CVS Controls Series 470
Piston Actuators
The CVS Series 470 is a double acting
pneumatic Piston Actuator, suitable
for use with Globe, Angle, Three Way,
and Reverse acting valves as well as
Steam Equipment. Capable of high
thrust applications to 19,500 lb-f,
with a maximum travel to 8 1/8
inches.
The CVS Series 470 Actuator may be
used in on/off applications, as well as
throttling service when used with a
positioner.
Head Office
3900 101 Street
Edmonton, Alberta
T6E 0A5
Canada
Office: (780) 437-3055
Fax: (780) 436-5461
Website:
www.cvs-controls.com
Email:
info@cvs-controls.com
INSTRUCTION MANUAL
Calgary Sales Office
3516 114 Avenue SE
Calgary, Alberta
T2Z 3V6
Canada
Office: (403) 250-1416
Fax: (403) 291-9487
