Clean Water Made Easy.
www.CleanWaterStore.com
7500-S Carbon Backwash Filter Guide
Thank you for purchasing a Clean Water System!
With proper installation and a little routine maintenance your system will be
providing clean, odor-free water for many years.
Please review this start-up guide entirely before beginning to install your
system, and follow the steps outlined for best results.
Minimum pressure of 30 PSI recommended. Maximum pressure
recommended 80 PSI. For indoor installation.
Protect from sunlight, rain, and freezing.
MEDIA CONTAINS DUST. USE MASK TO AVOID BREATHING DUST.
OK to wet down media with spray bottle.
To connect drain line to drain, use an air-gap connection.
Questions?
Call us toll-free: 1-888-600-5426 or 1-831-462-8500
Email us:
support@cleanwaterstore.com
See more information on our website:
www.cleanwaterstore.com/resources
Page 1
7500-S Carbon Backwash Filter Guide
www.cleanwaterstore.com
rev102418

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 7500-S and is the answer not in the manual?

Questions and answers

Summary of Contents for Clean Water Systems 7500-S

  • Page 1 Clean Water Made Easy. www.CleanWaterStore.com 7500-S Carbon Backwash Filter Guide Thank you for purchasing a Clean Water System! With proper installation and a little routine maintenance your system will be providing clean, odor-free water for many years. Please review this start-up guide entirely before beginning to install your system, and follow the steps outlined for best results.
  • Page 2: Table Of Contents

    Diagram of Installation Well Water (Fig. 5) ....................11 Diagram of Installation City Water (Fig. 6) ....................11 Programming Overview..........................12 Program the 7500-S Valve........................... 14 Initial Backwash and Start-Up ........................15 Limited Warranty ............................16 What to Do if Your Tank is Not Level Out of the Box •...
  • Page 3: Packing Lists

    Packing Lists All systems include: 7500-S control valve; power supply; funnel for adding media through the top; drain line flow control; and items included in one of the following options. Find Your Filter Size model to see what is included: Filter 0.75 cubic foot size 8”...
  • Page 4: System Installation Steps Overview

    The longer it soaks while you are doing everything else, the better. 3. Make the plumbing connections from your existing system to the filter, installing a 3-valve bypass around the 7500-S filter backwash control valve. 4. Screw on, attach the control head to the tank.
  • Page 5: Best Practices For Piping & Drain Installation

    5. Locate the unit near an unswitched, 120 volt / 60 Hz grounded electrical outlet. 6. Make sure to connect the IN pipe to the 7500-S inlet and the OUT pipe to the outlet and install a 3 valve bypass around the 7500-S control valve.
  • Page 6: Installation Of Your System In To Copper Or Metal Piping Systems

    This is simple and easy step to take if you are installing your water treatment system into copper piping. A simple ground jumper wire with a pipe clamp can be purchased at any Home Center, or hardware store etc. for a few dollars. Fig 1 Page 6 7500-S Carbon Backwash Filter Guide www.cleanwaterstore.com rev102418...
  • Page 7: How Your Filter Works (Fig 2)

    Carbon Media. During the backwash the Carbon Media is cleaned by the action of the water flowing through it. Page 7 7500-S Carbon Backwash Filter Guide www.cleanwaterstore.com rev102418...
  • Page 8: Parts Included With Control Valve

    3. Next add the media. The tank should be about 2/3rds full of media, do not fill more than 2/3rds, even if there is some media left over. Page 8 7500-S Carbon Backwash Filter Guide www.cleanwaterstore.com rev102418...
  • Page 9 13. Do NOT install check valve on drain, use air gap (a gap of air of 2” between end of drain tubing coming from 7500-S control valve and opening to the drain pipe to sewer or septic tank. NOTE: for 2.0 CF sizes and up, use 1” piping for drain. For sizes smaller than 2.0 CF, it is OK to use 5/8”...
  • Page 10: Install By-Pass (Fig. 4)

    Install By-Pass (Fig. 4) A 3-valve by-pass must be installed around 7500-S filter system, typically using PVC, PEX or other types of piping. Don’t sweat copper directly on 7500-S or heat up plastic. Flex lines may be used instead of the unions and 90’s shown. You could have slip by male fittings, then flex lines, then male nipples.
  • Page 11: Diagram Of Installation Well Water (Fig. 5)

    Diagram of Installation Well Water (Fig. 5) Carbon Diagram of Installation City Water (Fig. 6) Carbon Page 11 7500-S Carbon Backwash Filter Guide www.cleanwaterstore.com rev102418...
  • Page 12: Programming Overview

    Digital Display Icons and the four Service Buttons: In addition to the Dynamic Display Stipe (explained below) there are eight digital icons on the display that will indicate “where the valve is”. They are as follows (left to right, top row bottom row): Page 12 7500-S Carbon Backwash Filter Guide www.cleanwaterstore.com rev102418...
  • Page 13 This is the button you press (after you have unlocked the screen) that puts you in the Service Menu, so you can program the valve. The first time you press it, the Dynamic Display Stripe goes away, and the blue Wrench icon appears Page 13 7500-S Carbon Backwash Filter Guide www.cleanwaterstore.com rev102418...
  • Page 14: Program The 7500-S Valve

    2:00 am. Water cannot be used from the service side during the 18-20 minutes the control valve needs to cycle through the wash and rinse steps. 8. 485 Port Setting: this does not need to be adjusted or changed. Page 14 7500-S Carbon Backwash Filter Guide www.cleanwaterstore.com rev102418...
  • Page 15: Initial Backwash And Start-Up

    Open the first tap after the filter and run until clear. 7 The filter system will need to be backwashed and rinsed several times before all the fines are gone and the media starts filtering normally. Page 15 7500-S Carbon Backwash Filter Guide www.cleanwaterstore.com rev102418...
  • Page 16: Limited Warranty

    7. This warranty is to the original purchaser and is not transferable after the third year to any subsequent owner(s). 8. No other guarantees or warranty, expressed or implied, is applicable to our product. No repair or replacement made under the terms of the warranty shall extend this warranty. Page 16 7500-S Carbon Backwash Filter Guide www.cleanwaterstore.com rev102418...
