1 "DC 12-18V" POWER SOCKET
Connect to this socket only the supplied power supply.
2 UNBAL
Unbalanced audio output with 6,35mm (1/4") jack. Connect this output into an
unbalanced input of your mixer.
3 AF OUTPUT
Balanced audio output with XLR-M socket. Connect this output into a balanced input
of your mixer.
2.2 | HANDHELD WIRELESS MICROPHONE - START 16M
1
1 GRILLE
It protects the microphone capsule from impacts and/or accidental falls and
it reduces the noise of the plosive.
START 16 Series
6
User manual |
Series
REAR PANEL
1
2
2
3
3
4
5
