARE. Keep this product clean, dry, and keep all cutting bits sharp for better and safer performance.
-
Page 4: Specific Product Warnings And Precautions
SPECIFIC PRODUCT WARNINGS AND PRECAUTIONS MAINTAIN A SAFE WORKING ENVIRONMENT. Keep the work area well lit. Make sure there is adequate surrounding workspace. Always keep the work area free of obstructions, grease, oil, trash, and other debris. Do not use the Cordless Screwdriver in a damp or wet location. - Page 5 When unpacking, check to make sure all the parts shown on the Parts List on page 8 are included. If any parts are missing or broken, please call Harbor Freight Tools at the number shown on the cover of this manual as soon as possible.
- Page 6 MAGNETIC LOCKING SWITCH (#12) BIT HOLDER CHUCK CHARGER PLUG (#17) CHARGER POWER SWITCH (#11) HANDLE (#6, #7, #8, #9) FIGURE C To Charge The Cordless Screwdriver: NOTE: The Battery Pack (part #3) requires charging. The first charge requires 10 to 12 hours charge time prior to using the Cordless Screwdriver. Never charge battery more than 12 hours for the initial charge.
-
Page 7: Inspection, Maintenance, And Cleaning
While charging, the Charger and Cordless Screwdriver may become warm to the touch. This is normal, and does not indicate a problem. Once the Cordless Screwdriver is fully charged, disconnect the Charger from the electrical outlet. Then, disconnect the Charger Plug from the Cordless Screwdriver. -
Page 8: Please Read The Following Carefully
PLEASE READ THE FOLLOWING CAREFULLY THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT. -
Page 9: Assembly Diagram
ASSEMBLY DIAGRAM NOTE: CHARGER (#17) NOT SHOWN. NOTE: Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts. SKU 47953 PAGE 9...
