- Page 1 Navigation Lights Signalling Lights Searchlights Whistles TECHNICAL MANUAL DHR60 LED MED2014/90/EU 46 CFR 111.75-17 Den Haan Rotterdam...
- Page 2 Den Haan Rotterdam DISCLAIMER Despite constant care and attention DHR puts in its manuals it is still possible that information in this manual is incomplete or incorrect. We do not guarantee that the information in the manual is suitable for the purpose for which the information was consulted.
-
Page 3: Table Of Contents
Den Haan Rotterdam TABLE OF CONTENTS Technical data Product photos Dimensions Available models Exploded view Repair kit Electrical specification Electrical spec. Manoeuvring light Lifetime control Positioning lights Positioning all-round light Mounting instructions Version 3.1 May 2018... -
Page 4: Technical Data
Den Haan Rotterdam TECHNICAL DATA Application • For all vessels used in (European) inland navigation • For all seagoing vessels with a length less than 50 meters • UL1104 (USA): for vessels of 65 feet or more in length In compliance with: •... -
Page 5: Product Photos
Den Haan Rotterdam PRODUCT PHOTOS Version 3.1 May 2018... -
Page 6: Dimensions
Den Haan Rotterdam DIMENSIONS Ø8,5 All dimensions in mm. Version 3.1 May 2018... -
Page 7: Available Models
Den Haan Rotterdam AVAILABLE MODELS Sector lights Min. Visibility Colour Nom. Power Art. Code Starboard 2 NM Green 4,2 W 60.01.00.00 Port 2 NM 4,3 W 60.02.00.00 Masthead 5 NM White 11,7 W 60.03.00.00 Stern 2 NM White 4,1 W 60.04.00.00 Stern red (Suez) 2 NM... -
Page 8: Exploded View
Den Haan Rotterdam EXPLODED VIEW Item Part Material Cover Seawater resistant aluminium, hard anodized black Gasket Ø91x4mm EPDM - shore 30 Screen Seawater resistant aluminium, hard anodized black Glass Tube Borosilicate glass Heatsink Seawater resistant aluminium LED PCB MC-PCB, aluminium 1.55 mm Cable gland M20x15 Body: Polyamide Seal: Neoprene... -
Page 9: Electrical Specification
Den Haan Rotterdam ELECTRICAL SPECIFICATION LED DRIVER Power main Output 3-5 LEDS 24VDC (MAIN) Galvanic separation LED DRIVER Power spare Output 3-5 LEDS 24VDC (SPARE) Red cable ferrule PE - + White cable ferrule Main 24VDC Red cable ferrule PE - + Spare 24VDC White cable ferrule LED driver... -
Page 10: Electrical Spec. Manoeuvring Light
COLREG 72 at an operational lifetime of 50000 hrs. To guarantee a proper use of the LED navigation lights, we as a manufacturer advise the following: • Use the navigation light in combination with a DHR-specified control system, which monitors the status and operational life time of each individual navigation light •... -
Page 11: Positioning Lights
Den Haan Rotterdam POSITIONING LIGHTS [mm] Disclaimer: • The minimum luminous intensity requirements in the forward direction are only guaranteed if the sidelights are mounted in accordance with this drawing and table. • This is an illustration to indicate the dimensions of the inboard screens, relative to the keel line of the vessel. -
Page 12: Positioning All-Round Light
Den Haan Rotterdam POSITIONING ALL-ROUND LIGHT S[mm] D[mm] 6° 1000 1200 1400 1600 1800 Diagram for choosing the minimum distance between obstacle and mounting plate. Disclaimer: This is an illustration to indicate the position of the all-round light so not to be obscured by mast, topmasts or structures within the angular sector of more than 6 degrees. -
Page 13: Mounting Instructions
Den Haan Rotterdam MOUNTING INSTRUCTIONS Bolt M8 x (35 + M) Insulation sleeve Lantern base Insulation sleeve Mounting plate Min. 3 mm Washer M8 Nut M8 All dimensions in mm Mounting plate The mounting plate for navigation lights should be at least 3 mm thick and should not exceed a parallelism of // 00,5. - Page 14 Den Haan Rotterdam Wiring recommendations • Neoprene cable H07 RN3x1.5 • Cable diameter 6 - 9 mm USA: • Type SJ or equivalent and comply with UL 62 and IEEE 45- 83 • Wire gauge16 AWG • No. of conductors 3 •...
- Page 15 Den Haan Rotterdam Version 3.1 May 2018...
- Page 16 ADVANCED MARITIME SIGNALLING SOLUTIONS Den Haan Rotterdam Fascinatio Boulevard 1182 2909 VA Capelle a/d IJssel The Netherlands T +31 (0) 10 413 07 55 E sales@dhr.nl www.dhr.nl...
