MP80
INSTALLATION AND OPERATION MANUAL
MP80 SOLID FUEL
FURNACE FOR USE AS
ANADD-ON TO OIL, GAS OR
ELECTRIC FURNACE
OR AS AN INDEPENDENT
FORCED AIR WITH BLOWER
READ THOROUGHLY AND COMPLY WITH ALL LOCAL CODES AND REGULATIONS
VALLEY COMFORT SYSTEMS INC.
1290 COMMERCIAL WAY
PENTICTON, B.C. V2A 3H5
(250) 493-7444
www.blazeking.com
Email: sales@blazeking.com
MP80.PUB Version 1.05
1
Date printed:4/7/2011
Pour la version française de nos manuels S.V.P. vous référez à notre site web :
www.blazeking.com
Advertisement
Table of Contents
Related Manuals for Valley Comfort Systems MP80
Summary of Contents for Valley Comfort Systems MP80
- Page 1 MP80 INSTALLATION AND OPERATION MANUAL MP80 SOLID FUEL FURNACE FOR USE AS ANADD-ON TO OIL, GAS OR ELECTRIC FURNACE OR AS AN INDEPENDENT FORCED AIR WITH BLOWER READ THOROUGHLY AND COMPLY WITH ALL LOCAL CODES AND REGULATIONS VALLEY COMFORT SYSTEMS INC.
- Page 2 MP80.PUB Version 1.05 Date printed:4/7/2011...
-
Page 3: Table Of Contents
COMBUSTION AIR INTERCONNECT DUCT RETAINERS FLUE LOCATION & CONNECTIONS CHIMNEY HEIGHT THERMOSTATS FAN LIMITS DOOR LATCHES OIL FURNACE ADD ON GAS FURNACE ADD ON WIRING DIAGRAMS 20,21, ELECTRIC FURNACE ADD ON VB1000 BLOWER WARNOCK HERSEY LABEL MP80.PUB Version 1.05 Date printed:4/7/2011... -
Page 4: Warranty
FORT SYSTEMS INC shall in no event be liable for special, incidental, consequential, indirect or other similar damages arising from the breach of the warranty, even if VALLEY COMFORT SYSTEMS INC has been advised of the possibility of such damages. Some provinces / states do not allow the exclusion or limitation of incidental or consequential dam- ages, so the above limitation or exclusion may not apply to you. -
Page 5: Warranty
SYSTEMS INC. cannot provide a repair or replacement within a reasonable time, and the purchaser is willing to accept such a refund. If VALLEY COMFORT SYSTEMS INC. elects to repair or replace the product based on the formula be- low, VALLEY COMFORT SYSTEMS INC. will ship the product prepaid at their expense to a VALLEY COMFORT dealer nearest the purchaser. -
Page 6: Specifications
2) Stainless steel baffle system to retain high combustion efficiency Construction 14 Ga. Firebox Cast iron liners 12 Ga. heat exchanger 20 Ga. cabinet Stainless steel baffle Weight 325 lbs. MP80.PUB Version 1.05 Date printed:4/7/2011... -
Page 7: Safety Precautions
- Keep smoke pipe and chimney clean to prevent a chimney fire. In the event of a chimney fire turn down all thermostats and close off combustion air. Call a fire department if necessary. Have a clearly understood plan to handle a chimney fire. MP80.PUB Version 1.05 Date printed:4/7/2011... -
Page 8: Lighting Instructions
In a new furnace, spread 1" of sand or ashes in the bottom of the firebox to protect against high heat and to prevent warping Your MP80 firebox is lined with quality cast liners. Stresses inherent in the cast process must be neutral- ized before you build extremely hot fires. The first fire should be small and should burn no longer than 30 minutes, gradually increasing for the next six lightings. -
Page 9: Operations
If your furnace is operating as an add-on combination unit remember both units will not fully fire at the same time. If wood is to be your main source, set the wood thermostat at your desired room temperature and set the backup thermostat approximately 5 degrees lower. MP80.PUB Version 1.05 Date printed:4/7/2011... -
Page 10: Creosote
Having a clearly understood plan should a chimney fire occur. WARNING: FAILURE TO INSPECT AND CLEAN YOUR CHIMNEY SYSTEM REGULARLY CAN RESULT IN A SERIOUS FIRE WHICH MAY DAMAGE YOUR CHIMNEY OR CAUSE A HOUSE FIRE MP80.PUB Version 1.05 Date printed:4/7/2011... -
Page 11: Maintenance
Valley Comfort dealer. After each heating season thoroughly clean the chimney and firebox so your system is ready for next fall. Inspect all parts for signs of abnormal wear or problems. Have a warm safe winter MP80.PUB Version 1.05 Date printed:4/7/2011... -
Page 12: Installation Instructions
CF6 kit for use in wood counter flow installations INSTALLATION OPTIONS The MP80 may be installed as follows: (Typical Mechanical Drawings on page 13 fig. #1.) 1) An add-on to any of the following furnaces: a) An electric forced air furnace rated at 10 KW to 25 KW with a minimum size fan of 900 cfm. -
Page 13: Typical Installation Diagrams
NOTE TYPICAL ADD ON SYSTEM IN THIS CONFIGURATION SPECIAL CLEARANCES APPLY LAYOUT SEE CF6KIT INSTRUCTIONS. DO NOT INSTALL IN THIS CONFIGURATION WITHOUT USING THE CF6KIT. (80FIG1) *** SEE PAGE 22 FOR STAND-ALONE BLOWER DIMENSIONS *** MP80.PUB Version 1.05 Date printed:4/7/2011... -
Page 14: Clearances
LOCATION RE ALTERNATE FURNACE OR BLOWER The MP80 can be located on either side of the alternate furnace as space permits, in a series downstream configuration. Minimum size of the interconnect duct is 12 in. x 18 in. DO NOT USE INTERCONNECT DUCT ELBOWS THAT HAVE AN INSIDE RADIUS OF LESS THAN 6"... -
Page 15: Pressure Loss
NOTE: After interconnect duct opening has been cut into the side of the MP80, insulation must be fas- tened back to the furnace cabinet all around the opening. Use the metal strips provided to hold the in- sulation tightly against the cabinet inside, to prevent the insulation from dislodging due to blower in- duced vibration. -
Page 16: Flue Location & Connections
You must comply with the local authority having jurisdiction and with CSA installation standard B365 -M87. DO NOT OPERATE THE MP80 WITH A DRAFT OF OVER .06 INCHES WATER COL- UMN. HIGHER DRAFT LEVELS MAY CAUSE THE FIRE TO BURN OUT OF CONTROL AND CREATE A FIRE HAZARD. -
Page 17: Chimney Height
150°F. Thermostats should be mounted side by side on an inside wall out of direct sunlight or other heat sources. MP80.PUB Version 1.05 Date printed:4/7/2011... -
Page 18: Fan Limits
A loose fitting door will allow entry of excess air and result in higher burn rates with less control. MP80.PUB Version 1.05 Date printed:4/7/2011... -
Page 19: Oil Furnace Add On
1 pg. 13. The electric furnace can be located on either side of the MP80 but clear- ances to combustibles must be maintained. - Page 20 CF-6KIT INDEPENDENT WOOD FURNACE When installed with a blower cabinet mounted on either side the MP80 becomes an INDEPENDENT wood only furnace. The blower must have a minimum 900 cfm. capacity. In this configuration the interlock function of the transfer relay is not used. See Electrical Diagram 7 on page 21.
-
Page 21: Electric Furnace Add On
Junction ternate furnace. 120V IN TRANS- FORMER 24V OUT Optional CF-6KIT 120VAC IN DAMPER WOOD THERMOSTAT MOTOR MP80.PUB Version 1.05 Date printed:4/7/2011 120VAC Out to Blower 24 Volt Transformer comes with the VB1000 Blower... -
Page 22: Vb1000 Blower
Please check the dimensions on this drawing against the unit you are installing as there may be some slight variations in the dimensions due to manufacturing tolerances and or changes. Installation instructions begin on page 12 of this manual. MP80.PUB Version 1.05 Date printed:4/7/2011... -
Page 23: Warnock Hersey Label
MP80.PUB Version 1.05 Date printed:4/7/2011... - Page 24 DAMPER ALTERNATE THERMOSTAT WOOD THERMOSTAT MOTOR R (24V IN) C (Common) MP80.PUB Version 1.05 Date printed:4/7/2011...
