Page 1: User Manual
TVI Camera User Manual Version: TVI 1 Available from A1 Security Cameras ww.a1securitycameras.com email: sales@a1securitycameras... -
Page 2: Technical Parameters
TECHNICAL PARAMETERS Sensor Type 1/2.7" Sensor NTSC/PAL Signal System Resolution 1920×1080p LENS 2.8-12mm 3.6mm 2.8mm IR Distance 115ft 65ft Video Output 1 BNC (TVI /Support CVBS) Day & Night Switch Frame Rate 30fps / 25fps Min. 0lux（IR LED ON） Illumination S/N Ratio >52dB（AGC off）... -
Page 3: Installation
INSTALLATION Avoid installing it directly towards the sun. 1、 Do not install it in the place where temperature 2、 is above 50℃ or below -20℃. Avoid operating and storing in the water. 3、 Video cable connector and DC tie-in must be 4、... - Page 4 MAIN MENU: DAY-NIGHT VIDEO-SETING LANGUAGE RESET SAVE EXIT EXIT BRIGHTNESS 1-20 GLOBE/CENTER/ EXPOSURE——MODE BLC/FLC GAIN RETURN AE: You can set the AE mode as Brightness、 EXPOSURE 、GAIN Available from A1 Security Cameras ww.a1securitycameras.com email: sales@a1securitycameras...
- Page 5 Day and night [COLOR [Auto/ Mode /B/W ATW/ Mode /Smart] EXT] RETURN RETURN ATW/MWB EXT Day and night: Color, B/W,Smart are selectable for DAY/NIGHT switches VIDEO-SETTING CONTRAST 1-10 Sharpness 1-20 COLOR GAIN 1-20 1-15 FORMAT NTSC/PAL RETURN LANGUAGE : Available from A1 Security Cameras ww.a1securitycameras.com email: sales@a1securitycameras...
-
Page 6: Troubleshooting
English Chinese RESET : Restore all parameters to default settings. TROUBLESHOOTING Problem Reason How to solve Image normal in the day while Power is not Change power vague or being enough or supply or interfered by power cable shorten power horizontal is too long.
