- Page 1 Wheelbarrow Mixer Operations Manual Part# MIX3, MIX3-UK EDI# 27275, 27276 104 S. 8th Ave. Marshalltown, IA Phone 800-888-0127 / 641-753-0127 Fax 800-477-6341 / 641-753-6341 www.marshalltown.com WS1213 1 of 20 2-2014/Rev.A...
-
Page 2: Table Of Contents
INTRODUCTION The Marshalltown Wheelbarrow mixer is great for the do-it-yourself home project. It allows you to work almost anywhere. The mixer will clear a 30" door and easily fits into an elevator. A sturdy 110-volt or 230-volt electric motor allows you to work indoors without emissions. -
Page 3: Safety Precautions
Lightly grease wheel axles and the swivel bracket. • Periodically examine the mixer for significant or abnormal damage/wear. • Use factory authorized parts for replacement. WS1213 3 of 20 104 S. 8th Ave. Marshalltown, IA Phone 800-888-0127 / 641-753-0127 • Fax 800-477-6341 / 641-753-6341 www.marshalltown.com 2-2014/Rev.A... -
Page 4: Warranty
This product is warranted to the original purchaser only, to be free of defects in material and workmanship under normal use, for one year from purchase date. Marshalltown Company shall without charge for parts and labor, repair or replace such parts which are found to be defective. All transportation charges for replacement parts must be borne by the purchaser. -
Page 5: Assembly
Drum MIX3DRUM On/Off Switch MIX3SWITCH Pedestal MIX3PEDESTAL Wheel (single) MIX3WHEEL Gearbox MIX3GEARS Paddle (single) MIX3BLADE * Component of E WS1213 5 of 20 104 S. 8th Ave. Marshalltown, IA Phone 800-888-0127 / 641-753-0127 • Fax 800-477-6341 / 641-753-6341 www.marshalltown.com 2-2014/Rev.A... - Page 6 M8 Curved Washers (x8) M14 Lock Washer M8 Lock Nuts (x4) M6 Lock Nuts (x2) M14 Washer 14mm Washers (x2) WS1213 6 of 20 104 S. 8th Ave. Marshalltown, IA Phone 800-888-0127 / 641-753-0127 • Fax 800-477-6341 / 641-753-6341 www.marshalltown.com 2-2014/Rev.A...
- Page 7 Use hardware 1A on top, use 1B on bottom. Fasten using a 14mm wrench and 14mm socket. Finished frame. WS1213 7 of 20 104 S. 8th Ave. Marshalltown, IA Phone 800-888-0127 / 641-753-0127 • Fax 800-477-6341 / 641-753-6341 www.marshalltown.com 2-2014/Rev.A...
- Page 8 Fasten using a 14mm wrench and 14mm socket. Use hardware 2B on top, 2A on bottom. Finished frame with handles. WS1213 8 of 20 104 S. 8th Ave. Marshalltown, IA Phone 800-888-0127 / 641-753-0127 • Fax 800-477-6341 / 641-753-6341 www.marshalltown.com 2-2014/Rev.A...
- Page 9 5. Connect wheels to the drum frame assembly. Hardware required: SET 3 Insert wheel and fasten with cotter pin. (Hardware 3) Repeat step for other side. Finished frame with wheels. WS1213 9 of 20 104 S. 8th Ave. Marshalltown, IA Phone 800-888-0127 / 641-753-0127 • Fax 800-477-6341 / 641-753-6341 www.marshalltown.com 2-2014/Rev.A...
- Page 10 Finished frame with motor. Insert washers onto studs between nuts and frame, and fasten nuts using 10mm wrench and 10mm socket. WS1213 10 of 20 104 S. 8th Ave. Marshalltown, IA Phone 800-888-0127 / 641-753-0127 • Fax 800-477-6341 / 641-753-6341 www.marshalltown.com 2-2014/Rev.A...
- Page 11 Install paddles with short side facing outward, Fasten using a 19mm wrench and 19mm socket. towards top of the drum. WS1213 11 of 20 104 S. 8th Ave. Marshalltown, IA Phone 800-888-0127 / 641-753-0127 • Fax 800-477-6341 / 641-753-6341 www.marshalltown.com 2-2014/Rev.A...
- Page 12 Two washers placed on bottom of drum, secured with bolt. Use a 22mm socket to tighten drum to motor spindle. WS1213 12 of 20 104 S. 8th Ave. Marshalltown, IA Phone 800-888-0127 / 641-753-0127 • Fax 800-477-6341 / 641-753-6341 www.marshalltown.com 2-2014/Rev.A...
- Page 13 Put screws through mounting holes. Mount to mixer frame. Use a Phillips screwdriver and 10mm wrench to Finished mixer. tighten. WS1213 13 of 20 104 S. 8th Ave. Marshalltown, IA Phone 800-888-0127 / 641-753-0127 • Fax 800-477-6341 / 641-753-6341 www.marshalltown.com 2-2014/Rev.A...
- Page 14 Tighten hardware using a 14mm wrench and 14mm socket. Attach remaining legs. Tighten remaining hardware. Finished pedestal. WS1213 14 of 20 104 S. 8th Ave. Marshalltown, IA Phone 800-888-0127 / 641-753-0127 • Fax 800-477-6341 / 641-753-6341 www.marshalltown.com 2-2014/Rev.A...
- Page 15 Lift mixer slightly and insert pedestal. Grab mixer handles and carefully lift mixer into the Completed mixer with pedestal. upright position. WS1213 15 of 20 104 S. 8th Ave. Marshalltown, IA Phone 800-888-0127 / 641-753-0127 • Fax 800-477-6341 / 641-753-6341 www.marshalltown.com 2-2014/Rev.A...
-
Page 16: Operation
Cover exposed metal surfaces with a thin coat of SAE 30 engine oil. WS1213 16 of 20 104 S. 8th Ave. Marshalltown, IA Phone 800-888-0127 / 641-753-0127 • Fax 800-477-6341 / 641-753-6341 www.marshalltown.com 2-2014/Rev.A... -
Page 17: Concrete Mixing Guide
6. Add water to obtain desired thickness * Amount of water will vary according to moisture content of sand and gravel. WS1213 17 of 20 104 S. 8th Ave. Marshalltown, IA Phone 800-888-0127 / 641-753-0127 • Fax 800-477-6341 / 641-753-6341 www.marshalltown.com 2-2014/Rev.A... -
Page 18: Parts And Service Information
Drum MIX3DRUM On/Off Switch MIX3SWITCH Pedestal MIX3PEDESTAL Wheel (single) MIX3WHEEL Gearbox MIX3GEARS Paddle (single) MIX3BLADE * Component of E WS1213 18 of 20 104 S. 8th Ave. Marshalltown, IA Phone 800-888-0127 / 641-753-0127 • Fax 800-477-6341 / 641-753-6341 www.marshalltown.com 2-2014/Rev.A... - Page 19 WS1213 19 of 20 104 S. 8th Ave. Marshalltown, IA Phone 800-888-0127 / 641-753-0127 • Fax 800-477-6341 / 641-753-6341 www.marshalltown.com 2-2014/Rev.A...
- Page 20 104 S. 8th Ave. Marshalltown, IA Phone 800-888-0127 / 641-753-0127 Fax 800-477-6341 / 641-753-6341 www.marshalltown.com WS1213 20 of 20 104 S. 8th Ave. Marshalltown, IA Phone 800-888-0127 / 641-753-0127 • Fax 800-477-6341 / 641-753-6341 www.marshalltown.com 2-2014/Rev.A...
