Simplicity TURBO COLLECTORS 1692626 Parts Manual page 9

Turbo Blower Assembly - 38" Regent / 500 / 2500 & ZT Series
REF NO. PART NO.
1 108202
2 960403
3 1657499
4 1665982
5 1668500
6 1676148
7 1676833
8 1678435
9 1700259
10 1704314
11 1705267
12 1705492
13 1706284
14 1706465
15 1706631
16 1706634
17 1708030
18 1714911
19 1917356
20 1917372
21 1920415
22 1960472
23 1921959
24 1923341
25 1924361
26 1924874
27 1924940
28 1925003
29 1927557
30 1928691
31 1930641
32 1931333
33 1931355
34 1933263
35 1933988
36 1960251
37 1960252
38 1960256
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1693225 Turbo, 38"
TP 400-2157-00-AT-SMA
QTY.
2 BEARING
1 KEY, Woodruff, Modified, .188 x .875 #61
1 SPRING, Tension
4 BEARING, Retainer
1 BRACKET, Anchor, Spring
2 BUSHING
1 SPACER
1 BELT STOP
1 DECAL, Danger, Blower
1 FITTING, Grease
1 PLATE, Cover
1 FAN HOUSING (Incl. Ref. No. 9)
1 LEVER ASSY, Turbo (Incl. Ref. Nos. 6 &10)
1 PLATE ASSY.
1 FAN ASSY., 5 Blade
1 PULLEY, Driven
1 IDLER PULLEY ASSY.
1 BRACKET ASSY., Turbo
1 WASHER, Spring Lock, 5/16
1 NUT, Hex, 5/16
1 CAPSCREW, Hex Hd., 3/8-16 x 1-1/4
2 SCREW, Truss Hd., 1/4-18 x 5/8
3 CAPSCREW, Hex, 1/4-20 x 5/8
3 CAPSCREW, Hex Hd., 1/4-20 x 3/4
1 WASHER, Flat
1 WASHER, Flat, 5/16
3 WASHER, Plain, 3/8
1 CAPSCREW, Hex, Taptite, 1/4-20 x 1/2
6 NUT, Flange, Whizlock, 5/16-18
1 SETSCREW, Hex, Socket Hd., 5/16-18 x 5/16
10 NUT, Hex, Flange Lock, 1/4-20
7 CARRIAGE BOLT, 5/16-18 x 3/4
1 CARRIAGE BOLT, 3/8-16 x 2-1/4
1 WASHER, Flat, 7/16
6 PUSH NUT, 3/8
2 NUT, Hex, Jam, Center Lock, 3/8-16
1 CARRIAGE BOLT, 1/4-20 x 5/8
2 SCREW, Washer. Hd.., 1/4-18 x 5/8
DESCRIPTION
7
