- Page 1 Navigation Lights Signalling Lights Searchlights Whistles TECHNICAL MANUAL DHR80 LED MED2014/90/EU 46 CFR 111.75-17 Den Haan Rotterdam...
- Page 2 Den Haan Rotterdam DISCLAIMER Despite constant care and attention DHR puts in its manuals it is still possible that information in this man- ual is incomplete or incorrect. We do not guarantee that the information in the manual is suitable for the purpose for which the informa- tion was consulted.
-
Page 3: Table Of Contents
Den Haan Rotterdam TABLE OF CONTENTS Technical data Product photos Dimensions Available models Exploded view Repair kit Electrical specification Electrical spec. Manoeuvring light Lifetime control Positioning side lights Positioning all-round lights Mounting instructions Version 3.1 May 2018... -
Page 4: Technical Data
Den Haan Rotterdam TECHNICAL DATA Application: • As Navigation light for all sea-going vessels with a length of more than 20 metres • For all vessels used in (European) inland navigation • UL1104 (USA): for vessels of 65 feet or more in length In compliance with: •... -
Page 5: Product Photos
Den Haan Rotterdam PRODUCT PHOTOS Version 3.1 May 2018... -
Page 6: Dimensions
Den Haan Rotterdam DIMENSIONS Ø11 All dimensions in mm. Version 3.1 May 2018... -
Page 7: Available Models
Den Haan Rotterdam AVAILABLE MODELS Sector lights Min. Visibility Colour Nom. Power Art. Code Starboard 3 NM Green 5,9 W 80.01.00.00 Port 3 NM 6,1 W 80.02.00.00 Masthead 6 NM White 17,9 W 80.03.00.00 Stern 3 NM White 5,7 W 80.04.00.00 Towing 3 NM... -
Page 8: Exploded View
Den Haan Rotterdam EXPLODED VIEW Item Part Material Cover Seawater resistant aluminium, hard anodized black Gasket lens DHR80 EPDM - shore 30 Screen Seawater resistant aluminium, hard anodized black Glass Tube Borosilicate glass Heatsink Seawater resistant aluminium LED PCB MC-PCB, aluminium 1.55 mm Housing Seawater resistant aluminium, hard anodized black... -
Page 9: Electrical Specification
Den Haan Rotterdam ELECTRICAL SPECIFICATION LED DRIVER Power main Output 3-5 LEDS 24VDC (MAIN) Galvanic separation LED DRIVER Power spare Output 3-5 LEDS 24VDC (SPARE) Red cable ferrule PE - + White cable ferrule Main 24VDC Red cable ferrule PE - + Spare 24VDC White cable ferrule LED driver... -
Page 10: Electrical Spec. Manoeuvring Light
COLREG 72 at an operational lifetime of 50000 hrs. To guarantee a proper use of the LED navigation lights, we as a manufacturer advise the following: • Use the navigation light in combination with a DHR-specified control system, which monitors the status and operational life time of each individual navigation light •... -
Page 11: Positioning Side Lights
Den Haan Rotterdam POSITIONING SIDE LIGHTS Paint the inside matt black Parallel to the keel line 137,5 2˚ 112,5 8˚ 8˚ [mm] Disclaimer: • The minimum luminous intensity requirements in the forward direction are only guaranteed if the side- lights are mounted in accordance with this drawing and table. •... -
Page 12: Positioning All-Round Lights
Den Haan Rotterdam POSITIONING ALL-ROUND LIGHTS S[mm] D[mm] 6° 1000 1200 1400 1600 1800 Diagram for choosing the minimum distance between obstacle and mounting plate. Disclaimer: This is an illustration to indicate the position of the all-round light so not to be obscured by mast, topmasts or structures within the angular sector of more than 6 degrees. -
Page 13: Mounting Instructions
Den Haan Rotterdam MOUNTING INSTRUCTIONS Bolt M10 x (40 + M) Washer M10 Lantern base Mounting plate Min. 5 mm Washer M10 Nut M10 All dimensions in mm Mounting plate The mounting plate for navigation lights should be at least 5 mm thick and should not exceed a parallelism of // 00,5. - Page 14 Den Haan Rotterdam Wiring recommendations • Neoprene cable H07 RN3x1.5 • Cable diameter 6 - 9 mm USA: • Type SJ or equivalent and comply with UL 62 and IEEE 45- 83 • Wire gauge16 AWG • No. of conductors 3 •...
